Dongfeng Commercial Vehicle Tianjin 230 hp 6X4(10 wheels) Garbage Truck (Zhonglian Brand)

Export reference
MSRP N/A
Emission: China III / Euro III
Fuel: Diesel
Wheelbase:: 4350+1300mm
Cab dimensions:: 8.422×2.48×3.42m
Type:: Side-loading compression refuse truck
Front/rear track width:: Front track: 1986mm; Rear track: 1860/1860mm
Box volume: 13.6m³
Drive 6X4 (10 wheels)
Horsepower 230
Rated mass: 8.2ton

Overview

The ZOOMLION Dongfeng Commercial Vehicle Tianjin 230 hp 6X4(10 wheels) Garbage Truck (Zhonglian Brand) is a garbage truck featuring 13.6m³ tank capacity, 13.6m³ volume, 20.49t GVW and 6X4 (10 wheels) drive. On the powertrain side, it comes with 230 hp, China III / Euro III emissions and Diesel fuel.

China III / Euro III 230 Diesel 6X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Cab dimensions: 8.422×2.48×3.42m
Type: Side-loading compression refuse truck
Drive type: 6X4
Front/rear track width: Front track: 1986mm; Rear track: 1860/1860mm
Wheelbase: 4350+1300mm
Rated mass: 8.2ton
GVWR: 20.49ton
Front/rear suspension: 1.46/1.312m
Energy Type: Diesel
Body Parameters
Special Function Description: Tilt discharge method, simple structure, fast and clean unloading.
Vehicle certification code: ZLJ5200ZLJE3
Body Brand: ZOOMLION
Engine parameters
Engine Model: Dongfeng ISDe23030
fuel type: Diesel
Displacement: 6.7L
Emission standard: China III / Euro III
Max output power: 169kW
Max hp: 230Horsepower
Rated speed: 2500rpm
Cargo box parameters
Box volume: 13.6m³
Chassis Specs
Chassis Brand: Dongfeng Commercial Vehicle
Chassis Series: Dongfeng Tianjin
Chassis Model: DFL1200AX8
Leaf spring count: 8/9
Tire
Tire Size: 11.00-2012PR
Number of tires: 10pcs

Photos

Exterior1

1 photos

FAQ

What emission standard does Dongfeng Commercial Vehicle Tianjin 230 hp 6X4(10 wheels) Garbage Truck (Zhonglian Brand) use, and can it enter my country?

This model is listed as China III / Euro III. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Dongfeng Commercial Vehicle Tianjin 230 hp 6X4(10 wheels) Garbage Truck (Zhonglian Brand)?

Key specs of Dongfeng Commercial Vehicle Tianjin 230 hp 6X4(10 wheels) Garbage Truck (Zhonglian Brand): Drive: 6x4; Horsepower: 230 hp; Emission: China III / Euro III; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Dongfeng Commercial Vehicle Tianjin 230 hp 6X4(10 wheels) Garbage Truck (Zhonglian Brand) suited for?

Dongfeng Commercial Vehicle Tianjin 230 hp 6X4(10 wheels) Garbage Truck (Zhonglian Brand) is a garbage truck model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does Dongfeng Commercial Vehicle Tianjin 230 hp 6X4(10 wheels) Garbage Truck (Zhonglian Brand) differ from other variants in the same series?

Dongfeng Commercial Vehicle Tianjin 230 hp 6X4(10 wheels) Garbage Truck (Zhonglian Brand) belongs to ZOOMLION Dongfeng Commercial Vehicle chassis (garbage truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Dongfeng Commercial Vehicle Tianjin 230 hp 6X4(10 wheels) Garbage Truck (Zhonglian Brand)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Dongfeng Commercial Vehicle Tianjin 230 hp 6X4(10 wheels) Garbage Truck (Zhonglian Brand)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
