Dayun Zhisheng 200 hp 4X2(6 wheels) Truck-mounted Crane (China VI) (Wheelbase 4.2m)

Export reference
MSRP N/A
Emission: China VI
Fuel: Diesel
Wheelbase:: 4200mm
Cab dimensions:: 7.81x2.5x3.75m
Type:: truck-mounted crane
GVWR:: 16.2ton
Lifting capacity: 7ton
Drive 4x2 (6 wheels)
Horsepower 200
Rated mass: 5.21ton

Overview

The Dayun Zhisheng 200 hp 4X2(6 wheels) Truck-mounted Crane (China VI) (Wheelbase 4.2m) is a truck-mounted crane featuring 7ton tank capacity, 16.2t GVW and 4x2 (6 wheels) drive. On the powertrain side, it comes with 200 hp, China VI emissions and Diesel fuel.

China VI 200 Diesel 4x2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Cab dimensions: 7.81x2.5x3.75m
Type: truck-mounted crane
Drive type: 4x2
Wheelbase: 4200mm
Rated mass: 5.21ton
GVWR: 16.2ton
Front/rear suspension: 1.3/2.31m
Energy Type: Diesel
Body Parameters
Crane model: S2005
Lifting capacity: 7ton
crane self-weight: 3.1ton
Vehicle certification code: DYQ5162JSQD6AB
Engine parameters
Engine Brand: Yuchai
Engine Model: YuchaiYCS04200-68
fuel type: Diesel
Displacement: 4.16L
Emission standard: China VI
Max output power: 147kW
Max hp: 200Horsepower
Max torque: 720N·m
Max torque speed: 1200-1600rpm
Rated speed: 2300rpm
Chassis Specs
Chassis Brand: Dayun
Chassis Series: Zhisheng
Chassis Model: DYQ1162D6AA
Frame Dimensions: (860-800)×280×(8+6+4)mm
rear axle description: 153 Shortened Axle/10t
Axle ratio: 5.571
Leaf spring count: 9/10+8
Transmission Parameters
Number of gears: 8Gear
Transmission Model: Fast Gear8JS85E-C
Cab parameters
Cab: Day cab standard roof
Tire
Tire Size: 9.00R20 16PR
Number of tires: 6pcs

Photos

Exterior1

1 photos

FAQ

What emission standard does Dayun Zhisheng 200 hp 4X2(6 wheels) Truck-mounted Crane (China VI) (Wheelbase 4.2m) use, and can it enter my country?

This model is listed as China VI. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Dayun Zhisheng 200 hp 4X2(6 wheels) Truck-mounted Crane (China VI) (Wheelbase 4.2m)?

Key specs of Dayun Zhisheng 200 hp 4X2(6 wheels) Truck-mounted Crane (China VI) (Wheelbase 4.2m): Drive: 4x2; Horsepower: 200 hp; Emission: China VI; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Dayun Zhisheng 200 hp 4X2(6 wheels) Truck-mounted Crane (China VI) (Wheelbase 4.2m) suited for?

Dayun Zhisheng 200 hp 4X2(6 wheels) Truck-mounted Crane (China VI) (Wheelbase 4.2m) is a truck-mounted crane model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does Dayun Zhisheng 200 hp 4X2(6 wheels) Truck-mounted Crane (China VI) (Wheelbase 4.2m) differ from other variants in the same series?

Dayun Zhisheng 200 hp 4X2(6 wheels) Truck-mounted Crane (China VI) (Wheelbase 4.2m) belongs to Dayun Zhisheng Medium Truck (truck-mounted crane). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Dayun Zhisheng 200 hp 4X2(6 wheels) Truck-mounted Crane (China VI) (Wheelbase 4.2m)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Dayun Zhisheng 200 hp 4X2(6 wheels) Truck-mounted Crane (China VI) (Wheelbase 4.2m)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
