JAC Junling J5 143 hp 4X2(6 wheels) 4.18m single-row stake truck

Export reference
From $19,444
MSRP ¥14M CNY
Horsepower: 143
Emission: China V
Fuel: Diesel
Engine: Yunnei Dewei D25
Curb Weight:: 2.72ton
Wheelbase:: 3308mm
seating capacity: 3Personnel
Rated payload: 1.58ton
Drive 4X2 (6 wheels)
Cargo box type: Stake type

Overview

The JAC Junling J5 143 hp 4X2(6 wheels) 4.18m single-row stake truck is a Light Truck featuring 4.18m cargo length, Stake type cargo body, 3Personnel volume and 1.58t payload. Its segment focus covers Agricultural product transport and green channel, matching those duty cycles. On the powertrain side, it comes with a Yunnei Dewei D25 engine, 143 hp, 4X2 (6 wheels) drive and China V emissions.

China V 143 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): HFC5043CCYP92K2C2NV
Type: stake truck
Drive type: 4X2
Wheelbase: 3308mm
Box length class: 4.2m
engine: Yunnei PowerD25TCIE1
transmission: 6-speed transmission
Rear Axle Ratio: 4.875
Cab length: 5.995m
Cab width: 2.18m
Cab height: 3.25m
Front track width: 1580mm
rear track: 1395mm
Curb Weight: 2.72ton
Rated payload: 1.58ton
GVWR: 4.495ton
Max. speed: 98km/h
Origin: Hefei, Anhui
tonnage class: Light Truck
Approach angle: 21°
departure angle: 15°
market segment: Agricultural product transport, green channel
Remarks: Standard: LED headlights; Optional: auto A/C (requires MP5).
Front/rear suspension: 1.075/1.612m
Energy Type: Diesel
Engine parameters
Engine Brand: Yunnei Power
Engine Model: Yunnei PowerD25TCIE1
Engine info: Yunnei Dewei D25
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 2.499L
Emission standard: China V
Max output power: 105kW
Max hp: 143Horsepower
Max torque: 360N·m
Max torque speed: 1600-2800rpm
Rated speed: 3600rpm
Engine Type: 4-cylinder inline, 16-valve, DOHC, turbocharged intercooled, high-pressure common rail fuel injection
Transmission Parameters
Transmission Model: 6-speed transmission
shift method: Manual
Forward gears: 6Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: Stake type
Cargo box length: 4.18m
Cargo box width: 2.075m
*Cargo box interior width: 2.0750000476837
Cab parameters
Cab width: 1900mm
seating capacity: 3Personnel
Seat rows: Single Row
Chassis Specs
Front axle allowable load: 1800kg
Frame Dimensions: 180×65×4.5mm
rear axle allowable load: 2695kg
Axle ratio: 4.875
Leaf spring count: 3/3+3,3/9+7,5/9+7,11/9+7,7/4+6,3/5+6,5/5+6
Frame Type: Dovetail beam
rear axle oil change interval: 60,000 km
Tire
Tire Size: 7.00R16
Number of tires: 6pcs
Control configuration
ABS:
Brake assist (EBA/BAS/BA etc.): none
Power steering:
clutch booster:
automatic slack adjuster:
interior configuration
Steering Wheel Material: Plastic
steering wheel adjustment: Manual
Multifunction steering wheel:
AC control type: Manual
Power Windows:
Electric Heated Rearview Mirror:
Power interface:
Reverse Radar:
Seat material: fabric/leather
Reverse Camera:
Remote key:
Electronic Central Lock:
Exterior features
Air deflector:
Aluminum air tank:
Wiper type: flat wiper blades
Multimedia features
Center Console Color Screen:
External audio input (AUX/USB/iPod etc.):
Radio:
standard instrument cluster: none
LCD instrument cluster:
Roadside assistance call:
lighting configuration
Front fog lamp:
daytime running lights:
LED taillight:
Halogen Headlights: none
Service brake
Brake Type: Air brake
Parking brake: Spring brake
Front wheel brake: Drum Type
Rear Wheel Brake: Drum Type
smart configuration
Telematics System:
Cruise control (CCS):
adaptive cruise control (ACC):
Fatigue driving monitoring:
maintenance service
Vehicle Warranty Period: 18 months or 50,000 km
Rescue service: none

Photos

0 photos

FAQ

What is the export price of JAC Junling J5 143 hp 4X2(6 wheels) 4.18m single-row stake truck, and what does it include?

JAC Junling J5 143 hp 4X2(6 wheels) 4.18m single-row stake truck export reference is about From $19,444; MSRP is ¥14M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does JAC Junling J5 143 hp 4X2(6 wheels) 4.18m single-row stake truck use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of JAC Junling J5 143 hp 4X2(6 wheels) 4.18m single-row stake truck?

Key specs of JAC Junling J5 143 hp 4X2(6 wheels) 4.18m single-row stake truck: Drive: 4x2; Horsepower: 143 hp; Emission: China V; Fuel: Diesel; Engine: Yunnei Dewei D25. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is JAC Junling J5 143 hp 4X2(6 wheels) 4.18m single-row stake truck suited for?

JAC Junling J5 143 hp 4X2(6 wheels) 4.18m single-row stake truck is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does JAC Junling J5 143 hp 4X2(6 wheels) 4.18m single-row stake truck differ from other variants in the same series?

JAC Junling J5 143 hp 4X2(6 wheels) 4.18m single-row stake truck belongs to JAC J5 light-duty truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for JAC Junling J5 143 hp 4X2(6 wheels) 4.18m single-row stake truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export JAC Junling J5 143 hp 4X2(6 wheels) 4.18m single-row stake truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
