JAC Kangling X1 82 hp 4X2(6 wheels) 2.7m Single Row Van Mini Truck

Export reference
MSRP N/A
Horsepower: 82
Emission: China IV
Fuel: gasoline
Engine: Liuji gasoline 1.3L
Transmission: Qingshan
Curb Weight:: 1.45ton
seating capacity: 2Personnel
Rated payload: 0.745ton
Drive 4X2 (6 wheels)
Cargo box type: Van body

Overview

The JAC Kangling X1 82 hp 4X2(6 wheels) 2.7m Single Row Van Mini Truck is a mini truck featuring 2.7m cargo length, Van body cargo body, 2Personnel volume and 0.745t payload. On the powertrain side, it comes with a Liuji gasoline 1.3L engine, 82 hp, 4X2 (6 wheels) drive and China IV emissions.

China IV 82 gasoline 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): HFC5020XXYPW4E1B1D
Type: enclosed cargo truck
Drive type: 4X2
Wheelbase: 2400mm
Box length class: 2.7m
engine: Wuling LiujiLJ474Q3E2
transmission: QingshanMR510D
Cab length: 4.36m
Cab width: 1.64m
Cab height: 2.35m
Front track width: 1260mm
rear track: 1360mm
Curb Weight: 1.45ton
Rated payload: 0.745ton
GVWR: 2.325ton
Max. speed: 96km/h
Origin: Hefei, Anhui
tonnage class: mini truck
Approach angle: 25°
departure angle: 22°
Front/rear suspension: 0.976/0.984m
Energy Type: gasoline
Engine parameters
Engine Brand: Wuling Liuji
Engine Model: Wuling LiujiLJ474Q3E2
Engine info: Liuji gasoline 1.3L
Number of cylinders: 4cylinder
fuel type: gasoline
Cylinder arrangement: Inline
Displacement: 1.298L
Emission standard: China IV
Max output power: 60.5kW
Max hp: 82Horsepower
Max torque: 102N·m
Max torque speed: 3000-3500rpm
Rated speed: 6000rpm
Engine Type: 4-stroke, water-cooled, inline, 16-valve, roof-shaped combustion chamber, single overhead camshaft, timing belt drive, electronic gasoline injection
Transmission Parameters
Transmission Model: QingshanMR510D
Transmission Brand: Qingshan
shift method: Manual
Forward gears: 5Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: Van body
Cargo box length: 2.7m
Cargo box width: 1.56m
Cargo box height: 1.65m
*Cargo box interior width: 1.5599999427795
Cab parameters
seating capacity: 2Personnel
Seat rows: Single Row
fuel tank
Fuel tank capacity: 45L
Chassis Specs
Front axle allowable load: 1030kg
rear axle allowable load: 1295kg
Leaf spring count: 3/5
Tire
Tire Size: 6.00-13
Number of tires: 4pcs
interior configuration
steering wheel adjustment: Manual
AC control type: Manual

Photos

0 photos

FAQ

What emission standard does JAC Kangling X1 82 hp 4X2(6 wheels) 2.7m Single Row Van Mini Truck use, and can it enter my country?

This model is listed as China IV. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of JAC Kangling X1 82 hp 4X2(6 wheels) 2.7m Single Row Van Mini Truck?

Key specs of JAC Kangling X1 82 hp 4X2(6 wheels) 2.7m Single Row Van Mini Truck: Drive: 4x2; Horsepower: 82 hp; Emission: China IV; Fuel: gasoline; Engine: Liuji gasoline 1.3L; Transmission: Qingshan. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is JAC Kangling X1 82 hp 4X2(6 wheels) 2.7m Single Row Van Mini Truck suited for?

JAC Kangling X1 82 hp 4X2(6 wheels) 2.7m Single Row Van Mini Truck is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does JAC Kangling X1 82 hp 4X2(6 wheels) 2.7m Single Row Van Mini Truck differ from other variants in the same series?

JAC Kangling X1 82 hp 4X2(6 wheels) 2.7m Single Row Van Mini Truck belongs to JACX1 Mini Truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for JAC Kangling X1 82 hp 4X2(6 wheels) 2.7m Single Row Van Mini Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export JAC Kangling X1 82 hp 4X2(6 wheels) 2.7m Single Row Van Mini Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
