Sinotruk Weilong Heavy Truck 320 hp 8X4(12 wheels) 6.8m Dump Truck Chassis

Export reference
From $45,694
MSRP ¥32.9M CNY
Fuel: Diesel
Transmission: Fast Gear
Curb Weight:: 9.99ton
Wheelbase:: 2050+3250+1350mm
Tire Size:: 11R22.5
Model code (announced):: SXQ3310J5A2D5
Drive 8X4 (12 wheels)
Horsepower 320
Cargo box type: Dump type
Emission China V

Overview

The Sinotruk Weilong Heavy Truck 320 hp 8X4(12 wheels) 6.8m Dump Truck Chassis is a Heavy truck featuring 31t GVW, Dump type cargo body and 8X4 (12 wheels) drive. On the powertrain side, it comes with a JMC Ford JX6D09.365A5 engine, 320 hp, China V emissions and Fast Gear transmission.

China V 320 Diesel 8X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): SXQ3310J5A2D5
Drive type: 8X4
Wheelbase: 2050+3250+1350mm
engine: JMC Ford JX6D09.365A5
transmission: Fast Gear 10-Speed
Rear Axle Ratio: 4.44
Cab length: 9.115m
Cab width: 2.55m
Cab height: 3.15m
Front track width: 2066mm
rear track: 1877mm
Curb Weight: 9.99ton
GVWR: 31ton
Origin: Shanxi Taiyuan
tonnage class: Heavy truck
Approach angle: 20°
departure angle: 47°
Energy Type: Diesel
Engine parameters
Engine Brand: JMC Ford
Engine Model: JMC Ford JX6D09.320A5
Number of cylinders: 6cylinder
fuel type: Diesel
Displacement: 8.974L
Emission standard: China V
Max output power: 235kW
Max hp: 320Horsepower
Max torque: 1300N·m
Max torque speed: 1200-1700rpm
Rated speed: 2200rpm
Engine Type: 4-stroke, 4-valve, high-pressure common rail
Transmission Parameters
Transmission Model: Fast Gear 10-Speed
Transmission Brand: Fast Gear
Forward gears: 10Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Unloading Type: Dump type
Cargo box type: Dump type
Cab parameters
Cab suspension: Four-point air suspension
Cab tilting: Electric
Driver seat type: Mechanical suspension seat
Sunroof: Manual sunroof
fuel tank
Fuel tank material: aluminum alloy
Fuel tank capacity: 400L
Chassis Specs
Front axle allowable load: 6500/6500kg
rear axle description: XPT-26-470, 13t cast axle
rear axle allowable load: 18000 (tandem axle group)kg
Axle ratio: 4.44
Leaf spring count: 3/3/13
Tire
Tire Size: 11R22.5
Number of tires: 10pcs
Control configuration
ABS:
ASR traction control:
interior configuration
steering wheel adjustment: pneumatic
Power Windows:
Power Mirrors:
Electric Heated Rearview Mirror:
Electronic Central Lock:
Multimedia features
GPS/Beidou driving recorder:
Service brake
Front wheel brake: Drum Type
Rear Wheel Brake: Drum Type

Photos

0 photos

FAQ

What is the export price of Sinotruk Weilong Heavy Truck 320 hp 8X4(12 wheels) 6.8m Dump Truck Chassis, and what does it include?

Sinotruk Weilong Heavy Truck 320 hp 8X4(12 wheels) 6.8m Dump Truck Chassis export reference is about From $45,694; MSRP is ¥32.9M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Sinotruk Weilong Heavy Truck 320 hp 8X4(12 wheels) 6.8m Dump Truck Chassis use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Sinotruk Weilong Heavy Truck 320 hp 8X4(12 wheels) 6.8m Dump Truck Chassis?

Key specs of Sinotruk Weilong Heavy Truck 320 hp 8X4(12 wheels) 6.8m Dump Truck Chassis: Drive: 8x4; Horsepower: 320 hp; Emission: China V; Fuel: Diesel; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Sinotruk Weilong Heavy Truck 320 hp 8X4(12 wheels) 6.8m Dump Truck Chassis suited for?

Sinotruk Weilong Heavy Truck 320 hp 8X4(12 wheels) 6.8m Dump Truck Chassis is a Dump Trucks model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does Sinotruk Weilong Heavy Truck 320 hp 8X4(12 wheels) 6.8m Dump Truck Chassis differ from other variants in the same series?

Sinotruk Weilong Heavy Truck 320 hp 8X4(12 wheels) 6.8m Dump Truck Chassis belongs to Sinotruk Weilong heavy truck (Dump Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Sinotruk Weilong Heavy Truck 320 hp 8X4(12 wheels) 6.8m Dump Truck Chassis?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Sinotruk Weilong Heavy Truck 320 hp 8X4(12 wheels) 6.8m Dump Truck Chassis?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
