JAC GallopKW Heavy Truck 310hp 8X4(12 wheels) 9.5m Crew Cab Flatbed Cargo Truck (153 Rear Axle)

Export reference
MSRP N/A
Horsepower: 310
Emission: China IV
Fuel: Diesel
Engine: WeichaiWP10
Transmission: Fast Gear
Curb Weight:: 11.85ton
seating capacity: 3Personnel
Rated payload: 18.905ton
Drive 8X4 (12 wheels)
Cargo box type: stake body

Overview

The JAC GallopKW Heavy Truck 310hp 8X4(12 wheels) 9.5m Crew Cab Flatbed Cargo Truck (153 Rear Axle) is a Heavy-duty cargo trucks featuring 9.5m cargo length, stake body cargo body, 3Personnel volume and 18.905t payload. On the powertrain side, it comes with a WeichaiWP10 engine, 310 hp, 8X4 (12 wheels) drive and China IV emissions.

China IV 310 Diesel 8X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): HFC1311P2K4H45F
Type: Cargo Trucks
Drive type: 8X4
Wheelbase: 1900+4500+1350mm
Box length class: 9.5m
engine: WeichaiWP10.310E41
transmission: Fast Gear9JS119TA
Rear Axle Ratio: 4.44
Cab length: 11.9m
Cab width: 2.495m
Cab height: 3.29m
Front track width: 2040/2040mm
rear track: 1847/1847mm
Curb Weight: 11.85ton
Rated payload: 18.905ton
GVWR: 30.95ton
Max. speed: 95km/h
Origin: Hefei, Anhui
tonnage class: Heavy-duty cargo trucks
Approach angle: 22°
departure angle: 14°
Front/rear suspension: 1.495/2.745m
Energy Type: Diesel
Engine parameters
Engine Brand: Weichai
Engine Model: WeichaiWP10.310E41
Engine info: WeichaiWP10
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 9.726L
Emission standard: China IV
Max output power: 228kW
Max hp: 310Horsepower
Max torque: 1180N·m
Max torque speed: 1200-1600rpm
Rated speed: 2200rpm
Engine Type: Water-cooled, four-stroke, with exhaust brake, direct injection, turbocharged intercooled, electronic high-pressure common rail + SCR
Transmission Parameters
Transmission Model: Fast Gear9JS119TA
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 9Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: stake body
Cargo box length: 9.5m
Cargo box width: 2.4m
Cargo box height: 0.55m
*Cargo box interior width: 2.4000000953674
Cab parameters
Cab: High roof
seating capacity: 3Personnel
Seat rows: Sleeper cab
fuel tank
Fuel tank material: aluminum alloy
Fuel tank capacity: 600L
Chassis Specs
Front axle description: 5T
Front axle allowable load: 6500/6500kg
Frame Dimensions: 302x90x8mm
rear axle description: 153 rear axle
rear axle allowable load: 17950 (tandem axle)kg
Axle ratio: 4.44
Leaf spring count: 9/9/12
Suspension (front/rear): Leaf spring
Tire
Tire Size: 11.00R20,12R22.5,12.00R20
Number of tires: 12pcs
Control configuration
ABS:

Photos

0 photos

FAQ

What emission standard does JAC GallopKW Heavy Truck 310hp 8X4(12 wheels) 9.5m Crew Cab Flatbed Cargo Truck (153 Rear Axle) use, and can it enter my country?

This model is listed as China IV. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of JAC GallopKW Heavy Truck 310hp 8X4(12 wheels) 9.5m Crew Cab Flatbed Cargo Truck (153 Rear Axle)?

Key specs of JAC GallopKW Heavy Truck 310hp 8X4(12 wheels) 9.5m Crew Cab Flatbed Cargo Truck (153 Rear Axle): Drive: 8x4; Horsepower: 310 hp; Emission: China IV; Fuel: Diesel; Engine: WeichaiWP10; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is JAC GallopKW Heavy Truck 310hp 8X4(12 wheels) 9.5m Crew Cab Flatbed Cargo Truck (153 Rear Axle) suited for?

JAC GallopKW Heavy Truck 310hp 8X4(12 wheels) 9.5m Crew Cab Flatbed Cargo Truck (153 Rear Axle) is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does JAC GallopKW Heavy Truck 310hp 8X4(12 wheels) 9.5m Crew Cab Flatbed Cargo Truck (153 Rear Axle) differ from other variants in the same series?

JAC GallopKW Heavy Truck 310hp 8X4(12 wheels) 9.5m Crew Cab Flatbed Cargo Truck (153 Rear Axle) belongs to JAC Gallop K3 Heavy Truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for JAC GallopKW Heavy Truck 310hp 8X4(12 wheels) 9.5m Crew Cab Flatbed Cargo Truck (153 Rear Axle)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export JAC GallopKW Heavy Truck 310hp 8X4(12 wheels) 9.5m Crew Cab Flatbed Cargo Truck (153 Rear Axle)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
