Dongfeng 462-13.0t grade medium-rear axle

Export reference
MSRP N/A
Applicable Tire:: 11.00R20
Front/rear track width:: 1820/1860mm
Transmission Ratio:: 3.07,6.33
Axle Model: 462-13.0t medium/rear axle
Brake size: Φ410×220
Axle Type: Drive axle

Overview

The Dongfeng 462-13.0t grade medium-rear axle is a parts product with spec 462-13.0t medium/rear axle and Φ410×220 size.

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Axle Model: 462-13.0t medium/rear axle
Axle Type: Drive axle
Applicable Tire: 11.00R20
Front/rear track width: 1820/1860mm
Rated axle load: 2×13000ton
Transmission Ratio: 3.07,6.33
Brake size: Φ410×220
Max output torque: 2×43000N·m
Rim Used: 8.0-20inch
Wheel Bolts: Φ335-10×M22mm
Remarks: Through-type dual drive axles, stamped-welded axle housing

Photos

Exterior1

1 photos

FAQ

What transport jobs is Dongfeng 462-13.0t grade medium-rear axle suited for?

Match Dongfeng 462-13.0t grade medium-rear axle to your job using drive, horsepower and emission on this page. Include use case, destination and quantity in your quote request.

How does Dongfeng 462-13.0t grade medium-rear axle differ from other variants in the same series?

Dongfeng 462-13.0t grade medium-rear axle belongs to Dongfeng drive axle (axle). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Dongfeng 462-13.0t grade medium-rear axle?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Dongfeng 462-13.0t grade medium-rear axle?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
