Dongfeng DD2201D-300H 22.0-ton drive rear axle
EXW
Export quote
Dongfeng drive axle
Main model photos
24 photos
Models
On sale
Dongfeng DF1601D-300H 16.0-ton drive rear axle
EXW
Export quote
Dongfeng DF1302D-485 13.0-ton drive rear axle
EXW
Export quote
Dongfeng DF2001D-485 20.0-ton drive rear axle
EXW
Export quote
Dongfeng DF2001TD-440 10.0-ton through-type drive dual axle
EXW
Export quote
Series Specs
Basic Info
Axle Model: DD2201D-300H / DF1601D-300H / DF1302D-485 / DF2001D-485 / DF2001TD-440 / DD1001D-440 / DD1001D-400 / DF0601D-380 / DF0651D-310 / DF0422D-310 / DF0502D-285 / DF0302D-285 / DF4401TD-300H / DF3201TD-300H / 13t hub reduction through-drive tandem axle / DF2001TD-485 / DF2601TD-485 / 462-13.0t medium/rear axle / 10.0t through-drive dual axle / DF0402D-285 / 13.0t drive rear axle / 10.0t drive rear axle / DF0901D-350 / DF0801D-350 / DF0701D-380 / DF0551D-310 / 3.3t steering drive axle / 2.7t steering drive axle / Dongfeng new generation 485 drive axle / Dana DF0801D-380S
Axle Type: Drive axle / Steering axle
Applicable Tire: 12.0-20/12.00R20 / 12.0-20/11.0-20 / 11.00R20 / 7.50-20/10.00R20 / 7.50R15 / 8.0-20/11.00R20 / 7.5-20/10.00R20 / 9.00-20 / 7.00-20/9.00-20 / 7.00-16 / 12.00-20
Front/rear track width: 1860/1880 / 1860 / 1820-1860 / 1890 / 1860/1880/2075 / 1820 / 1628/1640 / 1800 / 1485/1530.5 / 1586 / 1820-1880 / 1820/1860 / 1750-1880 / 1458-1603 / 1750-1860 / 1650/1700/1800 / 1610/1630/1683.5 / 1774mm
Rated axle load: 22000 / 16000 / 13000 / 20000 / 10000×2 / 10000 / 9000 / 6000 / 4200 / 5000 / 3000 / 2×22000 / 2×16000 / 2×13000 / 2×10000 / 4000 / 8000 / 7000 / 5500 / 3300 / 2700 / 13000-16000 / 10000-16000ton
Transmission Ratio: 2.5,3.91,4.77,5.26,5.57,5.92,6.36,6.73 / 2.69,3.07,3.42,3.64,3.73,3.91,4.1,4.44,4.88,5.57,6.33 / 2.56,2.69,2.87,3.07,3.42,3.64,3.91,4.1 / 3.42,3.91,4.10,4.33,6.14 / 4.33,4.44,4.88,5.13,5.83,6.33,6.83 / 3.73,3.91,4.30,4.88,5.38,5.86 / 4.33,4.88,5.29,6.14,6.17 / 4.20/4.64/5.22/5.60/5.93/6.72 / 3.07,6.33 / 3.07,3.42,3.64,3.73,3.91,4.10,4.44,4.88,5.14,5.29,5.57,6.17,6.50,6.83 / 3.07,4.11,4.88,5.29,5.71,6.14 / 3.42,3.91,4.44,4.41,4.88,5.13,5.29,5.57,6.14,6.33,6.50 / 4.1,6.83 / 4.33,4.88,5.13,5.29,5.86,6.33,6.83 / 3.1-7.62 / 2.86-6.33 / 5.571
Brake: Air brake actuator / Hydraulic brake / air brake / Air brake / Hydraulic brake / S-cam roller type / drum brake / disc brake
Brake size: Φ410 / Φ400 / Φ310/Φ360 / Φ310 / Φ320/Φ310 / Φ300/Φ310 / Φ410×220 / Φ410×220/22.5 / Hydraulic brake Φ310×90 / hydraulic brake Φ300×75 / Φ410×180/Φ410×220 / Φ400×180 / Φ400×155 / Φ310×150 / Φ400×110 / Φ380×90 / Ф410X220
curb weight: 310 / 236/285 / 198 / 233 / 316 / 8000kg
Max output torque: 55000 / 50000 / 35000×2 / 35000 / 30000 / 16600 / 15000 / 11000 / 10000 / 9000 / 2×55000 / 2×50000 / 2×45000 / 50000×2 / 2×43000 / 2×30000 / 43000 / 24000 / 18000N·m
Rim Used: 20 / 8.0-20 / 5.5F-15 / 5.5F-16 / 8.5×20 in, 12.5R20 / 8.5×18 in, 11R18 / 8.5-20inch
Wheel Bolts: 10×M22×1.5/Φ335 / 10×M20×1.5/Φ335 / Φ335-10×M22 / Φ285.75-10×M20×1.5 / Φ203.2-5×M18 / Φ335-10×M20 / Φ275-8×M20×1.5 / Φ275-8×M20 / Φ222.25 / Φ222.25-6×M20×1.5 / 10-M22*1.5mm
Remarks: Cast / Stamped-welded / stamped-welded axle housing / Wheel-side drive through tandem axle; DF4401TD-300H / Wheel-side drive through tandem axle; cast / Wheel-side drive through tandem axle; DF2601TD-300H / Through-type dual drive axles; stamped-welded / Through-type dual drive axles / Through-type dual drive axles, stamped-welded axle housing / Single drive axle, stamped/welded axle housing / Single drive axle, stamped/welded or cast axle housing / Single drive axle, cast axle housing / Single drive axle, stamped/welded axle housing; spring seat center distance: 952mm / Steering drive axle, welded axle housing / Steering drive axle, cast axle housing / Cast axle housing, wheel-end reduction / Stamped-welded / cast steel axle housing / 8.0 rear drive axle
FAQ
What kind of truck is Dongfeng Dongfeng drive axle axle?
Dongfeng Dongfeng drive axle is an export-oriented axle lineup with about 31 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is axle typically used for?
For axle, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Dongfeng drive axle include?
Dongfeng drive axle currently lists about 31 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng drive axle?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
