Kama HK6 Fulai 110hp 4X2(6 wheels) 3.6m Dump Truck

Export reference
From $11,250
MSRP ¥8.1M CNY
Emission: China V
Fuel: Diesel
Curb Weight:: 2.72ton
Wheelbase:: 2800mm
Tire Size:: 6.50R16LT 10PR \7.00R16RT8PR
Model code (announced):: KMC3041HA28D5
Rated payload: 1.645ton
Drive 4X2 (6 wheels)
Horsepower 110
Cargo box type: Dump type

Overview

The Kama HK6 Fulai 110hp 4X2(6 wheels) 3.6m Dump Truck is a Light Truck featuring 1.645t payload, 4.495t GVW, Dump type cargo body and 4X2 (6 wheels) drive. On the powertrain side, it comes with a WeichaiWP2.3Q110E50 engine, 110 hp, China V emissions and 5-speed transmission transmission.

China V 110 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): KMC3041HA28D5
Drive type: 4X2
Wheelbase: 2800mm
engine: WeichaiWP2.3Q110E50
transmission: 5-speed transmission
Cab length: 5.46m
Cab width: 1.94m
Cab height: 2.28m
Front track width: 1495mm
rear track: 1490mm
Curb Weight: 2.72ton
Rated payload: 1.645ton
GVWR: 4.495ton
Origin: Shouguang, Shandong
tonnage class: Light Truck
Approach angle: 20°
departure angle: 18°
Energy Type: Diesel
Engine parameters
Engine Brand: Weichai
Engine Model: WeichaiWP2.3Q110E50
Number of cylinders: 4cylinder
fuel type: Diesel
Displacement: 2.29L
Emission standard: China V
Max output power: 81kW
Max hp: 110Horsepower
Max torque: 280N·m
Max torque speed: 1700-2300rpm
Rated speed: 3200rpm
Engine Type: Common Rail+SCR
Transmission Parameters
Transmission Model: 5-speed transmission
Forward gears: 5Gear
Number of Reverse Gears:
Cargo box parameters
Unloading Type: Dump type
Cargo box type: Dump type
Cargo box length: 3.6m
Cargo box width: 1.83m
Cargo box height: 0.39m
Cab parameters
Cab: 1680 canopy single row
Chassis Specs
Front axle description: 1060BQSM-2
Front axle allowable load: 1610kg
rear axle description: 1043AQDSM-2
rear axle allowable load: 2885kg
Leaf spring count: 9/8+4
Tire
Tire Size: 6.50R16LT 10PR \7.00R16RT8PR
Number of tires: 6pcs
Control configuration
ABS:

Photos

Exterior1

1 photos

FAQ

What is the export price of Kama HK6 Fulai 110hp 4X2(6 wheels) 3.6m Dump Truck, and what does it include?

Kama HK6 Fulai 110hp 4X2(6 wheels) 3.6m Dump Truck export reference is about From $11,250; MSRP is ¥8.1M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Kama HK6 Fulai 110hp 4X2(6 wheels) 3.6m Dump Truck use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Kama HK6 Fulai 110hp 4X2(6 wheels) 3.6m Dump Truck?

Key specs of Kama HK6 Fulai 110hp 4X2(6 wheels) 3.6m Dump Truck: Drive: 4x2; Horsepower: 110 hp; Emission: China V; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Kama HK6 Fulai 110hp 4X2(6 wheels) 3.6m Dump Truck suited for?

Kama HK6 Fulai 110hp 4X2(6 wheels) 3.6m Dump Truck is a Dump Trucks model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does Kama HK6 Fulai 110hp 4X2(6 wheels) 3.6m Dump Truck differ from other variants in the same series?

Kama HK6 Fulai 110hp 4X2(6 wheels) 3.6m Dump Truck belongs to Kama HK6 Light Truck (Dump Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Kama HK6 Fulai 110hp 4X2(6 wheels) 3.6m Dump Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Kama HK6 Fulai 110hp 4X2(6 wheels) 3.6m Dump Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
