Sinotruk SITRAK C5H 340hp 8X4(12 wheels) Aluminum Alloy Oil Tanker Truck (Chusheng Brand)

Export reference
From $67,361
MSRP ¥48.5M CNY
Curb Weight:: 11.205ton
Emission: China V
Fuel: Diesel
Wheelbase:: 1800+4575+1400mm
Cab dimensions:: 11.85×2.5×3.45m
Truck Type:: aluminum fuel tanker truck
Tank Size: 9.2×2.35×1.5m
Rated payload: 20.665ton
Drive 8X4 (12 wheels)
Horsepower 340

Overview

The Sinotruk SITRAK C5H 340hp 8X4(12 wheels) Aluminum Alloy Oil Tanker Truck (Chusheng Brand) is a fuel tanker truck featuring 9.2×2.35×1.5m tank capacity, 20.665t payload, 26m³ volume and 11.205ton GVW. On the powertrain side, it comes with 340 hp, 8X4 (12 wheels) drive, China V emissions and Diesel fuel.

China V 340 Diesel 8X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Cab dimensions: 11.85×2.5×3.45m
Drive type: 8X4
Truck Type: aluminum fuel tanker truck
Vehicle origin: Suizhou, Hubei
Wheelbase: 1800+4575+1400mm
Front track width: 2015/2015mm
rear track: 1830/1830mm
Curb Weight: 11.205ton
Rated payload: 20.665ton
Max. speed: 80km/h
Front/rear suspension: 1.43/2.645m
Energy Type: Diesel
Body Parameters
Tank Size: 9.2×2.35×1.5m
Tank Volume: 26m3
Vehicle certification code: CSC5326GYYLZKA
Body Brand: Chusheng Brand
Engine parameters
Engine Brand: Sinotruk
Engine Model: SinotrukMC07.34-50
Number of cylinders: 6cylinder
fuel type: Diesel
Displacement: 6.87L
Emission standard: China V
Max output power: 248kW
Max hp: 340Horsepower
Max torque: 1250N·m
Max torque speed: 1200-1800rpm
Rated speed: 2300rpm
Engine Type: Inline, water-cooled, 4-stroke, turbocharged with intercooler
Chassis Specs
Chassis Brand: Sitrak
Chassis Series: SITRAK C5H
Chassis Model: ZZ1326N466GE1K
Leaf spring count: 3/3/-/-
Transmission Parameters
Number of gears: 9Gear
Transmission Model: Sinotruk 9-speed
Tire
Tire Size: 295/80R22.5
Number of tires: 12pcs

Photos

Exterior1

1 photos

FAQ

What is the export price of Sinotruk SITRAK C5H 340hp 8X4(12 wheels) Aluminum Alloy Oil Tanker Truck (Chusheng Brand), and what does it include?

Sinotruk SITRAK C5H 340hp 8X4(12 wheels) Aluminum Alloy Oil Tanker Truck (Chusheng Brand) export reference is about From $67,361; MSRP is ¥48.5M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Sinotruk SITRAK C5H 340hp 8X4(12 wheels) Aluminum Alloy Oil Tanker Truck (Chusheng Brand) use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Sinotruk SITRAK C5H 340hp 8X4(12 wheels) Aluminum Alloy Oil Tanker Truck (Chusheng Brand)?

Key specs of Sinotruk SITRAK C5H 340hp 8X4(12 wheels) Aluminum Alloy Oil Tanker Truck (Chusheng Brand): Drive: 8x4; Horsepower: 340 hp; Emission: China V; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Sinotruk SITRAK C5H 340hp 8X4(12 wheels) Aluminum Alloy Oil Tanker Truck (Chusheng Brand) suited for?

Sinotruk SITRAK C5H 340hp 8X4(12 wheels) Aluminum Alloy Oil Tanker Truck (Chusheng Brand) is a fuel tanker truck model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does Sinotruk SITRAK C5H 340hp 8X4(12 wheels) Aluminum Alloy Oil Tanker Truck (Chusheng Brand) differ from other variants in the same series?

Sinotruk SITRAK C5H 340hp 8X4(12 wheels) Aluminum Alloy Oil Tanker Truck (Chusheng Brand) belongs to Chusheng Sitrak chassis (fuel tanker truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Sinotruk SITRAK C5H 340hp 8X4(12 wheels) Aluminum Alloy Oil Tanker Truck (Chusheng Brand)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Sinotruk SITRAK C5H 340hp 8X4(12 wheels) Aluminum Alloy Oil Tanker Truck (Chusheng Brand)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
