JAC Kangling X3 61 hp 4X2(6 wheels) 1.1L Gasoline 2.5m Double Row Stake Mini Truck

Export reference
From $5,833
MSRP ¥4.2M CNY
Horsepower: 60
Emission: China V
Fuel: gasoline
Engine: Liuji gasoline 1.1L
Transmission: Qingshan
Curb Weight:: 1.32ton
seating capacity: 5Personnel
Rated payload: 1.35ton
Drive 4X2 (6 wheels)
Cargo box type: Stake type

Overview

The JAC Kangling X3 61 hp 4X2(6 wheels) 1.1L Gasoline 2.5m Double Row Stake Mini Truck is a mini truck featuring 2.5m cargo length, Stake type cargo body, 5Personnel volume and 1.35t payload. On the powertrain side, it comes with a Liuji gasoline 1.1L engine, 60 hp, 4X2 (6 wheels) drive and China V emissions.

China V 60 gasoline 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): HFC5030CCYRW6E2B7DV
Type: stake truck
Drive type: 4X2
Wheelbase: 2700mm
Box length class: 2.5m
engine: Wuling LiujiLJ465Q-2AE
transmission: QingshanMR508A
Cab length: 5.05m
Cab width: 1.61m
Cab height: 2.41m
Front track width: 1260mm
rear track: 1260mm
Curb Weight: 1.32ton
Rated payload: 1.35ton
GVWR: 2.995ton
Max. speed: 105km/h
Origin: Hefei, Anhui
tonnage class: mini truck
Approach angle: 32°
departure angle: 20°
Remarks: Dual sun visors, optional A/C, electronic power steering
Front/rear suspension: 0.91/1.41m
Energy Type: gasoline
Engine parameters
Engine Brand: Wuling Liuji
Engine Model: Wuling LiujiLJ465Q-2AE
Engine info: Liuji gasoline 1.1L
Number of cylinders: 4cylinder
fuel type: gasoline
Cylinder arrangement: Inline
Displacement: 1.051L
Emission standard: China V
Max output power: 45kW
Max hp: 60Horsepower
Max torque: 850N·m
Max torque speed: 3500-4000rpm
Rated speed: 5600rpm
Engine Type: 4-stroke, inline inclined, mechanically adjusted roller rocker arm, electronic fuel injection, electronic ignition
Transmission Parameters
Transmission Model: QingshanMR508A
Transmission Brand: Qingshan
shift method: Manual
Forward gears: 5Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: Stake type
Cargo box length: 2.5m
Cargo box width: 1.51m
*Cargo box interior width: 1.5099999904633
Cab parameters
Cab width: 1475mm
seating capacity: 5Personnel
Seat rows: Double cab
Chassis Specs
Front axle allowable load: 1445kg
rear axle allowable load: 1550kg
Leaf spring count: 5/3+1,5/4
Tire
Tire Size: 175R14LT
Number of tires: 4pcs
Control configuration
Load-sensing proportioning valve (SABS):
interior configuration
steering wheel adjustment: Manual
Service brake
Brake Type: Hydraulic brake
Front wheel brake: Disc
Rear Wheel Brake: Drum Type

Photos

0 photos

FAQ

What is the export price of JAC Kangling X3 61 hp 4X2(6 wheels) 1.1L Gasoline 2.5m Double Row Stake Mini Truck, and what does it include?

JAC Kangling X3 61 hp 4X2(6 wheels) 1.1L Gasoline 2.5m Double Row Stake Mini Truck export reference is about From $5,833; MSRP is ¥4.2M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does JAC Kangling X3 61 hp 4X2(6 wheels) 1.1L Gasoline 2.5m Double Row Stake Mini Truck use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of JAC Kangling X3 61 hp 4X2(6 wheels) 1.1L Gasoline 2.5m Double Row Stake Mini Truck?

Key specs of JAC Kangling X3 61 hp 4X2(6 wheels) 1.1L Gasoline 2.5m Double Row Stake Mini Truck: Drive: 4x2; Horsepower: 60 hp; Emission: China V; Fuel: gasoline; Engine: Liuji gasoline 1.1L; Transmission: Qingshan. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is JAC Kangling X3 61 hp 4X2(6 wheels) 1.1L Gasoline 2.5m Double Row Stake Mini Truck suited for?

JAC Kangling X3 61 hp 4X2(6 wheels) 1.1L Gasoline 2.5m Double Row Stake Mini Truck is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does JAC Kangling X3 61 hp 4X2(6 wheels) 1.1L Gasoline 2.5m Double Row Stake Mini Truck differ from other variants in the same series?

JAC Kangling X3 61 hp 4X2(6 wheels) 1.1L Gasoline 2.5m Double Row Stake Mini Truck belongs to JAC X3 light-duty truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for JAC Kangling X3 61 hp 4X2(6 wheels) 1.1L Gasoline 2.5m Double Row Stake Mini Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export JAC Kangling X3 61 hp 4X2(6 wheels) 1.1L Gasoline 2.5m Double Row Stake Mini Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
