FAW Jiefang Aowei (J5P) heavy truck 350 hp 8X4(12 wheels) stake truck

Export reference
From $43,056
MSRP ¥31M CNY
Horsepower: 350
Emission: China III / Euro III
Fuel: Diesel
Engine: Xichai9L
Transmission: Fast Gear
Curb Weight:: 13.6ton
seating capacity: 3Personnel
Rated payload: 17.1ton
Drive 8X4 (12 wheels)
Cargo box type: Stake type

Overview

The FAW Jiefang Aowei (J5P) heavy truck 350 hp 8X4(12 wheels) stake truck is a Heavy-duty cargo trucks featuring 9.5m cargo length, Stake type cargo body, 3Personnel volume and 17.1t payload. Its segment focus covers Agricultural product transport, LTL transport and green channel, matching those duty cycles. On the powertrain side, it comes with a Xichai9L engine, 350 hp, 8X4 (12 wheels) drive and China III / Euro III emissions.

China III / Euro III 350 Diesel 8X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): CA5312CLXYP21K2L2T4E
Type: stake truck
Drive type: 8X4
Wheelbase: 2000+4700+1350mm
engine: XichaiCA6DL2-35E3
transmission: Fast GearRT-11509C
Rear Axle Ratio: 4.42
Cab length: 11.29m
Cab width: 2.5m
Cab height: 3.58m
Front track width: 2020/2020mm
rear track: 1830/1830mm
Curb Weight: 13.6ton
Rated payload: 17.1ton
GVWR: 30.9ton
Max. speed: 75km/h
Origin: Changchun
tonnage class: Heavy-duty cargo trucks
market segment: Agricultural product transport, LTL transport, green channel, industrial product transport
Remarks: Engine net power: CA6DL1-32E3 228kW, CA6DL2-35E3 258kW; VIN mapping: LFNFVXNX → CA6DL1-32E3, LFNFVXPX → CA6DL2-35E3; optional flat-top cab and new high-top cab. Front/rear overhang (mm): 1418/2222,1418/2922,1418/2522. Overall dimensions L×W×H (mm): 11990,11290 ×2490 ×3980,3780,3580. Cargo box internal dimensions L×W×H (mm): 8800,9500 ×2300 ×800,600. 6500/6500/17900 (tandem axle), 6580/6580/17740 (tandem axle)
Energy Type: Diesel
Engine parameters
Engine Brand: Xichai
Engine Model: XichaiCA6DL2-35E3
Engine info: Xichai9L
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 8.6L
Emission standard: China III / Euro III
Max output power: 258kW
Max hp: 350Horsepower
Max torque: 1500N·m
Max torque speed: 1200-1500rpm
Rated speed: 2100rpm
Engine Type: Inline, electronic, common rail, turbocharged, air-to-air intercooled
Transmission Parameters
Transmission Model: Fast GearRT-11509C
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 9Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: Stake type
Cargo box length: 9.5m
Cargo box width: 2.3m
Cargo box height: 0.6m
*Cargo box interior width: 2.2999999523163
Cab parameters
Cab: High roof
seating capacity: 3Personnel
Seat rows: Sleeper cab
fuel tank
Fuel tank material: aluminum alloy
Fuel tank capacity: 400L
Chassis Specs
Front axle description: Axle 1950 front axle
Front axle allowable load: 6500kg
rear axle description: Axle Ф290 wheel reduction axle (domestic ABS)
rear axle allowable load: 17900kg
Axle ratio: 4.42
Leaf spring count: 9/12
Tire
Tire Size: 11.00-20 11.00R20 12.00-20 12.00R20
Number of tires: 12pcs

Photos

0 photos

FAQ

What is the export price of FAW Jiefang Aowei (J5P) heavy truck 350 hp 8X4(12 wheels) stake truck, and what does it include?

FAW Jiefang Aowei (J5P) heavy truck 350 hp 8X4(12 wheels) stake truck export reference is about From $43,056; MSRP is ¥31M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does FAW Jiefang Aowei (J5P) heavy truck 350 hp 8X4(12 wheels) stake truck use, and can it enter my country?

This model is listed as China III / Euro III. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of FAW Jiefang Aowei (J5P) heavy truck 350 hp 8X4(12 wheels) stake truck?

Key specs of FAW Jiefang Aowei (J5P) heavy truck 350 hp 8X4(12 wheels) stake truck: Drive: 8x4; Horsepower: 350 hp; Emission: China III / Euro III; Fuel: Diesel; Engine: Xichai9L; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is FAW Jiefang Aowei (J5P) heavy truck 350 hp 8X4(12 wheels) stake truck suited for?

FAW Jiefang Aowei (J5P) heavy truck 350 hp 8X4(12 wheels) stake truck is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does FAW Jiefang Aowei (J5P) heavy truck 350 hp 8X4(12 wheels) stake truck differ from other variants in the same series?

FAW Jiefang Aowei (J5P) heavy truck 350 hp 8X4(12 wheels) stake truck belongs to FAW Jiefang Aowei J5P Heavy-duty Truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for FAW Jiefang Aowei (J5P) heavy truck 350 hp 8X4(12 wheels) stake truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export FAW Jiefang Aowei (J5P) heavy truck 350 hp 8X4(12 wheels) stake truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
