Sanhuan Shitong Fuxingka 115 hp 4X2(6 wheels) truck-mounted crane

Export reference
From $16,667
MSRP ¥12M CNY
Emission: China IV
Fuel: Diesel
Wheelbase:: 4450mm
Cab dimensions:: 7.99×2.475×3.115m
Type:: truck-mounted crane
GVWR:: 14.575ton
Lifting capacity: 3.2ton
Drive 4X2 (6 wheels)
Horsepower 115
Rated mass: 8.72ton

Overview

The Sanhuan Shitong Fuxingka 115 hp 4X2(6 wheels) truck-mounted crane is a truck-mounted crane featuring 3.2ton tank capacity, 14.575t GVW and 4X2 (6 wheels) drive. On the powertrain side, it comes with 115 hp, China IV emissions and Diesel fuel.

China IV 115 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Cab dimensions: 7.99×2.475×3.115m
Type: truck-mounted crane
Drive type: 4X2
Wheelbase: 4450mm
Rated mass: 8.72ton
GVWR: 14.575ton
Front/rear suspension: 1.17/2.375m
Energy Type: Diesel
Body Parameters
Crane model: SQ3.2S
Lifting capacity: 3.2ton
crane self-weight: 1.35ton
Vehicle certification code: STQ5151JSQN4
Body Brand: Sanhuan Shitong
Engine parameters
Engine Brand: Yuchai
Engine Model: YuchaiYC4FA115-40
fuel type: Diesel
Displacement: 2.982L
Emission standard: China IV
Max output power: 85kW
Max hp: 115Horsepower
Max torque: 300N·m
Max torque speed: 1600-2400rpm
Rated speed: 3200rpm
Chassis Specs
Chassis Brand: Sanhuan Shitong
Chassis Series: Fuxing Truck
Chassis Model: STQ1151L07Y2N4
Leaf spring count: 8/11+8
Transmission Parameters
Number of gears: 8Gear
Transmission Model: 8-speed transmission
Tire
Tire Size: 9.00-20 16PR
Number of tires: 6pcs

Photos

Exterior3

3 photos

FAQ

What is the export price of Sanhuan Shitong Fuxingka 115 hp 4X2(6 wheels) truck-mounted crane, and what does it include?

Sanhuan Shitong Fuxingka 115 hp 4X2(6 wheels) truck-mounted crane export reference is about From $16,667; MSRP is ¥12M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Sanhuan Shitong Fuxingka 115 hp 4X2(6 wheels) truck-mounted crane use, and can it enter my country?

This model is listed as China IV. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Sanhuan Shitong Fuxingka 115 hp 4X2(6 wheels) truck-mounted crane?

Key specs of Sanhuan Shitong Fuxingka 115 hp 4X2(6 wheels) truck-mounted crane: Drive: 4x2; Horsepower: 115 hp; Emission: China IV; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Sanhuan Shitong Fuxingka 115 hp 4X2(6 wheels) truck-mounted crane suited for?

Sanhuan Shitong Fuxingka 115 hp 4X2(6 wheels) truck-mounted crane is a truck-mounted crane model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does Sanhuan Shitong Fuxingka 115 hp 4X2(6 wheels) truck-mounted crane differ from other variants in the same series?

Sanhuan Shitong Fuxingka 115 hp 4X2(6 wheels) truck-mounted crane belongs to Sanhuan Shitong Fuxingka Light Truck (truck-mounted crane). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Sanhuan Shitong Fuxingka 115 hp 4X2(6 wheels) truck-mounted crane?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Sanhuan Shitong Fuxingka 115 hp 4X2(6 wheels) truck-mounted crane?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
