Hualing Heavy-duty Truck 31T 8X4(12 wheels) 5.6m Pure Electric Dump Truck 422.87kWh

Export reference
MSRP N/A
Rated payload:: 15.305ton
Wheelbase:: 1850+3200+1350mm
Cargo box type:: Dump type
Model code (announced):: HN3311B36C2BEV
Cab length:: 9.52m
GVWR:: 31ton
Drive 8X4 (12 wheels)
CLTC range: 310km
Motor 1 Brand: Boxi
Curb Weight: 15.5ton

Overview

The Hualing Heavy-duty Truck 31T 8X4(12 wheels) 5.6m Pure Electric Dump Truck 422.87kWh is a Heavy truck featuring 310km battery/range, Boxi motor, 8X4 (12 wheels) drive and 15.305t payload.

8X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): HN3311B36C2BEV
Drive type: 8X4
Wheelbase: 1850+3200+1350mm
Cab length: 9.52m
Cab width: 2.55m
Cab height: 3.25m
CLTC range: 310km
Curb Weight: 15.5ton
Rated payload: 15.305ton
GVWR: 31ton
Max. speed: 85km/h
Origin: Ma'anshan, Anhui
tonnage class: Heavy truck
Energy Type: Electric
electric motor
Motor 1 Brand: Boxi
Motor 1 Model: TZ368XS-BXM002
Motor Type: Permanent magnet synchronous motor
total rated power: 360kW
Peak power: 360kW
total peak torque: 2800N·m
Battery/Charging
Battery Brand: CATL
Battery type: Lithium Iron Phosphate Battery
Battery capacity: 422.87kWh
Energy Density: 160.26
Cargo box parameters
Cargo box type: Dump type
Cargo box length: 5.6m
Cargo box width: 2.3m
Cargo box height: 0.9m
Cab parameters
seating capacity: 3Personnel
Seat rows: Single Row
Chassis Specs
Front axle allowable load: 6500/6500kg
rear axle allowable load: 18000 (tandem axle group)kg
Tire
Tire Size: 11.00R20 18PR,12.00R20 18PR,12R22.5 18PR
Number of tires: 12pcs
Control configuration
ABS:

Photos

Exterior1

1 photos

FAQ

What are the key specs of Hualing Heavy-duty Truck 31T 8X4(12 wheels) 5.6m Pure Electric Dump Truck 422.87kWh?

Key specs of Hualing Heavy-duty Truck 31T 8X4(12 wheels) 5.6m Pure Electric Dump Truck 422.87kWh: Drive: 8x4. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Hualing Heavy-duty Truck 31T 8X4(12 wheels) 5.6m Pure Electric Dump Truck 422.87kWh suited for?

Hualing Heavy-duty Truck 31T 8X4(12 wheels) 5.6m Pure Electric Dump Truck 422.87kWh is a electric dump truck model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does Hualing Heavy-duty Truck 31T 8X4(12 wheels) 5.6m Pure Electric Dump Truck 422.87kWh differ from other variants in the same series?

Hualing Heavy-duty Truck 31T 8X4(12 wheels) 5.6m Pure Electric Dump Truck 422.87kWh belongs to Hualing M5 Heavy Truck (electric dump truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Hualing Heavy-duty Truck 31T 8X4(12 wheels) 5.6m Pure Electric Dump Truck 422.87kWh?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Hualing Heavy-duty Truck 31T 8X4(12 wheels) 5.6m Pure Electric Dump Truck 422.87kWh?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
