Hualing M5 31T 8X4(12 wheels) 5.6m electric dump truck 422kWh
EXW
Export quote
Hualing M5 Heavy Truck electric dump truck
Main model photos
436 photos
Models
On sale
Hualing M5 31T 8X4(12 wheels) Battery Swap Edition 6.2m electric dump truck 282kWh
EXW
Export quote
Hualing M5 31T 8X4(12 wheels) Battery Swap 7.6m Electric Dump Truck 282kWh
EXW
Export quote
Hualing M5 31T 8X4(12 wheels) Battery Swap Edition 5.6m Electric Dump Truck 282kWh
EXW
Export quote
Hualing Heavy Truck 31T 8X4(12 wheels) Battery Swap 5.6m Electric Dump Truck 281.92kWh
EXW
Export quote
Inventory
Hualing M5 31T 8X4(12 wheels) 5.6m Electric Dump Truck 350kWh
EXW
Export quote
Hualing Heavy-duty Truck 31T 8X4(12 wheels) 5.6m Pure Electric Dump Truck 422.87kWh
EXW
Export quote
Hualing Heavy Truck 31T 8X4(12 wheels) 5.6m Electric Dump Truck 374.65kWh
EXW
Export quote
Hualing Heavy Truck 31T 8X4(12 wheels) 5.8m Pure Electric Dump Truck 374.65kWh
EXW
Export quote
Hualing Heavy Truck 31T 8X4(12 wheels) 6m Electric Dump Truck 374.65kWh
EXW
Export quote
Series Specs
Basic Info
Model code (announced): HN3312B36C2BEV / HN3311B36C7BEV / HN3310B36C5BEV / HN3310B36D8BEV / HN3310B36C1BEV / HN3311B36C2BEV / HN3310B36C7BEV
Drive type: 8X4
Wheelbase: 1850+3200+1350 / 1850+4800+1350 / 1850+3700+1350mm
Cab length: 9.52 / 10 / 9.67 / 11.5 / 9.62 / 10.4 / 10.1 / 9.42 / 10.02 / 9.92m
Cab width: 2.55m
Cab height: 3.36 / 3.45 / 3.8 / 3.7 / 3.25 / 3.6m
CLTC range: 282 / 190 / 310 / 305km
Curb Weight: 17.9 / 21.2 / 19.6 / 24.5 / 18.5 / 15.5ton
Rated payload: 12.97 / 9.67 / 11.27 / 6.37 / 12.37 / 15.305 / 15.37ton
GVWR: 31ton
Max. speed: 85 / 89km/h
Origin: Ma'anshan, Anhui
tonnage class: Heavy truck
Energy Type: Electric
electric motor
Motor 1 Brand: Tebest / Boxi
Motor 1 Model: TZ400XSTPG06 / TZ400XSTPG04 / TZ368XS-BXM002
Motor Type: Permanent magnet synchronous motor
total rated power: 215 / 250 / 220 / 260 / 360kW
Peak power: 360kW
total peak torque: 2800 / 2100N·m
total rated torque: 1207 / 1600 / 1500N·m
Electronic Control
ECU Brand: Hualing brand
Battery/Charging
Charging method: Dual-gun DC charging / Battery swap
Battery Brand: CATL
Battery type: Lithium Iron Phosphate Battery
Battery capacity: 422.87 / 281.92 / 350.08 / 374.65kWh
fast charge time: 2 / 1 / 1.5h
Energy Density: 157.57 / 160.26 / 136
Battery Model: L228H01
Transmission Parameters
Number of gears: 9Gear
shift type: AMT manual/auto
Transmission Model: 9-Speed AMT
Cargo box parameters
Cargo box type: Dump type
Cargo box length: 5.6 / 6.2 / 7.6 / 6.5 / 6 / 5.8m
Cargo box width: 2.3 / 2.35m
Cargo box height: 0.9 / 1.2 / 1.5 / 0.6m
Cab parameters
seating capacity: 2 / 3Personnel
Seat rows: Single Row
Chassis Specs
Front axle allowable load: 6500/6500 / 6500/6500kg
rear axle description: Dual 16T grade
FAQ
What kind of truck is Hualing Hualing M5 Heavy Truck electric dump truck?
Hualing Hualing M5 Heavy Truck is an export-oriented electric dump truck lineup with about 16 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Hualing M5 Heavy Truck electric dump truck cover?
Hualing M5 Heavy Truck electric dump truck mainly covers: Drive: 8x4. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Hualing M5 Heavy Truck electric dump truck?
For Hualing M5 Heavy Truck electric dump truck: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is electric dump truck typically used for?
electric dump truck is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Hualing M5 Heavy Truck electric dump truck include?
Hualing M5 Heavy Truck electric dump truck currently lists about 16 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Hualing M5 Heavy Truck electric dump truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
