FAW Jiefang Lingtu 4X2(6 wheels) 3.7m single-row pure electric dump truck CATL 98.04kWh
EXW
From $34,361
Export quote
FAW Jiefang Lingtu Light-duty Truck electric dump
Main model photos
838 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Jiefang Lingtu 4X2(6 wheels) 3.7m single-row pure electric dump truck CATL 98.04kWh | 4x2 | From $34,361 | |
| FAW Jiefang Lingtu 4X2(6 wheels) 3.6m single-row pure electric dump truck CATL 98.04kWh | 4x2 | From $34,361 | |
| FAW Jiefang Lingtu 4X2(6 wheels) 3.5m Single Row Pure Electric Dump Truck CATL 98.04kWh | 4x2 | From $34,361 | |
| FAW Jiefang Lingtu 4X2(6 wheels) 3.8m single-row pure electric dump truck CATL 98.04kWh | 4x2 | From $37,222 | |
| FAW Jiefang Lingtu 4X2(6 wheels) 3.7m single-row pure electric dump truck CATL 98.04kWh | 4x2 | From $37,222 |
FAW Jiefang Lingtu 4X2(6 wheels) 3.6m single-row pure electric dump truck CATL 98.04kWh
EXW
From $34,361
Export quote
FAW Jiefang Lingtu 4X2(6 wheels) 3.5m Single Row Pure Electric Dump Truck CATL 98.04kWh
EXW
From $34,361
Export quote
FAW Jiefang Lingtu 4X2(6 wheels) 3.8m single-row pure electric dump truck CATL 98.04kWh
EXW
From $37,222
Export quote
FAW Jiefang Lingtu 4X2(6 wheels) 3.7m single-row pure electric dump truck CATL 98.04kWh
EXW
From $37,222
Export quote
Series Specs
Basic Info
Model code (announced): CA3140P40L2BEVA84 / CA3090P40L1BEVA84 / CA3160P40L2BEVA84
Drive type: 4X2
Wheelbase: 3300mm
Cab length: 5.915 / 5.815 / 5.765 / 5.9 / 5.84 / 5.69 / 5.995 / 5.975 / 5.74m
Cab width: 2.24 / 2.14m
Cab height: 2.485 / 2.4 / 2.6m
CLTC range: 260 / 160km
Curb Weight: 5.53 / 4.71 / 6.4ton
Rated payload: 8.27 / 3.895 / 9.405ton
GVWR: 13.995 / 9.1 / 16ton
Max. speed: 80km/h
Origin: Qingdao, Shandong / Qingdao
tonnage class: Light Truck / Medium-duty truck
Energy Type: Electric
electric motor
Motor 1 Brand: FAW Jiefang / FAW
Motor 1 Model: CAM365PT51 / CAM370PT52
Motor Type: Permanent magnet synchronous motor
total rated power: 90 / 80kW
Peak power: 171 / 160kW
Motor 1 Peak Power: 171kW
Electronic Control
ECU Brand: FAW vehicle controller
Battery/Charging
Battery Brand: CATL
Battery type: Lithium Iron Phosphate Battery
Battery capacity: 98.04 / 164.86kWh
Transmission Parameters
shift type: AT automatic
Transmission Model: J2S130
Cargo box parameters
Cargo box type: Rear dump / Dump type
Cargo box length: 3.7 / 3.6 / 3.5 / 3.8m
Cargo box width: 2.1 / 2m
Cargo box height: 0.6 / 0.8m
Cab parameters
Cab: FAW Jiefang Lingtu wide-body single-row cab
seating capacity: 3 / 2Personnel
Seat rows: Single Row / Sleeper cab
Chassis Specs
Front axle allowable load: 4860 / 3300 / 5600kg
rear axle description: 385DH rear axle / 325G rear axle
rear axle allowable load: 9135 / 5800 / 10400kg
Tire
Tire Size: 8.25R20 16PR / 7.50R16LT 16PR / 9.00R20 16PR
Number of tires: 6pcs
Control configuration
ABS:
interior configuration
AC control type: Manual
FAQ
What kind of truck is FAW Jiefang FAW Jiefang Lingtu Light-duty Truck electric dump truck?
FAW Jiefang FAW Jiefang Lingtu Light-duty Truck is an export-oriented electric dump truck lineup with about 9 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for FAW Jiefang Lingtu Light-duty Truck electric dump?
FAW Jiefang Lingtu Light-duty Truck electric dump export reference is about $34,361 – $52,500. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does FAW Jiefang Lingtu Light-duty Truck electric dump cover?
FAW Jiefang Lingtu Light-duty Truck electric dump mainly covers: Drive: 4x2. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in FAW Jiefang Lingtu Light-duty Truck electric dump?
For FAW Jiefang Lingtu Light-duty Truck electric dump: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is electric dump truck typically used for?
electric dump truck is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does FAW Jiefang Lingtu Light-duty Truck electric dump include?
FAW Jiefang Lingtu Light-duty Truck electric dump currently lists about 9 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for FAW Jiefang Lingtu Light-duty Truck electric dump?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
