FAW Jiefang Qingdao Han V 260 hp 8X2(10 wheels) fuel tanker truck (Chusheng brand)

Export reference
From $35,444
MSRP ¥25.52M CNY
Curb Weight:: 13.8ton
Emission: China V
Fuel: Diesel
Wheelbase:: 1900+4160+1350mm
Cab dimensions:: 11.2×2.49×3.4m
Truck Type:: Fuel tanker truck
Tank Size: 8.5×2.48×1.8m
Rated payload: 17.07ton
Drive 8X2 (10 wheels)
Horsepower 260

Overview

The FAW Jiefang Qingdao Han V 260 hp 8X2(10 wheels) fuel tanker truck (Chusheng brand) is a fuel tanker truck featuring 8.5×2.48×1.8m tank capacity, 17.07t payload, 25.5m³ volume and 13.8ton GVW. On the powertrain side, it comes with 260 hp, 8X2 (10 wheels) drive, China V emissions and Diesel fuel.

China V 260 Diesel 8X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Cab dimensions: 11.2×2.49×3.4m
Truck Type: Fuel tanker truck
Drive type: 8X2
Wheelbase: 1900+4160+1350mm
Vehicle origin: Suizhou, Hubei
Front track width: 1964/1964mm
rear track: 1960/1847mm
Curb Weight: 13.8ton
Rated payload: 17.07ton
Max. speed: 79km/h
Front/rear suspension: 1.375/2.415m
Energy Type: Diesel
Body Parameters
Tank Size: 8.5×2.48×1.8m
Tank Volume: 25.5m3
Vehicle certification code: CSC5310GYYCAB
Body Brand: Chusheng Brand
Engine parameters
Engine Brand: Xichai
Engine Model: XichaiCA6DL1-26E5
Number of cylinders: 6cylinder
fuel type: Diesel
Displacement: 7.7L
Emission standard: China V
Max output power: 195kW
Max hp: 260Horsepower
Max torque: 1050N·m
Max torque speed: 1300-1600rpm
Chassis Specs
Chassis Brand: FAW Jiefang Qingdao
Chassis Series: HanV
Chassis Model: CA1311P1K2L6T10BE5A80
Frame Dimensions: 280*80*(8+5)mm
rear axle description: 457 stamped-welded axle
Axle ratio: 4.875
Leaf spring count: 12/12/6+-/10+9
clutch: Φ430
Transmission Parameters
Number of gears: 9Gear
Transmission Model: Fast Gear9JS119
Cab parameters
Cab: HanV flat floor flat roof
Tire
Tire Size: 295/80R22.5
Number of tires: 10pcs

Photos

Exterior1

1 photos

FAQ

What is the export price of FAW Jiefang Qingdao Han V 260 hp 8X2(10 wheels) fuel tanker truck (Chusheng brand), and what does it include?

FAW Jiefang Qingdao Han V 260 hp 8X2(10 wheels) fuel tanker truck (Chusheng brand) export reference is about From $35,444; MSRP is ¥25.52M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does FAW Jiefang Qingdao Han V 260 hp 8X2(10 wheels) fuel tanker truck (Chusheng brand) use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of FAW Jiefang Qingdao Han V 260 hp 8X2(10 wheels) fuel tanker truck (Chusheng brand)?

Key specs of FAW Jiefang Qingdao Han V 260 hp 8X2(10 wheels) fuel tanker truck (Chusheng brand): Drive: 8x2; Horsepower: 260 hp; Emission: China V; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is FAW Jiefang Qingdao Han V 260 hp 8X2(10 wheels) fuel tanker truck (Chusheng brand) suited for?

FAW Jiefang Qingdao Han V 260 hp 8X2(10 wheels) fuel tanker truck (Chusheng brand) is a fuel tanker truck model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does FAW Jiefang Qingdao Han V 260 hp 8X2(10 wheels) fuel tanker truck (Chusheng brand) differ from other variants in the same series?

FAW Jiefang Qingdao Han V 260 hp 8X2(10 wheels) fuel tanker truck (Chusheng brand) belongs to Chusheng FAW Jiefang Qingdao chassis (fuel tanker truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for FAW Jiefang Qingdao Han V 260 hp 8X2(10 wheels) fuel tanker truck (Chusheng brand)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export FAW Jiefang Qingdao Han V 260 hp 8X2(10 wheels) fuel tanker truck (Chusheng brand)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
