FAW Jiefang Qingdao Hanwei (J5M) 220 hp 6X4(10 wheels) Liquefied Gas Transport Truck (Chengliwei Brand)
EXW
Export quote
Chengliwei FAW Jiefang Qingdao chassis liquefied
Main model photos
88 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Jiefang Qingdao Hanwei (J5M) 220 hp 6X4(10 wheels) Liquefied Gas Transport Truck (Chengliwei Brand) | 6x4 / 220hp / China III / Euro III | ||
| FAW Jiefang Qingdao Hanwei (J5M) 280 hp 8X4(12 wheels) Liquefied Gas Transport Truck (Chengliwei Brand) | 8x4 / 280hp / China III / Euro III | ||
| FAW Jiefang Qingdao Hanwei (J5M) 260 hp 8X4(12 wheels) Liquefied Gas Transport Truck (Chengliwei Brand) | 8x4 / 260hp / China III / Euro III |
Series Specs
Basic Info
Cab dimensions: 10.2×2.5×3.45 / 11.7×2.49×3.69m
Truck Type: liquefied gas transport truck
Drive type: 6X4 / 8X4
Front/rear track width: Front track: 1914mm; Rear track: 1847mm; Rear track: 1847mm / Front track: 1928/1928; 2020/2020; 1950/1950 Rear track: 1847/1847; 1830/1830; 1847/1847
Wheelbase: 4725+1350 / 1900+4500+1350;2000+4700+1350;1950+4550+1350mm
Front track width: 1914 rear track: 1847mm
rear track: 1847mm
Rated payload: 10.42 / 14.91 / 14.49ton
GVWR: 25 / 31ton
Max. speed: 80km/h
Front/rear suspension: 1.375/2.75 / 1.375/2.575m
Energy Type: Diesel
Body Parameters
Tank Size: 7.534×2.124 / 8.96×2.374 / 8.757×2.374m
Other special notes: Unit volume filling capacity: 0.42 t/m³. Cab optional with chassis. Protection material: Q235 carbon steel, connection: front/rear guards welded, rear guard section (mm): 170×50×5, ground clearance (mm): 530. / Unit volume filling mass: 0.42 t/m³. Cab optional with chassis. Guard material: Q235 carbon steel; connection method: left and right sides and rear lower guard all welded; rear guard section dimensions (mm): 100×50×5; rear guard ground clearance (mm): 540. / Transport medium: unit volume filling capacity 0.42 t/m³; tank straight section length (mm): 6389. Guard material: Q235 carbon steel, connection: left/right sides and rear lower guard welded, rear guard section dimensions (mm): 100×50×5, rear guard ground clearance (mm): 540.
Tank Straight Section Length: 6.38 / 6.389m
Tank Volume: 24.81 / 35.5 / 34.5m3
Transport medium: liquefied petroleum gas (propane)
Vehicle certification code: CLW5250GYQ / CLW5311GYQ / CLW5311GYQC
Body Brand: Chengliwei
Engine parameters
Engine Brand: Dachai
Engine Model: Dachai CA6DE3-22E3 / Dachai BF6M1013-28E3 / Dachai BF6M1013-26E3
Number of cylinders: 6cylinder
Displacement: 6.618 / 7.146L
Emission standard: China III / Euro III
Max output power: 162 / 216 / 203kW
Max hp: 220 / 280 / 260Horsepower
Max torque: 770 / 1050 / 950N·m
Max torque speed: 1400 / 1100-1400rpm
Rated speed: 2300rpm
Chassis Specs
Chassis Brand: FAW Jiefang Qingdao
Chassis Series: Hanwei J5M
Chassis Model: CA1253P7K2L7T1E / CA1313P7K1L11T4E
Leaf spring count: 4/10,11/11 / 12/12/10,9/9/12
Transmission Parameters
Number of gears: 6 / 9Gear
Transmission Model: FAW CA6T138 / Fast Gear 9JS119
Tire
Tire Size: 9.00R20,9.00-20,10.00R20,10.00-20 / 10.00-20,10.00R20,11.00-20,11.00R20
Number of tires: 10 / 12pcs
FAQ
What kind of truck is Chengliwei Chengliwei FAW Jiefang Qingdao chassis liquefied gas transport truck?
Chengliwei Chengliwei FAW Jiefang Qingdao chassis is an export-oriented liquefied gas transport truck lineup with about 3 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Chengliwei FAW Jiefang Qingdao chassis liquefied cover?
Chengliwei FAW Jiefang Qingdao chassis liquefied mainly covers: Drive: 6x4 / 8x4; Horsepower: 220 hp / 260 hp / 280 hp; Emission: China III / Euro III; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Chengliwei FAW Jiefang Qingdao chassis liquefied?
For Chengliwei FAW Jiefang Qingdao chassis liquefied: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is liquefied gas transport truck typically used for?
liquefied gas transport truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Chengliwei FAW Jiefang Qingdao chassis liquefied include?
Chengliwei FAW Jiefang Qingdao chassis liquefied currently lists about 3 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Chengliwei FAW Jiefang Qingdao chassis liquefied?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
