Quanchai 4A2-88C55 88 hp 2.27L China V Diesel Engine
EXW
Export quote
Quanchai 4A Series engine
Main model photos
9 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Quanchai 4A2-88C55 88 hp 2.27L China V Diesel Engine | 88hp / China V | ||
| Quanchai 4A2-88C53 88 hp 2.16L China V Diesel Engine | 88hp / China V | ||
| Quanchai 4A2-88C50 88 hp 2.27L China V Diesel Engine | 88hp / China V | ||
| Quanchai 4A2-68C50 68 hp 2.27L China V Diesel Engine | 68hp / China V | ||
| Quanchai 4A2-82C50 82 hp 2.27L China V Diesel Engine | 82hp / China V |
Quanchai 4A2-88C53 88 hp 2.16L China V Diesel Engine
EXW
Export quote
Quanchai 4A2-88C50 88 hp 2.27L China V Diesel Engine
EXW
Export quote
Quanchai 4A2-68C50 68 hp 2.27L China V Diesel Engine
EXW
Export quote
Quanchai 4A2-82C50 82 hp 2.27L China V Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: Quanchai 4A Series
Engine manufacturer: Anhui Quanchai Power Co., Ltd.
Suitable Range: mini cargo truck / Suitable for 2-3T light trucks and light buses / Truck engine
Intake type: Turbocharged Air-to-Air Intercooling / Turbocharged intercooled + EGR / Turbocharged intercooled; naturally aspirated
Min. fuel consumption at full load: 215 / 200 / ≤215 / 220g/kW.h
Engine net weight: 235kg
Engine Dimensions: 816.5×560×655mm
Compression ratio: 17.5:1 / 17.5：1
noise at 1m: 98dB
Bore × Stroke: 85×100 / 85×95 / 80x90mm
Valves per cylinder: 2pcs
Engine Brand: Quanchai
Engine Model: 4A2-88C55 / 4A2-88C53 / 4A2-88C50 / 4A2-68C50 / 4A2-82C50 / 4A1-82C43 / 4A1-62C43 / 4A1-68C43 / 4A1-68C40
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 2.27 / 2.156 / 1.809L
Emission standard: China V / China IV
Max output power: 65 / 50 / 60 / 45kW
Max hp: 88 / 68 / 82 / 62Horsepower
Max torque: 240 / 170 / 220 / 205 / 150N·m
Max torque speed: 1400-2400 / 2000 / 1800rpm
Rated speed: 3200rpm
Engine Type: 4-cylinder, inline, water-cooled, 4-stroke / Inline, vertical, water-cooled, high-pressure common rail, turbocharged intercooled / Longitudinal mounting / Vertical, inline, water-cooled, four-stroke, direct injection / Inline, vertical, water-cooled, four-stroke, turbocharged intercooled, high-pressure common rail
FAQ
What kind of truck is Quanchai Quanchai 4A Series engine?
Quanchai Quanchai 4A Series is an export-oriented engine lineup with about 9 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Quanchai 4A Series engine cover?
Quanchai 4A Series engine mainly covers: Horsepower: 68 hp / 82 hp / 88 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Quanchai 4A Series engine?
For Quanchai 4A Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Quanchai 4A Series engine include?
Quanchai 4A Series engine currently lists about 9 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Quanchai 4A Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
