Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) 6.3m truck-mounted crane truck
EXW
From $24,306
Export quote
Dongfeng New Chenglong M3 Medium Truck
Main model photos
612 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) 6.3m truck-mounted crane truck | 4x2 / 245hp / China VI | From $24,306 | |
| Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) 6.2m truck-mounted crane truck | 4x2 / 245hp / China VI | From $24,306 | |
| Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) 6.1 m truck-mounted crane | 4x2 / 245hp / China VI | From $24,306 | |
| Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) 5.8m Truck Mounted Crane | 4x2 / 245hp / China VI | From $24,306 | |
| Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) 6.1 m truck-mounted crane | 4x2 / 245hp / China VI | From $24,306 |
Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) 6.2m truck-mounted crane truck
EXW
From $24,306
Export quote
Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) 6.1 m truck-mounted crane
EXW
From $24,306
Export quote
Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) 5.8m Truck Mounted Crane
EXW
From $24,306
Export quote
Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) 6.1 m truck-mounted crane
EXW
From $24,306
Export quote
Series Specs
Basic Info
Cab dimensions: 9×2.55×3.85 / 9×2.55×3.95 / 9×2.55×3.99 / 9×2.55×3.88 / 9×2.55×3.8 / 7.465×2.55×3.68 / 7.465×2.55×3.65 / 9×2.55×3.72m
Type: Truck with crane
Drive type: 4X2
Wheelbase: 5100 / 3950mm
Rated mass: 6.105 / 4.705 / 4.905 / 5.505 / 5.87 / 5.005 / 6.17 / 6.24 / 5.805 / 6.305ton
Front track width: 2046 / 1916mm
rear track: 1860 / 1800mm
GVWR: 18ton
Remarks: Optional M35B cab
Front/rear suspension: 1.445/2.455 / 1.345/2.17m
Energy Type: Diesel
Body Parameters
Crane model: SPS200 / SPS20000
Lifting capacity: 6.8 / 8 / 7.5ton
crane self-weight: 4.1 / 3.7 / 3.5ton
Vehicle certification code: XCL5185JSQ6 / ABL5180JSQCT / ABC5182JSQLZ6 / LZ5185JSQM3AC1 / ABC5180JSQLZ6 / HHH5180JSQLZ6 / XCL5185JSQH / SYP5180JSQLQ6 / ABC5186JSQLZ6 / LZ5185JSQM3AC2
Body Brand: Baolu Suiche Brand / Shenbai Heavy Industry / Chenglong brand / Huihe Brand / SANY Brand
Engine parameters
Engine Brand: Yuchai
Engine Model: YCS07L245-66 / YCS04240-66 / YuchaiYCS06245-60A / YuchaiYCS04200-68
Displacement: 6.442 / 4.295 / 6.23 / 4.16L
Emission standard: China VI
Max output power: 180 / 173 / 147kW
Max hp: 245 / 240 / 200Horsepower
Max torque: 950N·m
Max torque speed: 1200-1700rpm
Rated speed: 2300rpm
Chassis Specs
Chassis Brand: DongfengLiuqi / Dongfeng
Chassis Series: New Chenglong M3 / Chenglong New M3
Chassis Model: LZ1186M3ACT / LZ1180H5ACT
Frame Dimensions: 282(8+4) partial triple-layer (with small connecting plate) / 282 (8+4) partial triple-layer / 231(6)mm
Steering gear: Domestic
rear axle description: 153 / 8T
Axle ratio: 4.875
Leaf spring count: 11/12+9 / 8/9+5
Transmission Parameters
Number of gears: 8Gear
Transmission Model: 8JS95E-C / 8JS85E-C / Fast Gear8JS75E-C / Fast Gear8JS95E-C
Cargo box parameters
Cargo box length: 6.3 / 6.2 / 6.1 / 5.8 / 6.05 / 6 / 5.9 / 6.15 / 5.7 / 5.5 / 5.35 / 5.6 / 4.6m
Cargo box width: 2.45 / 2.4m
Cargo box height: 0.6 / 0.55m
Cab parameters
Cab: M31B / M35B
fuel tank
Fuel tank capacity: 200 / 160L
FAQ
What kind of truck is Dongfeng Dongfeng New Chenglong M3 Medium Truck truck-mounted crane?
Dongfeng Dongfeng New Chenglong M3 Medium Truck is an export-oriented truck-mounted crane lineup with about 64 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Dongfeng New Chenglong M3 Medium Truck?
Dongfeng New Chenglong M3 Medium Truck export reference is about $20,833 – $61,917. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Dongfeng New Chenglong M3 Medium Truck cover?
Dongfeng New Chenglong M3 Medium Truck mainly covers: Drive: 4x2; Horsepower: 245 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dongfeng New Chenglong M3 Medium Truck?
For Dongfeng New Chenglong M3 Medium Truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is truck-mounted crane typically used for?
truck-mounted crane specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Dongfeng New Chenglong M3 Medium Truck include?
Dongfeng New Chenglong M3 Medium Truck currently lists about 64 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng New Chenglong M3 Medium Truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
