Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) Green Sprinkler Truck
EXW
From $23,472
Export quote
Dongfeng New Chenglong M3 Medium Truck water
Main model photos
612 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) Green Sprinkler Truck | 4x2 / 245hp | From $23,472 | |
| Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) Green Sprinkler Truck | 4x2 / 245hp | From $23,333 | |
| Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) Green Sprinkler Truck | 4x2 / 245hp | From $23,472 | |
| Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) Green Sprinkler Truck | 4x2 / 245hp | From $23,333 | |
| Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) Green Sprinkler Truck | 4x2 / 245hp | From $23,472 |
Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) Green Sprinkler Truck
EXW
From $23,333
Export quote
Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) Green Sprinkler Truck
EXW
From $23,472
Export quote
Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) Green Sprinkler Truck
EXW
From $23,333
Export quote
Dongfeng Liuqi New Chenglong M3 245 hp 4X2(6 wheels) Green Sprinkler Truck
EXW
From $23,472
Export quote
Series Specs
Basic Info
Cab dimensions: 8.285×2.54×3.3 / 8.71×2.54×3.3 / 8.39×2.55×3.34 / 8.83×2.5×3.4 / 9.345×2.55×3.4 / 7.25×2.49×2.96 / 8.96×2.5×3.06 / 7.98×2.47×3.155 / 7.83×2.5×3.1 / 7.81×2.55×3.06 / 8.83×2.55×3.28 / 8.36×2.55×3.39 / 8.05×2.55×3.05 / 8.65×2.49×2.96 / 7.89×2.486×3.19m
Truck Type: landscaping sprinkler truck / Water Sprinkler Truck / Electric Water Sprinkler Truck / Water Sprinkler Truck / Green Spray Truck
Drive type: 4X2
Wheelbase: 4500 / 5100 / 3950 / 4200mm
Vehicle origin: Suizhou, Hubei / Nanning / Liuzhou / Gui'an New District, Guizhou / Changsha, Hunan / Tianmen Economic Development Zone, Hubei
Front track width: 2046 / 1940 / 1930 / 2020 / 1916mm
rear track: 1860 / 1800mm
Curb Weight: 6.35 / 7.08 / 7.3 / 7.66 / 5.1 / 8 / 6.66 / 6.28 / 6.15 / 6.8 / 5.94 / 7.75 / 6.24ton
Rated payload: 11.455 / 10.725 / 10.505 / 10.145 / 9.87 / 9.145 / 9.55 / 9.655 / 11.005 / 9.865 / 10.055 / 9.565ton
Max. speed: 89km/h
Front/rear suspension: 1.345/2.44 / 1.345/2.865 / 1.345/2.495 / 1.345/2.385 / 1.345/1.955 / 1.445/2.515 / 1.345/2.36 / 1.345/2.285 / 1.345/2.215 / 1.345/2.565 / 1.345/2.255 / 1.445/2.095 / 1.345/2.715m
Energy Type: Diesel / Electric
Engine parameters
Injection System: Common Rail
Engine Model: YCS06245-60 / YCS06230-61 / B6.2NS6B230 / YuchaiYCY30170-60 / YuchaiYCS04200-68
Number of cylinders: 6 / 4cylinder
Displacement: 6.23 / 6.234 / 6.2 / 2.97 / 4.16L
Emission standard: China VI
Max output power: 180 / 169 / 125 / 147kW
Max hp: 245 / 230 / 170 / 200Horsepower
Rated speed: 2300rpm
Engine Type: High-pressure common rail + EGR + DOC + DPF + SCR + ASC
Body Parameters
Tank Dimensions (L×W×H): 4×2.4×1.42 / 4.45×2.36×1.4 / 4×2.4×1.5 / 5×2.4×1.6 / 4×2.45×1.7 / 4.2×2.35×1.45m
Vehicle certification code: KLF5180GPSL6 / NZ5180GPSLZ / KLF5181GPSL6 / KLF5182GPS6D / GK5180GSSBEV / LZL5180GSSBEV / ZBH5160GPSLZE6B / DXA5160GPSL6 / KLF5161GPSL6 / 10.00R20 18PR / KLF5160GPSL6
Body Brand: Kailifeng / Yuchai Special Vehicle Brand / Chenglong brand / Guizhou (brand) / Yanlong brand / Zhongbiao Brand / XCMG brand
Others: Total tank capacity 12.65 m³ / Total tank capacity: 12.22 m³ / Total tank capacity: 11.6 m³ / Effective tank volume: 9.8 m³
Cargo box parameters
Box volume: 10.01 / 10.2 / 10.16 / 11.05 / 11.58 / 10.89m³
Chassis Specs
Chassis Brand: DongfengLiuqi / Dongfeng
Chassis Series: New Chenglong M3
Chassis Model: LZ1186M3ACT / LZ1186M3AZBEV10 / LZ5180XXYM3AZBEV12T / LZ1166M3ACT
Front axle description: 5.5T / 4.2T / 5T / 3.6T
Frame Dimensions: 264(6+4) / 231(6)mm
Steering gear: Domestic
rear axle description: 153 / 9T / 8T / 10T / 8T rear axle
Axle ratio: 5.571 / 4.875 / 6.333 / 5.833
Leaf spring count: 11/12+9 / 8/9+5 / 8/7+6 / 7/7+6
Transmission Parameters
Number of gears: 8 / 2 / 6Gear
Transmission Model: 8JS85E-C / 8JS95TE-C / 2E110-B / 6.0E+95 / WLYWLY6TS55 / Fast Gear8JS75E-C
Cab parameters
Cab: M31B / M3
Tire
Tire Size: 10.00R20 / 275/80R22.5 / 10.00R20 18PR / 295/80R22.5 / 9.00R20 16PR
Number of tires: 6pcs
FAQ
What kind of truck is Dongfeng Dongfeng New Chenglong M3 Medium Truck water sprinkler truck?
Dongfeng Dongfeng New Chenglong M3 Medium Truck is an export-oriented water sprinkler truck lineup with about 31 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Dongfeng New Chenglong M3 Medium Truck water?
Dongfeng New Chenglong M3 Medium Truck water export reference is about $19,444 – $49,306. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Dongfeng New Chenglong M3 Medium Truck water cover?
Dongfeng New Chenglong M3 Medium Truck water mainly covers: Drive: 4x2; Horsepower: 245 hp; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dongfeng New Chenglong M3 Medium Truck water?
For Dongfeng New Chenglong M3 Medium Truck water: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is water sprinkler truck typically used for?
water sprinkler truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Dongfeng New Chenglong M3 Medium Truck water include?
Dongfeng New Chenglong M3 Medium Truck water currently lists about 31 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng New Chenglong M3 Medium Truck water?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
