SHACMAN Commercial Vehicle Xuande Wing 9 Standard Edition 160hp 4X2(6 wheels) 4.06m refrigerated truck
EXW
From $21,611
Export quote
SHACMAN Commercial Vehicle Xuande Yi 9 Light Truck
Main model photos
224 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SHACMAN Commercial Vehicle Xuande Wing 9 Standard Edition 160hp 4X2(6 wheels) 4.06m refrigerated truck | 4x2 / 160hp / China VI | From $21,611 | |
| SHACMAN Commercial Vehicle Xuande Wing 9 Standard Edition 150hp 4X2(6 wheels) 4.06m refrigerated truck | 4x2 / 150hp / China VI | From $21,153 | |
| SHACMAN Commercial Vehicle Xuande Wing 9 Standard Load Edition 160 hp 4X2(6 wheels) 4.06m AMT automatic refrigerated truck | 4x2 / 160hp / China VI | From $25,000 | |
| SHACMAN Commercial Vehicle Xuande Yi9 Standard Load Version 160 hp 4X2(6 wheels) 4.06m Refrigerated Truck | 4x2 / 160hp / China VI | From $25,000 | |
| SHACMAN Commercial Vehicle Xuande Yi 9 Standard Load 150 hp 4X2(6 wheels) 4.06m refrigerated truck | 4x2 / 150hp / China VI | From $21,069 |
SHACMAN Commercial Vehicle Xuande Wing 9 Standard Edition 150hp 4X2(6 wheels) 4.06m refrigerated truck
EXW
From $21,153
Export quote
SHACMAN Commercial Vehicle Xuande Wing 9 Standard Load Edition 160 hp 4X2(6 wheels) 4.06m AMT automatic refrigerated truck
EXW
From $25,000
Export quote
SHACMAN Commercial Vehicle Xuande Yi9 Standard Load Version 160 hp 4X2(6 wheels) 4.06m Refrigerated Truck
EXW
From $25,000
Export quote
SHACMAN Commercial Vehicle Xuande Yi 9 Standard Load 150 hp 4X2(6 wheels) 4.06m refrigerated truck
EXW
From $21,069
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SHACMAN Commercial Vehicle Xuande Yi 9 143 hp 4X2(6 wheels) 4.15 m refrigerated truck | 4x2 / 143hp / China V | From $23,333 |
SHACMAN Commercial Vehicle Xuande Yi 9 143 hp 4X2(6 wheels) 4.15 m refrigerated truck
EXW
From $23,333
Export quote
Series Specs
Basic Info
Cab dimensions: 5.995×2.2×3.21 / 5.995×2.34×3.26 / 5.99×2.3×3.36 / 5.995×2.3×3.36 / 5.995×2.24×3.21 / 5.995×2.34×3.21m
Truck Type: Refrigerated Truck
Drive type: 4X2
Wheelbase: 3300mm
Vehicle origin: Xi'an, Shaanxi / Baoji, Shaanxi
Front track width: 1730 / 1800 / 1680mm
rear track: 1635 / 1555 / 1800mm
Curb Weight: 3.2ton
Rated payload: 1.165 / 1.1ton
GVWR: 4.495ton
Max. speed: 105km/h
Remarks: Standard reinforced rim. / Optional: Cab: Wing 9 Single Row / 1995 Comfort Edition; Non-illuminated badge; LED front combination lamps; Dedicated top deflector; Tianxingjian Zhiya BD on-board terminal; Integrated electric-adjust & heated rearview mirrors; Rod-style rearview mirrors; Rod-style electric-adjust & heated rearview mirrors. Chassis: Air horn; Aluminum rear guard.
Front/rear suspension: 1.2/1.495m
Energy Type: Diesel
Engine parameters
Injection System: Common Rail
Engine Model: FotonF2.5NS6B160 / Yunnei PowerD25TCIF1 / FotonF2.8NS6B156 / Yunnei PowerD25TCIE10
Number of cylinders: 4cylinder
Displacement: 2.498 / 2.5 / 2.78L
Emission standard: China VI / China V
Max output power: 115 / 110 / 105kW
Max hp: 160 / 150 / 156 / 143Horsepower
Max torque: 400 / 440N·m
Rated speed: 3000 / 2900rpm
Engine Type: Electronic control common rail system HEGR + DOC + DPF + SCR + ASC
Cargo box parameters
Cargo box dimensions: 4.06×2.1×2.1 / 4.12×2.1×2.1 / 4.15×2.1×2.1 / 4.15×2.2×2.2m
Cargo box width: 2.1 / 2.2m
Body Parameters
Vehicle certification code: SX5040XLCNP6331 / SX5040XLCNP5331
Body Brand: SHACMAN Commercial Vehicle
Chassis Specs
Chassis Brand: SHACMAN Commercial Vehicle
Chassis Series: Xuande Yi9 / 192-132/5 single layer / Xuande X9
Chassis Model: SX1040NP6331 / SX1040NP5331
Front axle description: HDZ2.2t / HDZ02/2.2T
Frame Dimensions: 192-132/5 single layermm
rear axle description: Hande single-reduction axle / HDZ260/3.5T / 3.5T
Axle ratio: 4.33
Leaf spring count: 9/7+7 / 6/6+5 / 3/3+2,6/6+5 / 3/3+2,3/3+3 / 3/3+2 / 2/2+1
Transmission Parameters
Number of gears: 6Gear
Transmission Model: Fast GearC6J45T / Fast GearC6J40T-B / Fast GearF6JZ45AM / 6-speed transmission / Fast Gear 6-speed
Cab parameters
Cab: Yi9 single-row
fuel tank
Fuel tank capacity: 120L
FAQ
What kind of truck is SHACMAN Commercial Vehicle SHACMAN Commercial Vehicle Xuande Yi 9 Light Truck Refrigerated Truck?
SHACMAN Commercial Vehicle SHACMAN Commercial Vehicle Xuande Yi 9 Light Truck is an export-oriented Refrigerated Truck lineup with about 12 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for SHACMAN Commercial Vehicle Xuande Yi 9 Light Truck?
SHACMAN Commercial Vehicle Xuande Yi 9 Light Truck export reference is about $16,542 – $31,667. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does SHACMAN Commercial Vehicle Xuande Yi 9 Light Truck cover?
SHACMAN Commercial Vehicle Xuande Yi 9 Light Truck mainly covers: Drive: 4x2; Horsepower: 143 hp / 150 hp / 160 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SHACMAN Commercial Vehicle Xuande Yi 9 Light Truck?
For SHACMAN Commercial Vehicle Xuande Yi 9 Light Truck: 1) set emission; 2) match body/wheelbase to cargo type; 3) pick drive and horsepower; 4) compare prices, then open a model to quote.
What is Refrigerated Truck typically used for?
Refrigerated Truck covers box, stake or flatbed cargo work from city delivery to regional haul. Filter by body and payload needs.
How many models does SHACMAN Commercial Vehicle Xuande Yi 9 Light Truck include?
SHACMAN Commercial Vehicle Xuande Yi 9 Light Truck currently lists about 12 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SHACMAN Commercial Vehicle Xuande Yi 9 Light Truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
