SRM Xinyuan T5L EV Urban Edition 3.77m Single Row Pure Electric Box Van Micro Truck CATL 55.7kWh 4X2(6 wheels)
EXW
From $24,000
Export quote
SRM Xinyuan New Energy T5L EV electric cargo truck
Main model photos
127 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SRM Xinyuan T5L EV Urban Edition 3.77m Single Row Pure Electric Box Van Micro Truck CATL 55.7kWh 4X2(6 wheels) | 4x2 | From $24,000 | |
| SRM Xinyuan T5LEV 2025 Model 3.8m Single Row Pure Electric Van Micro Truck CALB 71.1kWh 4X2(6 wheels) | 4x2 | From $26,222 | |
| SRM Xinyuan T5LEV 2025 Model 3.8m Single Row Pure Electric Grating Micro Truck CALB 71.1kWh 4X2(6 wheels) | 4x2 | From $26,083 | |
| SRM Xinyuan T5LEV 2025 Model 3.7m Single Row Pure Electric Grating Micro Truck CALB 71.1kWh 4X2(6 wheels) | 4x2 | From $26,083 | |
| SRM Xinyuan T5LEV 2025 Model 3.8m Single Row Pure Electric Flatbed Micro Truck CALB 71.1kWh 4X2(6 wheels) | 4x2 | From $25,667 |
SRM Xinyuan T5LEV 2025 Model 3.8m Single Row Pure Electric Van Micro Truck CALB 71.1kWh 4X2(6 wheels)
EXW
From $26,222
Export quote
SRM Xinyuan T5LEV 2025 Model 3.8m Single Row Pure Electric Grating Micro Truck CALB 71.1kWh 4X2(6 wheels)
EXW
From $26,083
Export quote
SRM Xinyuan T5LEV 2025 Model 3.7m Single Row Pure Electric Grating Micro Truck CALB 71.1kWh 4X2(6 wheels)
EXW
From $26,083
Export quote
SRM Xinyuan T5LEV 2025 Model 3.8m Single Row Pure Electric Flatbed Micro Truck CALB 71.1kWh 4X2(6 wheels)
EXW
From $25,667
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SRM Xinyuan T5LEV 3.5T 3.8m Single Row Pure Electric Cargo Van with Grid Side Panels 55.7kWh 4X2(6 wheels) | 4x2 | ||
| SRM Xinyuan T5LEV 2024 City Edition 3.5T 3.8m Single Row Pure Electric Cage Cargo Mini Truck 55.7kWh 4X2(6 wheels) | 4x2 | From $24,000 |
Series Specs
Basic Info
Model code (announced): JKC5034XXYD0X2BEV / JKC5034XXYD0X7BEV / JKC5034CCYD0X7BEV / JKC1034D0X7BEV / JKC5034XXYD0X6BEV / JKC5034CCYD0X6BEV / JKC1034D0X6BEV / JKC1034D0X2BEV / JKC5034CCYD0X5BEV / JKC5034CCYD0X1BEV / JKC5034CCYD0X3BEV / JKC1034D0X3BEV / JKC5034CCYD0X4BEV / JKC5034XXYD0X3BEV / JKC1034D0X1BEV / JKC5034XXYD0X1BEV
Type: enclosed cargo truck / stake truck / Cargo Trucks
Drive type: 4X2
Wheelbase: 3800mm
Box length class: 3.8 / 3.7m
Cab length: 5.975 / 5.875m
Cab width: 1.85 / 1680m
Cab height: 2.63 / 2.475 / 2.075 / 2.54 / 2.06 / 2.595m
CLTC range: 280 / 350 / 330 / 340km
Curb Weight: 1.99 / 2.05 / 2.075 / 1.91 / 1.97 / 2.02 / 1.86 / 1.875 / 2.08 / 2.035 / 2.095 / 1.93 / 2.07ton
Rated payload: 1.375 / 1.315 / 1.29 / 1.455 / 1.395 / 1.345 / 1.505 / 1.495 / 1.285 / 1.33 / 1.27 / 1.435 / 1.295 / 1.49ton
GVWR: 3.495ton
Max. speed: 80km/h
Origin: Chongqing Fuling / Chongqing
tonnage class: mini truck
Remarks: Standard: rear fog lamp / Standard reverse radar.
Version: City Version / 2025 Model / 2024 City Edition / Intercity Version / 2024 Intercity Edition
electric motor
Motor 1 Brand: Inovance United / Jingjin / Inovance
Motor 1 Model: TZ210XS102 / TZ180XSA09
Max torque: 230N·m
Motor Type: Permanent magnet synchronous motor
Energy Type: Electric
total rated power: 50 / 42kW
Peak power: 105kW
total peak torque: 300N·m
Battery/Charging
Charging method: Fast Charge / Standard: fast charge; Optional: slow charge / Fast charge, optional slow charge
Battery Brand: CATL / CALB
Battery type: Lithium Iron Phosphate Battery
Battery capacity: 55.7 / 71.1 / 56.7 / 70.47kWh
Battery rated voltage: 309.1 / 347.7V
Energy Density: 156.25 / 144.9 / 146.3 / 157.57
Cargo box parameters
Cargo box volume: 11.5 / 11.3 / 11.2m³
Cargo box type: Van body / Stake type / stake body
Cargo box length: 3.77 / 3.8 / 3.7m
Cargo box width: 1.775 / 1.76m
Cargo box height: 1.7 / 0.37m
Cab parameters
seating capacity: 2Personnel
Seat rows: Single Row
Chassis Specs
Front axle allowable load: 1200kg
rear axle allowable load: 2295kg
FAQ
What kind of truck is SRM SRM Xinyuan New Energy T5L EV electric cargo truck?
SRM SRM Xinyuan New Energy T5L EV is an export-oriented electric cargo truck lineup with about 25 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for SRM Xinyuan New Energy T5L EV electric cargo truck?
SRM Xinyuan New Energy T5L EV electric cargo truck export reference is about $23,444 – $26,361. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does SRM Xinyuan New Energy T5L EV electric cargo truck cover?
SRM Xinyuan New Energy T5L EV electric cargo truck mainly covers: Drive: 4x2. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SRM Xinyuan New Energy T5L EV electric cargo truck?
For SRM Xinyuan New Energy T5L EV electric cargo truck: confirm local charging and registration first, then filter by range/power and payload, and quote with your operating route.
What is electric cargo truck typically used for?
electric cargo truck focuses on lower-emission work where charging is available. Confirm local charging and registration before purchase.
How many models does SRM Xinyuan New Energy T5L EV electric cargo truck include?
SRM Xinyuan New Energy T5L EV electric cargo truck currently lists about 25 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SRM Xinyuan New Energy T5L EV electric cargo truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
