Yuchai YCD4G4S-90 61 hp 2.2L China V Diesel Engine
EXW
Export quote
Yuchai YCD4 Series engine
Main model photos
5 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Yuchai YCD4G4S-90 61 hp 2.2L China V Diesel Engine | 61hp / China V | ||
| Yuchai YCD4G4S-95 82 hp 2.2L China V Diesel Engine | 82hp / China V | ||
| Yuchai YCD4H1L-70 70 hp 2.16L China IV Diesel Engine | 70hp / China IV | ||
| Yuchai YCD4H1L-80 80 hp 2.16L China IV Diesel Engine | 80hp / China IV | ||
| Yuchai YCD4G1G-60 60 hp 2.16L China IV Diesel Engine | 60hp / China IV |
Yuchai YCD4G4S-95 82 hp 2.2L China V Diesel Engine
EXW
Export quote
Yuchai YCD4H1L-70 70 hp 2.16L China IV Diesel Engine
EXW
Export quote
Yuchai YCD4H1L-80 80 hp 2.16L China IV Diesel Engine
EXW
Export quote
Yuchai YCD4G1G-60 60 hp 2.16L China IV Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: YCD4 Series
Engine manufacturer: Guangxi Yuchai Machinery Co., Ltd.
Suitable Range: Light/medium trucks and dump trucks under 3T / light truck, mini truck, dump truck / Light-duty truck, dump truck under 5T / light truck and dump truck under 6T / Medium-light truck & dump truck under 8T / Light truck & dump truck under 8T / medium-light truck and dump truck under 6T / Medium-light truck, dump truck under 5T
Intake type: Turbocharged Air-to-Air Intercooling / Vertical, inline, water-cooled, four-stroke
Min. fuel consumption at full load: ≤215 / 210 / 205 / 206 / 208 / 199 / 195 / 202 / 200 / 215g/kW.h
Engine net weight: 240 / 280 / 250 / 300 / 380 / 260 / 450 / 460 / 420 / 360 / 320kg
Engine Dimensions: 810×569×680 / 830×620×680 / 978×628×845 / 978×628×861 / 978×688×826 / 960×675×876 / 980×680×855 / 948×641×780mm
Bore × Stroke: 85×95 / 93×103 / 90×103 / 95×115 / 89×100 / 100×118 / 102×118 / 102×120 / 105x120 / 105×125 / 108×125 / 98×115mm
Valves per cylinder: 4pcs
Engine Brand: Yuchai
Engine Model: YCD4G4S-90 / YCD4G4S-95 / YCD4H1L-70 / YCD4H1L-80 / YCD4G1G-60 / YCD4G1G-80 / YCD4N1L-95 / YCD4N1L-100 / YCD4NA1L-95 / YCD4NA1L-85 / YCD4K1G-110 / YCD4K2S-110 / YCD4V1G-90 / YCD4M1G-115 / YCD4M1S-115 / YCD4T1G-120 / YCD4T1S-120 / YCD4T1G-130 / YCD4T1S-130 / YCD4F1G-130 / YCD4F1G-115 / YCD4F2S-130 / YCD4F2L-130 / YCD4F2S-115 / YCD4D1G-140 / YCD4D2S-140 / YCD4D2L-140 / YCD4J2S-150 / YCD4J2L-150 / YCD4P2S-170 / YCD4P4S-130 / YuchaiYCD4P4S-140 / YCD4P4S-160 / YuchaiYCD4P4S-170 / YCD4J4S-150 / YCD4D4S-140 / YCD4F4S-130 / YuchaiYCD4F4S-115 / YCD4T4S-120 / YCD4T4S-130 / YCD4M4S-115 / YCD4R4S-115 / YCD4NA4S-90 / YCD4N4S-95 / YCD4N4S-100 / YCD4N4S-110 / YCD4V4S-90 / YCD4V4S-95 / YCD4G4S-60 / YCD4G4S-80
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 2.2 / 2.156 / 2.799 / 2.621 / 3.26 / 2.488 / 3.707 / 3.857 / 3.922 / 4.156 / 4.329 / 4.58 / 3.47L
Emission standard: China V / China IV
Max output power: 45 / 60 / 52 / 70 / 75 / 65 / 80 / 85 / 90 / 95 / 97 / 105 / 110 / 125 / 115kW
Max hp: 61 / 82 / 70 / 80 / 60 / 95 / 100 / 85 / 110 / 90 / 115 / 120 / 130 / 140 / 150 / 170 / 160Horsepower
Max torque: 140 / 210 / 185 / 165 / 240 / 260 / 225 / 285 / 230 / 340 / 360 / 380 / 410 / 465 / 550 / 440 / 480 / 500 / 460 / 430 / 350 / 330 / 310 / 250N·m
Max torque speed: 1600-2240 / 1600-2200 / 1600-2100 / 1400-1800 / 1600-2000 / 1500-1950 / 1700-2325rpm
Rated speed: 3200 / 3100 / 2800 / 2600 / 3000rpm
Engine Type: Vertical, inline, water-cooled, four-stroke
FAQ
What kind of truck is Yuchai Yuchai YCD4 Series engine?
Yuchai Yuchai YCD4 Series is an export-oriented engine lineup with about 56 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Yuchai YCD4 Series engine cover?
Yuchai YCD4 Series engine mainly covers: Horsepower: 60 hp / 61 hp / 70 hp / 80 hp / 82 hp; Emission: China IV / China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Yuchai YCD4 Series engine?
For Yuchai YCD4 Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Yuchai YCD4 Series engine include?
Yuchai YCD4 Series engine currently lists about 56 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Yuchai YCD4 Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
