Hanma CM6D28.410 50 410hp 11.8L China V Diesel Engine
EXW
Export quote
Hanma CM6D28 series engine
Main model photos
14 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Hanma CM6D28.410 50 410hp 11.8L China V Diesel Engine | 410hp / China V | ||
| Hanma CM6D28.430 60 430hp 11.8L China VI Diesel Engine | 430hp / China VI | ||
| Hanma Power CM6D28.400 60 400 hp 11.8L China VI Diesel Engine | 400hp / China VI | ||
| Hanma Power CM6D28.460 60 460 hp 11.8L China VI Diesel Engine | 460hp / China VI | ||
| Hanma CM6D28.460 50 460hp 11.8L China V Diesel Engine | 460hp / China V |
Hanma CM6D28.430 60 430hp 11.8L China VI Diesel Engine
EXW
Export quote
Hanma Power CM6D28.400 60 400 hp 11.8L China VI Diesel Engine
EXW
Export quote
Hanma Power CM6D28.460 60 460 hp 11.8L China VI Diesel Engine
EXW
Export quote
Hanma CM6D28.460 50 460hp 11.8L China V Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: CM6D28 Series
Engine manufacturer: Anhui Hualing Automobile Co., Ltd. / Hualing
Suitable Range: For logistics transport vehicles, engineering transport vehicles, special vehicles, long-distance buses, construction machinery, and generator sets.
Intake type: Turbocharged Air-to-Air Intercooling
Min. fuel consumption at full load: 189g/kW.h
Engine net weight: 1065kg
Engine Dimensions: 1360x812x1138 / 1455.5X840X1212mm
noise at 1m: 96dB
Compression ratio: 17.0:1 / 17:1
Bore × Stroke: 128×153mm
Valves per cylinder: 4pcs
firing order: 1-5-3-6-2-4
Engine Brand: Hanma
Engine Model: CM6D28.410 50 / CM6D28.430 60 / CM6D28.400 60 / CM6D28.460 60 / CM6D28.460 50 / CM6D28.430 50 / CM6D28.380 50 / CM6D28.350 50 / CM6D28.480 50 / CM6D28.480 40 / CM6D28.350 40 / CM6D28.380 40 / CM6D28.410 40 / CM6D28.430 40 / CM6D28.460 40 / CM6D28.480 30 / CM6D28.460 30 / CM6D28.430 30 / CM6D28.410 30 / CM6D28.380 30 / CM6D28.350 30 / CM6D28.320 30
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 11.813 / 11.8 / 11.81L
Emission standard: China V / China VI / China IV / China III / Euro III
Max output power: 302 / 316 / 294 / 338 / 279 / 257 / 353 / 352 / 301 / 235kW
Max hp: 410 / 430 / 400 / 460 / 380 / 350 / 480 / 320Horsepower
Max torque: 1970 / 2055 / 1950 / 2150 / 2200 / 2050 / 1800 / 1600 / 2250 / 2000 / 1980N·m
Max torque speed: 1000-1400 / 1000-1500 / 1100-1450 / 1100-1400 / 1100-1500rpm
Rated speed: 1900rpm
Engine Type: Inline, four-stroke / Inline, high-pressure common rail / Inline
FAQ
What kind of truck is Hanma Hanma CM6D28 series engine?
Hanma Hanma CM6D28 series is an export-oriented engine lineup with about 22 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Hanma CM6D28 series engine cover?
Hanma CM6D28 series engine mainly covers: Horsepower: 400 hp / 410 hp / 430 hp / 460 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Hanma CM6D28 series engine?
For Hanma CM6D28 series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Hanma CM6D28 series engine include?
Hanma CM6D28 series engine currently lists about 22 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Hanma CM6D28 series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
