Yuchai YC4E140-56A 140 hp 4.26L China V Diesel Engine
EXW
Export quote
Yuchai YC4E Series engine
Main model photos
4 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Yuchai YC4E140-56A 140 hp 4.26L China V Diesel Engine | 140hp / China V | ||
| Yuchai YC4E140-56 140 hp 4.26L China V Diesel Engine | 140hp / China V | ||
| Yuchai YC4E160-56 160 hp 4.26L China V Diesel Engine | 160hp / China V | ||
| Yuchai YC4E140-46 140 hp 4.26L China IV Diesel Engine | 140hp / China IV | ||
| Yuchai YC4E160-46 160 hp 4.26L China IV Diesel Engine | 160hp / China IV |
Yuchai YC4E140-56 140 hp 4.26L China V Diesel Engine
EXW
Export quote
Yuchai YC4E160-56 160 hp 4.26L China V Diesel Engine
EXW
Export quote
Yuchai YC4E140-46 140 hp 4.26L China IV Diesel Engine
EXW
Export quote
Yuchai YC4E160-46 160 hp 4.26L China IV Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: YC4E Series
Engine manufacturer: Guangxi Yuchai Machinery Co., Ltd. / Yuchai
Suitable Range: Medium dump truck, cargo truck, 8-ton truck crane / 4×2 medium, light transport truck; 4×2 municipal sanitation truck / light truck / Medium-duty truck, high-end light-duty truck, low-speed vehicle
Intake type: Turbocharged Air-to-Air Intercooling
Min. fuel consumption at full load: 197 / ≤198 / ≤196 / 200g/kW.h
Engine net weight: 430 / 420 / 380kg
noise at 1m: ≤97 / 99dB
Bore × Stroke: 110x112mm
Valves per cylinder: 2 / 4pcs
Engine Brand: Yuchai
Engine Model: YC4E140-56A / YC4E140-56 / YC4E160-56 / YC4E140-46 / YC4E160-46 / YC4E140-45 / YC4E160-45 / YC4E140-41 / YC4E160-41 / YC4E140-42 / YC4E140-40 / YC4E160-42 / YC4E160-33 / YC4E135-33 / YC4E140-33 / YC4E170-31 / YC4E160-31 / YC4E140-31 / YC4E140-32 / YC4E180-20 / YC4E160-20 / YC4E150-20 / YC4E140-20 / YC4E135-21 / YC4E135-20 / YC4E180-30 / YC4E160-30 / YC4E140-30
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 4.26 / 4.257L
Emission standard: China V / China IV / China III / Euro III / China II/Euro II
Max output power: 103 / 118 / 100 / 105 / 125 / 132 / 110kW
Max hp: 140 / 160 / 135 / 170 / 180 / 150Horsepower
Max torque: 450 / 500 / 600 / 430 / 550 / 392 / 590 / 520 / 490 / 630N·m
Max torque speed: 1300-1600 / 1200-1600 / 1700 / 1600 / 1400-1700 / 1400-1800rpm
Rated speed: 2600 / 2800 / 2500rpm
Engine Type: Vertical, inline, water-cooled, four-stroke / Vertical, inline 4-cylinder, water-cooled, 4-stroke, electronic unit pump / Vertical, inline 4-cylinder, water-cooled, 4-stroke, electronic direct injection / Electronic unit pump, EGR + POC + DOC / BOSCH high-pressure common rail SCR / Vertical, inline, water-cooled, four-stroke, direct injection / Vertical, inline, 4-stroke, water-cooled, electronic direct injection
FAQ
What kind of truck is Yuchai Yuchai YC4E Series engine?
Yuchai Yuchai YC4E Series is an export-oriented engine lineup with about 28 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Yuchai YC4E Series engine cover?
Yuchai YC4E Series engine mainly covers: Horsepower: 140 hp / 160 hp; Emission: China IV / China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Yuchai YC4E Series engine?
For Yuchai YC4E Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Yuchai YC4E Series engine include?
Yuchai YC4E Series engine currently lists about 28 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Yuchai YC4E Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
