SDEC SC7H250Q6 250hp 6.5L China VI Diesel Engine
EXW
Export quote
SDEC SC7H Series engine
Main model photos
7 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SDEC SC7H250Q6 250hp 6.5L China VI Diesel Engine | 250hp / China VI | ||
| SDEC SC7H230Q6 230hp 6.5L China VI Diesel Engine | 230hp / China VI | ||
| SDEC SC7H215Q6 215hp 6.5L China VI Diesel Engine | 215hp / China VI | ||
| SDEC SC7H200Q6 200 hp 6.5L China VI Diesel Engine | 200hp / China VI | ||
| SDEC SC7H240Q6 240 hp 6.5L China VI Diesel Engine | 240hp / China VI |
SDEC SC7H230Q6 230hp 6.5L China VI Diesel Engine
EXW
Export quote
SDEC SC7H215Q6 215hp 6.5L China VI Diesel Engine
EXW
Export quote
SDEC SC7H200Q6 200 hp 6.5L China VI Diesel Engine
EXW
Export quote
SDEC SC7H240Q6 240 hp 6.5L China VI Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: SC7H series
Engine manufacturer: SDEC Power / Shanghai Diesel Engine Co., Ltd.
Suitable Range: Medium and heavy trucks, buses, cranes
Intake type: Exhaust turbocharger / Turbocharged Air-to-Air Intercooling
Min. fuel consumption at full load: ≤196 / 188 / 190g/kW.h
Engine net weight: 580 / 480kg
Engine Dimensions: 1059×729×924 / 1059x725x960mm
Compression ratio: 31.7
noise at 1m: 95dB
Bore × Stroke: 105×124mm
Valves per cylinder: 4pcs
Engine Brand: SDEC
Engine Model: SC7H250Q6 / SC7H230Q6 / SC7H215Q6 / SC7H200Q6 / SC7H240Q6 / SC7H270Q6 / SC7H290Q6 / SC7H240Q5 / SC7H280Q6 / SC7H280Q5 / SC7H260Q5 / SC7H245Q5 / SC7H245Q4 / SC7H230Q5 / SC7H230Q4 / SC7H220Q4 / SC7H215Q5 / SC7H215Q4 / SC7H200Q4 / SC7H180Q5 / SC7H180Q4 / SC7H260Q4 / SC7H240 / SC7H220 / SC7H200
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 6.44 / 6.5L
Emission standard: China VI / China V / China IV
Max output power: 184 / 170 / 158 / 147 / 199 / 213 / 177 / 206 / 205 / 192 / 180 / 169 / 162 / 132kW
Max hp: 250 / 230 / 215 / 200 / 240 / 270 / 290 / 280 / 260 / 245 / 220 / 180Horsepower
Max torque: 1000 / 900 / 920 / 1160 / 960 / 820 / 800 / 750 / 660 / 730N·m
Max torque speed: 1200-1700 / 1100-1700 / 1200-2000 / 1400 / 1200-1600 / 1200-1800rpm
Rated speed: 2300 / 2500rpm
Engine Type: Inline 6-cylinder, electronically controlled high-pressure common rail, DOC+DPF+SCR+ASC / Inline, electronic common rail, 4-valve, turbocharged intercooled, water-cooled, rear gear train / Compression ignition, direct injection, inline six-cylinder, water-cooled / Inline, electronic common rail, 4-valve, turbocharged intercooled / Inline, electronic control system
FAQ
What kind of truck is SDEC SDEC SC7H Series engine?
SDEC SDEC SC7H Series is an export-oriented engine lineup with about 25 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does SDEC SC7H Series engine cover?
SDEC SC7H Series engine mainly covers: Horsepower: 200 hp / 215 hp / 230 hp / 240 hp / 250 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SDEC SC7H Series engine?
For SDEC SC7H Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does SDEC SC7H Series engine include?
SDEC SC7H Series engine currently lists about 25 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SDEC SC7H Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
