SDEC SC10E420Q6 420 hp 10.42L China VI diesel engine
EXW
Export quote
SDEC SC10E Series engine
Main model photos
10 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SDEC SC10E420Q6 420 hp 10.42L China VI diesel engine | 420hp / China VI | ||
| SDEC SC10E370Q6 370 hp 10.42 L China VI diesel engine | 370hp / China VI | ||
| SDEC SC10E330Q6 330 hp 10.42 L China VI diesel engine | 330hp / China VI | ||
| SDEC SC10E300Q6 300 hp 10.42 L China VI diesel engine | 300hp / China VI | ||
| SDEC SC10EQ6 420hp 10.42L China VI Diesel Engine | 420hp / China VI |
SDEC SC10E370Q6 370 hp 10.42 L China VI diesel engine
EXW
Export quote
SDEC SC10E330Q6 330 hp 10.42 L China VI diesel engine
EXW
Export quote
SDEC SC10E300Q6 300 hp 10.42 L China VI diesel engine
EXW
Export quote
SDEC SC10EQ6 420hp 10.42L China VI Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: SC10E Series
Engine manufacturer: SDEC Power / Shanghai Diesel Engine Co., Ltd. / SDEC
Suitable Range: heavy-duty truck, bus, crane
Intake type: Turbocharged Air-to-Air Intercooling / Exhaust turbocharger
Min. fuel consumption at full load: 190 / ≤188 / 185 / 188g/kW.h
Engine net weight: 980 / 975kg
Engine Dimensions: 1389x720x1060 / 1389×824×1130 / 1389X824X1155 / 1389X810X1130mm
Compression ratio: 17
noise at 1m: 185 / 97dB
Bore × Stroke: 128×135 / 128x153mm
Valves per cylinder: 4pcs
Engine Brand: SDEC
Engine Model: SC10E420Q6 / SC10E370Q6 / SC10E330Q6 / SC10E300Q6 / SC10EQ6 / SC10E330Q5 / SC10E390Q5 / SC10E400Q6 / SC10E340Q5 / SC10E380Q5 / SC10E360Q5 / SC10E360Q4 / SC10E300Q5 / SC10E320Q5 / SC10E340Q4 / SC10E350Q4 / SC10E380Q4 / SC10E300Q4 / SC10E320Q4 / SC10E420Q3B / SC10E380Q3B / SC10E340Q3B / SC10E310Q3B / SC10E290Q3B / SC10E340Q3 / SC10E400 / SC10E380 / SC10E340 / SC10E310 / SC10E290
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 10.4 / 10.42L
Emission standard: China VI / China V / China IV / China III / Euro III
Max output power: 309 / 272 / 243 / 221 / 287 / 294 / 251 / 279 / 265 / 235 / 258 / 220 / 280 / 250 / 228 / 213kW
Max hp: 420 / 370 / 330 / 300 / 390 / 400 / 340 / 380 / 360 / 320 / 350 / 310 / 290Horsepower
Max torque: 2000 / 1800 / 1600 / 1400 / 1550 / 1900 / 1700 / 1350 / 1500 / 1450 / 1190 / 1950 / 1300N·m
Max torque speed: 1100-1400 / 1100-1500 / 1300 / 1000-1500 / 1400rpm
Rated speed: 1900rpm
Engine Type: Compression ignition, direct injection, inline six-cylinder, water-cooled / Inline 6-cylinder, electronically controlled high-pressure common rail, DOC+DPF+SCR+ASC / 4-valve, Bosch electronic control high-pressure common rail system / Bosch Electronically Controlled High-Pressure Common Rail System, Multi-Injection / EGR+DOC+DPF+SCR+ASC / Inline, 4-valve, electronically controlled common rail, turbocharged, intercooled, water-cooled, rear-mounted gear train / Inline, mechanical pump, internal EGR, turbocharged intercooled, wet liner, rear gear train / Inline, electronic common rail, water-cooled, rear-mounted gear type
FAQ
What kind of truck is SDEC SDEC SC10E Series engine?
SDEC SDEC SC10E Series is an export-oriented engine lineup with about 30 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does SDEC SC10E Series engine cover?
SDEC SC10E Series engine mainly covers: Horsepower: 300 hp / 330 hp / 370 hp / 420 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SDEC SC10E Series engine?
For SDEC SC10E Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does SDEC SC10E Series engine include?
SDEC SC10E Series engine currently lists about 30 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SDEC SC10E Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
