SDEC SC12E440Q6 440 hp 12L China VI Diesel Engine
EXW
Export quote
SDEC SC12E Series engine
Main model photos
7 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SDEC SC12E440Q6 440 hp 12L China VI Diesel Engine | 440hp / China VI | ||
| SDEC SC12E460Q6 460 hp 12L China VI Diesel Engine | 460hp / China VI | ||
| SDEC SC12E450Q6 450 hp 12 L China VI diesel engine | 450hp / China VI | ||
| SDEC SC12E420Q6 420 hp 12L China VI Diesel Engine | 420hp / China VI | ||
| SDEC SC12EQ6 480 hp 12L China VI Diesel Engine | 480hp / China VI |
SDEC SC12E460Q6 460 hp 12L China VI Diesel Engine
EXW
Export quote
SDEC SC12E450Q6 450 hp 12 L China VI diesel engine
EXW
Export quote
SDEC SC12E420Q6 420 hp 12L China VI Diesel Engine
EXW
Export quote
SDEC SC12EQ6 480 hp 12L China VI Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: SC12E Series
Engine manufacturer: SDEC Power / Shanghai Diesel Engine Co., Ltd.
Suitable Range: heavy-duty truck, bus, crane
Intake type: Exhaust turbocharger / Turbocharged Air-to-Air Intercooling
Min. fuel consumption at full load: ≤185 / 190 / 185g/kW.h
Engine net weight: 1070kg
Engine Dimensions: 1389×824×1155 / 1389x800x1095mm
Compression ratio: 17
noise at 1m: 97dB
Bore × Stroke: 128×153mm
Valves per cylinder: 4pcs
Engine Brand: SDEC
Engine Model: SC12E440Q6 / SC12E460Q6 / SC12E450Q6 / SC12E420Q6 / SC12EQ6 / SC12E420Q5 / SC12E350Q5 / SC12E480Q6 / SC12E480Q5 / SC12E390Q5 / SC12E430Q5 / SC12E480Q4 / SC12E460Q5 / SC12E440Q4 / SC12E385Q4 / SC12E350Q4 / SC12E460Q4 / SC12E3480 / SC12E3440 / SC12E3400 / SC12E380 / SC12E390Q4 / SC12E430Q4 / SC12E385
Number of cylinders: 6 / 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 11.81 / 11.8L
Emission standard: China VI / China V / China IV
Max output power: 323 / 338 / 331 / 309 / 353 / 258 / 287 / 316 / 324 / 283 / 294 / 280kW
Max hp: 440 / 460 / 450 / 420 / 480 / 350 / 390 / 430 / 385 / 400 / 380Horsepower
Max torque: 2100 / 2200 / 2000 / 2250 / 1600 / 1900 / 1800 / 1950N·m
Max torque speed: 1100-1400 / 1100-1500 / 1300 / 1200-1500 / 1000-1500rpm
Rated speed: 1900 / 220rpm
Engine Type: EGR+DOC+DPF+SCR+ASC / Inline 6-cylinder, electronically controlled high-pressure common rail, DOC+DPF+SCR+ASC / Inline, 4-valve, electronically controlled common rail, turbocharged, intercooled, water-cooled, rear-mounted gear train
