4KK1N6HD
EXW
Export quote
Qingling Isuzu 4K Series engine
Main model photos
4 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| 4KK1N6HD | 160hp | ||
| 4KB1-TCG60 | 131hp | ||
| Qingling Isuzu 4KH1N6MD 140 hp 3.0L China VI diesel engine | 140hp / China VI | ||
| 4KK1N6SD | 132hp / China VI | ||
| Qingling Isuzu 4KK1N6LB 120 hp 2.5L China VI Diesel Engine | 120hp / China VI |
4KB1-TCG60
EXW
Export quote
Qingling Isuzu 4KH1N6MD 140 hp 3.0L China VI diesel engine
EXW
Export quote
4KK1N6SD
EXW
Export quote
Qingling Isuzu 4KK1N6LB 120 hp 2.5L China VI Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: 4K Series
Engine manufacturer: Isuzu (China) Engine Co., Ltd. / Qingling Isuzu (Chongqing) Engine Co., Ltd. / Qingling
Intake type: Turbocharged Air-to-Air Intercooling / Inline 4-cylinder, turbocharged intercooled
Min. fuel consumption at full load: ≤200g/kW.h
Engine net weight: 255kg
Engine Dimensions: 784×725×605 / 767x589x707mm
Compression ratio: 18.3
Bore × Stroke: Φ95.4×104.9 / 95.4x104.9mm
Valves per cylinder: 4 / 2pcs
firing order: 1-3-4-2
Engine Brand: Qingling Isuzu / Isuzu
Engine Model: 4KK1N6HD / 4KB1-TCG60 / 4KH1N6MD / 4KK1N6SD / 4KK1N6LB / 4KH1CT6H1 / 4KH1CN5LS / 4KH1CT5H1 / 4KH1CN6HB / 4KH1CN6LB / 4KH1CN5HS / 4KH1-TCG51 / 4KH1CN5HD / 4KH1CN5MD / 4KH1-TCG40 / 4KH1-TC
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 2.499 / 2.999L
Emission standard: China VI / China V / China IV / China III / Euro III
Max output power: 118 / 96 / 103 / 97 / 88 / 105 / 72 / 85kW
Max hp: 160 / 131 / 140 / 132 / 120 / 143 / 98 / 130 / 115Horsepower
Max torque: 220 / 280 / 290 / 277N·m
Max torque speed: 1400-2400 / 1700 / 1800 / 1500 / 1500-2900rpm
Rated speed: 3400 / 2900rpm
Engine Type: DENSO 1800bar high-pressure common rail, DOC (diesel oxidation catalyst) / High-pressure common rail, precision electronic control, multi-stage injection, optimized combustion and exhaust gas recirculation, dual-stage fuel
FAQ
What kind of truck is Qingling Isuzu Qingling Isuzu 4K Series engine?
Qingling Isuzu Qingling Isuzu 4K Series is an export-oriented engine lineup with about 16 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Qingling Isuzu 4K Series engine cover?
Qingling Isuzu 4K Series engine mainly covers: Horsepower: 120 hp / 131 hp / 132 hp / 140 hp / 160 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Qingling Isuzu 4K Series engine?
For Qingling Isuzu 4K Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Qingling Isuzu 4K Series engine include?
Qingling Isuzu 4K Series engine currently lists about 16 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Qingling Isuzu 4K Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
