Foton AumanEXT 9 Series 375 hp 6X4(10 wheels) Fire Truck Chassis
EXW
Export quote
Foton Auman ETX Heavy Truck fire truck
Main model photos
853 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Foton AumanEXT 9 Series 375 hp 6X4(10 wheels) Fire Truck Chassis | 6x4 / 375hp / China IV | ||
| Foton AumanETX 9 Series 375 hp 6X4(10 wheels) Fire Truck (Feiyan Brand) | 6x4 / 375hp / China IV | ||
| Foton AumanETX 3 Series 210 hp 4X2(6 wheels) Fire Truck (Feiyan Brand) | 4x2 / 210hp / China IV |
Foton AumanETX 9 Series 375 hp 6X4(10 wheels) Fire Truck (Feiyan Brand)
EXW
Export quote
Foton AumanETX 3 Series 210 hp 4X2(6 wheels) Fire Truck (Feiyan Brand)
EXW
Export quote
Series Specs
Basic Info
Cab dimensions: 9.557X2.495X3.44 / 9.995×2.5×3.6 / 8.315x2.44x3.2m
Type: fire truck
Drive type: 6X4 / 4X2
Wheelbase: 4300+1350 / 4700mm
Front/rear track width: Front track: 2005mm; Rear track: 1865 / Front track: 2005; Rear track: 1865/1865 / Front track: 1960; Rear track: 1847
Rated mass: 14.8 / 5.1ton
GVWR: 32 / 30 / 14.88ton
Front/rear suspension: 1.532/2.375 / 1.532/2.708 / 1.365/2.1m
Energy Type: Diesel
Body Parameters
Tank Medium: water
Liquid Capacity: 14.8ton
Tank Size: 4.55x2.3x1.48 / 2.325x2.3x1m
Vehicle certification code: CX5300GXFSG150 / CX5150GXFSG50
Body Brand: FotonAuman / Feiyan
Engine parameters
Injection System: Common Rail (China IV)
Engine Model: WeichaiWP12.375E40 / DongfengISDe210 40
Displacement: 11.596 / 6.7L
Emission standard: China IV
Max output power: 276 / 155kW
Max hp: 375 / 210Horsepower
Rated speed: 1900 / 2500rpm
Chassis Specs
Chassis Brand: FotonAuman
Chassis Series: Auman ETX 9 Series / AumanETX / Auman
Chassis Model: BJ5323VMPKE-XA / BJ5163GYY-AB
Frame Dimensions: 320 / 250mm
Steering gear: Domestic
rear axle description: 13T / 10T
Axle ratio: 4.38 / 5.143
Leaf spring count: 9/12 / 10/10+9
clutch: Φ430 / Φ395
Transmission Parameters
Number of gears: 9 / 7Gear
Transmission Model: Fast Gear9JSD200T / DachiDC7J100TA
Cab parameters
Cab: ETX-2490 flat roof / ETX-2200 flat roof
Tire
Tire Size: 12.00R20,12.00-20 / 12.00R20 / 10R22.5
Number of tires: 10 / 6pcs
FAQ
What kind of truck is Auman Foton Auman ETX Heavy Truck fire truck?
Auman Foton Auman ETX Heavy Truck is an export-oriented fire truck lineup with about 3 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Foton Auman ETX Heavy Truck fire truck cover?
Foton Auman ETX Heavy Truck fire truck mainly covers: Drive: 4x2 / 6x4; Horsepower: 210 hp / 375 hp; Emission: China IV; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Foton Auman ETX Heavy Truck fire truck?
For Foton Auman ETX Heavy Truck fire truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is fire truck typically used for?
fire truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Foton Auman ETX Heavy Truck fire truck include?
Foton Auman ETX Heavy Truck fire truck currently lists about 3 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Foton Auman ETX Heavy Truck fire truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
