JAC Kangling 33 wide body 156hp 4X2(6 wheels) 4.03m refrigerated truck
EXW
From $15,556
Export quote
JAC H1 light truck Refrigerated Truck
Main model photos
672 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| JAC Kangling 33 wide body 156hp 4X2(6 wheels) 4.03m refrigerated truck | 4x2 / 156hp / China V | From $15,556 | |
| JAC Kangling H3 Narrow Body 88hp 4X2(6 wheels) 3.37m Refrigerated Truck | 4x2 / 88hp / China V | From $16,389 | |
| JAC Kangling H3 Narrow Body 88hp 4X2(6 wheels) 3.7m Refrigerated Truck | 4x2 / 88hp / China V | From $16,389 | |
| JAC Kangling H3 Narrow Body Express Edition 115 hp 4X2(6 wheels) 3.7m Semi-row Refrigerated Truck | 4x2 / 115hp / China V | From $10,583 | |
| JAC Kangling H3 Narrow Body Express Edition 115 hp 4X2(6 wheels) 4.03m Single Row Refrigerated Truck | 4x2 / 115hp / China V | From $10,583 |
JAC Kangling H3 Narrow Body 88hp 4X2(6 wheels) 3.37m Refrigerated Truck
EXW
From $16,389
Export quote
JAC Kangling H3 Narrow Body 88hp 4X2(6 wheels) 3.7m Refrigerated Truck
EXW
From $16,389
Export quote
JAC Kangling H3 Narrow Body Express Edition 115 hp 4X2(6 wheels) 3.7m Semi-row Refrigerated Truck
EXW
From $10,583
Export quote
JAC Kangling H3 Narrow Body Express Edition 115 hp 4X2(6 wheels) 4.03m Single Row Refrigerated Truck
EXW
From $10,583
Export quote
Series Specs
Basic Info
Cab dimensions: 5.995×2.33×3.39 / 5.55×2.04×2.97 / 5.995×2.04×3.02 / 5.995×2.28×3.19 / 5.995×2.19×3.1m
Truck Type: Refrigerated Truck
Drive type: 4X2
Wheelbase: 3308mm
Vehicle origin: Hefei, Anhui
Front track width: 1685 / 1395 / 1525mm
rear track: 1525 / 1470 / 1440 / 1665mm
Curb Weight: 3.88 / 2.7 / 2.705 / 2.805 / 1.495 / 2.8ton
Rated payload: 4.2 / 1.495 / 2.805ton
Max. speed: 95 / 90km/h
Front/rear suspension: 1.1/1.587 / 1.065/1.635 / 1.09/1.61 / 1.075/1.612 / 1.09/1.597 / 1.105/1.582m
Energy Type: Diesel
Engine parameters
Injection System: Common Rail
Engine Model: Yunnei PowerD30TCIE1 / Quanchai4A2-88C50 / Quanchai4B2-115C50 / WeichaiWP3Q130E50 / Yunnei PowerYN33CRD1
Number of cylinders: 4cylinder
Displacement: 2.977 / 2.27 / 2.545 / 2.97 / 3.298L
Emission standard: China V / China IV
Max output power: 115 / 65 / 85 / 96kW
Max hp: 156 / 88 / 115 / 130 / 116Horsepower
Max torque: 400 / 240 / 320 / 350 / 315N·m
Rated speed: 3200 / 3000rpm
Engine Type: 4-cylinder inline, 16-valve, DOHC, turbocharged intercooled, high-pressure common rail fuel injection / Electronic high-pressure common rail + SCR / Inline, water-cooled, 4-stroke, turbocharged with intercooler / Electronically controlled high-pressure common rail
Cargo box parameters
Cargo box dimensions: 4.03×2.08×2.2 / 3.37×1.81×1.85 / 3.7×1.81×1.85 / 3.7×1.81×1.9 / 4.03×1.81×1.9 / 4.03×2.08×2 / 4.15×2.06×2m
Cargo box width: 2.08 / 1.81 / 2.06m
Cargo box height: 2.2 / 1.85 / 1.9 / 2m
Body Parameters
Vehicle certification code: HFC5080XLCP91K1C2V / HFC5040XLCP93K1B4V / HFC5041XLCP93K1C2V / HFC5043XLCP91K1C2V / HFC5043XLCP91K5C2
Body Brand: JAC
Others: Supermarket delivery, short-distance fresh food delivery
Chassis Specs
Chassis Brand: JAC
Chassis Series: Kangling 808 / Kangling H3 Narrow Body / Kangling H3 / Kangling H / JAC
Chassis Model: HFC1080P91K1C2V / HFC5040XLCP93K1B4V / HFC1041P93K1C2V / HFC1043P91K1C2V / HFC1043P91K5C2
Front axle description: Payload 2995kg / 2T I-beam
Frame Dimensions: 140×55×5 / 170×70×5mm
rear axle description: Payload 5280kg / 3T / 4T
Axle ratio: 4.875 / 4.33
Leaf spring count: 12/8+6,8/7+6,13/8+6 / 7/5+3 / 3/3+4 / 3/9+7 / 13/8+6 / 12/8+6,8/7+6 / 12/8+6
Transmission Parameters
Number of gears: 6 / 5Gear
Transmission Model: Lu'an LC6T450M1 / Lu'an LC5T28B / Lu'an LC6T450 / LC5T455
Cab parameters
Cab: Narrow cab
Tire
Tire Size: 7.50-16 14PR,7.50R16 14PR / 6.50R16 / 6.50R16LT 10PR / 7.00R16LT 8PR / 7.50R16LT / 7.50R16 6PR
FAQ
What kind of truck is JAC JAC H1 light truck Refrigerated Truck?
JAC JAC H1 light truck is an export-oriented Refrigerated Truck lineup with about 10 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for JAC H1 light truck Refrigerated Truck?
JAC H1 light truck Refrigerated Truck export reference is about $10,583 – $16,389. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does JAC H1 light truck Refrigerated Truck cover?
JAC H1 light truck Refrigerated Truck mainly covers: Drive: 4x2; Horsepower: 88 hp / 115 hp / 156 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in JAC H1 light truck Refrigerated Truck?
For JAC H1 light truck Refrigerated Truck: 1) set emission; 2) match body/wheelbase to cargo type; 3) pick drive and horsepower; 4) compare prices, then open a model to quote.
What is Refrigerated Truck typically used for?
Refrigerated Truck covers box, stake or flatbed cargo work from city delivery to regional haul. Filter by body and payload needs.
How many models does JAC H1 light truck Refrigerated Truck include?
JAC H1 light truck Refrigerated Truck currently lists about 10 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for JAC H1 light truck Refrigerated Truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
