Dongfeng Commercial Vehicle Tianjin KS 210hp 4X2(6 wheels) Green Sprinkler Truck (8-speed) (Juchenwang Brand)
EXW
From $27,778
Export quote
聚尘王牌 Dongfeng Commercial Vehicle chassis water
Main model photos
18 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Commercial Vehicle Tianjin KS 210hp 4X2(6 wheels) Green Sprinkler Truck (8-speed) (Juchenwang Brand) | 4x2 / 210hp / China V | From $27,778 | |
| Dongfeng Commercial Vehicle Tianjin KS 210hp 4X2(6 wheels) Green Sprinkler Truck (Juchenwang Brand) | 4x2 / 210hp / China V | From $24,722 | |
| Dongfeng Commercial Vehicle Tianjin KS 180hp 4X2(6 wheels) Green Sprinkler Truck (Juchenwang Brand) | 4x2 / 180hp / China V | From $23,611 | |
| Dongfeng Commercial Vehicle Tianlong KL 240hp 6X4(10 wheels) water sprinkler truck (Juchenwang brand) | 6x4 / 240hp / China V | From $40,556 | |
| Dongfeng Commercial Vehicle Tianlong KL 350hp 6X4(10 wheels) water sprinkler truck (Juchenwang brand) | 6x4 / 350hp / China V | From $41,389 |
Dongfeng Commercial Vehicle Tianjin KS 210hp 4X2(6 wheels) Green Sprinkler Truck (Juchenwang Brand)
EXW
From $24,722
Export quote
Dongfeng Commercial Vehicle Tianjin KS 180hp 4X2(6 wheels) Green Sprinkler Truck (Juchenwang Brand)
EXW
From $23,611
Export quote
Dongfeng Commercial Vehicle Tianlong KL 240hp 6X4(10 wheels) water sprinkler truck (Juchenwang brand)
EXW
From $40,556
Export quote
Dongfeng Commercial Vehicle Tianlong KL 350hp 6X4(10 wheels) water sprinkler truck (Juchenwang brand)
EXW
From $41,389
Export quote
Series Specs
Basic Info
Cab dimensions: 8.9×2.5×3.2 / 8.7×2.5×3.2 / 9.95×2.5×3.15 / 8.5×2.5×3.2 / 8.6×2.5×3.2 / 8.6×2.5×2.82m
Truck Type: landscaping sprinkler truck / Water Sprinkler Truck
Drive type: 4X2 / 6X4
Wheelbase: 4700 / 4500 / 4350+1350 / 3950 / 3800mm
Vehicle origin: Suizhou, Hubei
Front track width: 1920 / 1880 / 2040 / 1876mm
rear track: 1860 / 1800 / 1860/1860 / 1820mm
Curb Weight: 6.85 / 10.995 / 7.3 / 6.97ton
Rated payload: 10.955 / 13.81 / 10.57 / 8.635ton
Max. speed: 98 / 90 / 89km/h
Front/rear suspension: 1.43/2.77 / 1.5/2.75 / 1.43/2.37 / 1.43/2.47m
Energy Type: Diesel
Body Parameters
Tank Dimensions (L×W×H): 5.3×2.28×1.42 / 5×2.3×1.45 / 6.6×2.25×1.4 / 5×2.35×1.45 / 5.1×2×1.3m
Vehicle certification code: HNY5180GPSD5 / HNY5250GSSD5 / HNY5180GPSD6 / HNY5160GSSD5
Body Brand: Juchenwang brand
Engine parameters
Engine Model: DongfengISD210 50 / DongfengISB180 50 / YuchaiYC6JA240-50 / DongfengDDi75S350-50 / DongfengDDi75S292-50 / DongfengISD270 50 / DongfengISD245 50 / DongfengB6.2NS6B210 / DongfengD6.7NS6B230 / DongfengISB210 50 / DongfengEQH180-53
Number of cylinders: 6 / 4cylinder
Displacement: 6.7 / 5.9 / 6.87 / 7.53 / 6.2 / 4.752L
Emission standard: China V / China VI
Max output power: 155 / 132 / 177 / 257 / 215 / 198 / 180 / 154 / 169kW
Max hp: 210 / 180 / 240 / 350 / 292 / 270 / 245 / 230Horsepower
Rated speed: 2500 / 2300 / 2400rpm
Engine Type: 6-cylinder, inline, turbocharged, intercooled, electronic common rail, China V engine / SCR / Vertical, inline, water-cooled, four-stroke / Water-cooled, electronic high-pressure common rail, turbocharged intercooled, SCR / Compression ignition, inline four-cylinder
Cargo box parameters
Box volume: 11.5 / 14.5 / 11.6 / 9m³
Chassis Specs
Chassis Brand: Dongfeng Commercial Vehicle
Chassis Series: Tianjin KS / Tianlong KL / Tianjin VR / Tianjin KR / Dongfeng Tianjin KS
Chassis Model: DFH1180BX1V / DFL1250A13 / DFH1180EX8 / DFL1160BX1V
Front axle description: 4.5T / 5T / 5.5T
rear axle description: 9T / 10T
Leaf spring count: 8/10+8 / 7/9+6,8/10+8 / 8/9,8/10,9/10 / 7/9+6,8/10+8,8/9+6,11/10+8 / 7/9+6,8/10+8,10/11+10,11/11+10
Transmission Parameters
Number of gears: 8 / 6 / 9 / 7Gear
Transmission Model: Fast Gear 8-speed / Dongfeng 6-speed / Fast Gear 9-speed / Dachi 7-speed
Tire
Tire Size: 10.00R20 18PR / 275/80R22.5 18PR / 10.00R20 18PR,275/80R22.5 18PR / 11.00R20 18PR / 11.00-20 18PR,11.00R20 18PR,295/80R22.5 18PR,12.00R20 16PR / 9.00R20 16PR
Number of tires: 6 / 10pcs
FAQ
What kind of truck is 聚尘王牌 聚尘王牌 Dongfeng Commercial Vehicle chassis water sprinkler truck?
聚尘王牌 聚尘王牌 Dongfeng Commercial Vehicle chassis is an export-oriented water sprinkler truck lineup with about 15 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for 聚尘王牌 Dongfeng Commercial Vehicle chassis water?
聚尘王牌 Dongfeng Commercial Vehicle chassis water export reference is about $21,111 – $42,500. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does 聚尘王牌 Dongfeng Commercial Vehicle chassis water cover?
聚尘王牌 Dongfeng Commercial Vehicle chassis water mainly covers: Drive: 4x2 / 6x4; Horsepower: 180 hp / 210 hp / 240 hp / 350 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in 聚尘王牌 Dongfeng Commercial Vehicle chassis water?
For 聚尘王牌 Dongfeng Commercial Vehicle chassis water: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is water sprinkler truck typically used for?
water sprinkler truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does 聚尘王牌 Dongfeng Commercial Vehicle chassis water include?
聚尘王牌 Dongfeng Commercial Vehicle chassis water currently lists about 15 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for 聚尘王牌 Dongfeng Commercial Vehicle chassis water?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
