Kama Kaijie HM3 Zunxiang Edition 137 hp 4X2(6 wheels) 3.83m dump truck (China VI) (8-speed)
EXW
Export quote
Kama Kaijie HM3 Light Truck Dump Trucks
Main model photos
68 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Kama Kaijie HM3 Zunxiang Edition 137 hp 4X2(6 wheels) 3.83m dump truck (China VI) (8-speed) | 4x2 / 137hp / China VI | ||
| Kama Kaijie HM3 Zunxiang Edition 137 hp 4X2(6 wheels) 4.16m dump truck (China VI) (8-speed) | 4x2 / 137hp / China VI | ||
| Kama Kaijie HM3 Zunxiang Edition 137 hp 4X2(6 wheels) 3.83m Dump Truck (China VI) | 4x2 / 137hp / China VI | ||
| Kama Kaijie HM3 Zunxiang Edition 137 hp 4X2(6 wheels) 4.16m Dump Truck (China VI) | 4x2 / 137hp / China VI | ||
| Kama Kaijie HM3 Zunxiang Edition 140 hp 4X2(6 wheels) 3.83m Dump Truck (China VI)(8-speed) | 4x2 / 140hp / China VI |
Kama Kaijie HM3 Zunxiang Edition 137 hp 4X2(6 wheels) 4.16m dump truck (China VI) (8-speed)
EXW
Export quote
Kama Kaijie HM3 Zunxiang Edition 137 hp 4X2(6 wheels) 3.83m Dump Truck (China VI)
EXW
Export quote
Kama Kaijie HM3 Zunxiang Edition 137 hp 4X2(6 wheels) 4.16m Dump Truck (China VI)
EXW
Export quote
Kama Kaijie HM3 Zunxiang Edition 140 hp 4X2(6 wheels) 3.83m Dump Truck (China VI)(8-speed)
EXW
Export quote
Series Specs
Basic Info
Model code (announced): KMC3092HB330DP6 / KMC3092HA330DP6 / KMC3042HB330DP6 / KMC3042HA330DP5 / KMC3042HQ330DP6 / KMC3042HA33D5 / KMC3042HA330DP6 / KMC3042HA33P5 / KMC3046HA33D5
Drive type: 4X2
Wheelbase: 3300 / 3600mm
Engine Model: Yunnei Power490PLUS2 / XichaiCA4DB1-14E68 / Yunnei PowerD25TCIF1 / XichaiCA4DB1-11E6 / WeichaiWP2.3NQ130E50 / WeichaiWP2.3Q110E50 / QuanchaiQ23-115E60 / XichaiCA4DB1-13E6 / WeichaiWP2.3NQ130E61 / Yunnei PowerYN27CRE10 / Chaochai4BK461 / Yunnei PowerYN27CRE1 / Yunnei PowerYN33CRE1 / Xichai4DW93-84E5
Transmission Model: 8-speed gearbox / 5-speed transmission / WLY 8-speed / WLY10H35-576-51 / WLYWLY1046 / WLY5-speed / WLYWLY10H35 / WLYWLY10H46 / WLYWLY5H46 / WLYWLY1046HF / Lu'an LC5T40 / Lu'an MSC-5S / 5-speed gearbox
Rear Axle Ratio: 5.375 / 4.875 / 4.33
Cab length: 5.995 / 6.445 / 5.955m
Cab width: 2.32 / 2.28 / 2.55 / 2.24 / 2.1 / 1900m
Cab height: 2.16 / 2.34 / 2.37 / 2.53 / 2.39m
Front track width: 1610 / 1570 / 1600 / 1620 / 1680mm
rear track: 1590 / 1655 / 1600 / 1550mm
Curb Weight: 4.05 / 4.45 / 2.72 / 2.6ton
Rated payload: 4.855 / 4.455 / 1.58 / 1.495 / 1.56ton
GVWR: 9.1 / 4.495 / 4.29ton
Origin: Shouguang, Shandong
tonnage class: Medium-duty truck / Light Truck
Approach angle: 18 / 21 / 20 / 25°
departure angle: 15 / 16 / 17 / 18°
Version: Zunxiang Edition
Energy Type: Diesel
Engine parameters
Engine Brand: Yunnei Power / Xichai / Weichai / Quanchai
Number of cylinders: 4cylinder
Displacement: 2.499 / 2.2 / 2.5 / 2.29 / 2.3 / 2.672 / 3.298 / 2.54L
Emission standard: China VI / China V
Max output power: 101 / 100 / 110 / 81 / 96 / 85 / 95 / 70 / 64kW
Max hp: 137 / 140 / 150 / 110 / 130 / 115 / 116 / 95 / 84Horsepower
Max torque: 350 / 400 / 280 / 380 / 320 / 305 / 250 / 315 / 220N·m
Max torque speed: 1600-2400 / 1400-2400 / 1700-2300 / 2000 / 1600-2600 / 1900-2100rpm
Rated speed: 3000 / 3200rpm
Engine Type: Inline 4-cylinder, 4-stroke, water-cooled, turbocharged intercooled, BOSCH 1800BAR common rail system, EGR DOC DPF / Electronic control common rail system HEGR + DOC + DPF + SCR + ASC / Common Rail+SCR / Inline 4-cylinder, water-cooled, 4-stroke, turbocharged with intercooler, high-pressure common rail / 4-valve, high-pressure common rail, turbocharged intercooled / 4-cylinder inline, 8-valve, turbocharged intercooled, high-pressure common rail fuel injection / 4-cylinder inline, direct injection, turbocharged & intercooled, electronic common rail
Technology route: Common Rail SCR
Transmission Parameters
Transmission Brand: WLY / Lu'an
shift method: Manual
Forward gears: 8 / 5Gear
Number of Reverse Gears: 2 / 1pcs
Cargo box parameters
Seal cover type: none
Unloading Type: Dump type / Rear-dump body
Cargo box type: square box / Dump type / Rear-dump body
Cargo box length: 3.83 / 4.16 / 4.27 / 4.6 / 4.2m
Body Parameters
Lifting type: Double Lift Cylinder
FAQ
What kind of truck is Kama Kama Kaijie HM3 Light Truck Dump Trucks?
Kama Kama Kaijie HM3 Light Truck is an export-oriented Dump Trucks lineup with about 28 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Kama Kaijie HM3 Light Truck Dump Trucks?
Kama Kaijie HM3 Light Truck Dump Trucks export reference is about $12,083 – $18,056. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Kama Kaijie HM3 Light Truck Dump Trucks cover?
Kama Kaijie HM3 Light Truck Dump Trucks mainly covers: Drive: 4x2; Horsepower: 137 hp / 140 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Kama Kaijie HM3 Light Truck Dump Trucks?
For Kama Kaijie HM3 Light Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Kama Kaijie HM3 Light Truck Dump Trucks include?
Kama Kaijie HM3 Light Truck Dump Trucks currently lists about 28 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Kama Kaijie HM3 Light Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
