FAW Liute Longwei (L5P) Heavy Truck 330 hp 8X4(12 wheels) 7m Dump Truck (Heavy-duty)
EXW
From $48,611
Export quote
FAW Liute Longwei L5P Heavy Truck Dump Trucks
Main model photos
12 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Liute Longwei (L5P) Heavy Truck 330 hp 8X4(12 wheels) 7m Dump Truck (Heavy-duty) | 8x4 / 330hp / China IV | From $48,611 | |
| FAW Liute Longwei (L5P) Heavy Truck Standard Load Version 310 hp 8X4(12 wheels) 8m Dump Truck | 8x4 / 310hp / China IV | From $45,042 | |
| FAW Liute Longwei (L5P) Heavy Truck 310 hp 8X4(12 wheels) 7.6m Dump Truck (Front Lift) | 8x4 / 310hp / China IV | From $44,458 | |
| FAW Liute Longwei (L5P) Heavy Truck 310 hp 8X4(12 wheels) 7.2m Dump Truck (Front Lift) | 8x4 / 310hp / China IV | From $43,653 | |
| FAW Liute Longwei (L5P) Heavy Truck 310 hp 8X4(12 wheels) 7m Dump Truck (Front Lift) | 8x4 / 310hp / China IV | From $43,292 |
FAW Liute Longwei (L5P) Heavy Truck Standard Load Version 310 hp 8X4(12 wheels) 8m Dump Truck
EXW
From $45,042
Export quote
FAW Liute Longwei (L5P) Heavy Truck 310 hp 8X4(12 wheels) 7.6m Dump Truck (Front Lift)
EXW
From $44,458
Export quote
FAW Liute Longwei (L5P) Heavy Truck 310 hp 8X4(12 wheels) 7.2m Dump Truck (Front Lift)
EXW
From $43,653
Export quote
FAW Liute Longwei (L5P) Heavy Truck 310 hp 8X4(12 wheels) 7m Dump Truck (Front Lift)
EXW
From $43,292
Export quote
Series Specs
Basic Info
Model code (announced): LZT3314PK2E4T4A93 / LZT3310PK2E4T4A92 / LZT3315PK2E4T4A92 / LZT3311PK2E4T4A91 / LZT3311P31K2E4T4A93 / LZT3258PK2E4T1A93 / LZT3256PK2E4T1A93 / LZT3254PK2E4T1A93 / LZT3251PK2E4T1A93 / LZT3256PK2E4T3A90 / LZT3252P2K2E3T1A92 / LZT3304P2K2E3T4A92 / LZT3255P2K2E3T1A92
Drive type: 8X4 / 6X4 / 6X2
Wheelbase: 1860+3400+1350 / 1860+3800+1350 / 1860+2990+1350 / 1860+2740+1350 / 1860+3600+1350 / 4850+1350 / 4250+1350 / 3980+1350 / 3750+1350 / 1860+3500 / 1860+4000+1350mm
Engine Model: XichaiCA6DL2-33E4 / XichaiCA6DL2-31E4 / XichaiCA6DL2-29E4 / XichaiCA6DL2-35E4 / XichaiCA6DL2-31E4(R) / XichaiCA6DL1-26E4 / Xichai CA6DL2-31E3F (engineering version) / XichaiCA6DL1-28E3F / XichaiCA6DL2-35E4(R)35E4
Transmission Model: Fast Gear12JS160T / FAW JiefangCA10TAX160M / Fast Gear12JS160TA / Fast Gear8JS118 / FAW JiefangCA10TA130M
Rear Axle Ratio: 5.73 / 5.286 / 5.921 / 4.875
Cab length: 9.89 / 10.85 / 10.45 / 10.07 / 9.17 / 10.28 / 9.685 / 9.485 / 9.28 / 9.08 / 8.89 / 8.69 / 8.485 / 8.9m
Cab width: 2.5 / 2.49m
Cab height: 3.52 / 3.43 / 3.65 / 3.47m
Front track width: 2020/2020 / 1830/1830,1920/1920 / 2020mm
rear track: 1860/1860 / 1860mm
Curb Weight: 15.005 / 15.23 / 14.98 / 14.78 / 15 / 12.005 / 12.205 / 12.155 / 12.045 / 11.82 / 15.06ton
Rated payload: 15.865 / 15.565 / 15.87 / 15.805 / 16.065 / 12.865 / 12.665 / 12.715 / 12.825 / 12.565 / 14.985ton
GVWR: 31 / 30.925 / 30.98 / 30.975 / 25 / 24.515 / 30.175ton
Origin: Liuzhou, Guangxi / Liuzhou, Guangxi Liuzhou, Guangxi Liuzhou, Guangxi
tonnage class: Heavy truck
Approach angle: 28 / 19 / 16 / 25°
departure angle: 15 / 17 / 21 / 20 / 16 / 18 / 19°
Remarks: Cab color: Uros Red; air conditioning; air-suspended full-floating cab mount; manual hydraulic cab tilting device; mechanical damping driver seat; external sun visor; heavy-duty Steyr cast steel suspension; rear axle suspension with double U-bolts; heavy-duty large rubber thrust rod; large connecting plate; transmission rear PTO; φ120 large-diameter four-hole end-face tooth heavy-duty driveshaft; large copper radiator; cyclone dual-channel intake pipe; oil-bath air cleaner (with secondary air filter); radiator guard; heavy-duty large-bore power steering gear; exhaust brake; air-to-air intercooler; air handbrake; air dryer; cold start; distribution box (with master power switch); full-length constant-width straight frame rail; 350L iron fuel tank / Mainly flat gravel, dirt roads, asphalt national/provincial highways, expressways — fairly good road conditions. Economical speed 50 km/h. / Mainly flat gravel, dirt roads, asphalt national/provincial highways, expressways — good road conditions; Cab color: Urusso Red; A/C; Cab manual hydraulic tilt; Mechanical 8-way adjustable driver seat; External sun visor; Reinforced 457 suspension; Rear axle suspension double U-bolts; Large rubber thrust rod; Large connecting plate; PTO rear take-off; φ120mm 4-hole face tooth heavy-duty driveshaft; Oversized aluminum radiator; Desert air filter; Radiator protection device; Heavy-duty large-bore power steering; Exhaust brake; Air-to-air intercooler; Air handbrake; Air dryer; Cold start; Fuse box; Full-length straight frame; 350L steel fuel tank; Power windows; ABS.
Version: Standard Load Edition
Energy Type: Diesel
Engine parameters
Engine Brand: Xichai
Number of cylinders: 6cylinder
Displacement: 8.75 / 8.6 / 7.7 / 8.57L
Emission standard: China IV / China III / Euro III
Max output power: 249 / 231 / 218 / 261 / 195 / 209kW
Max hp: 330 / 310 / 296 / 350 / 260 / 280Horsepower
Max torque: 1350 / 1250 / 1500 / 1050 / 1100N·m
Max torque speed: 1300-1500 / 1300-1700 / 1400rpm
Rated speed: 2100 / 2300rpm
Engine Type: 6-cylinder inline, direct injection, turbocharged intercooled, electronic common rail / 6-cylinder inline, 4-valve, direct injection, electronic common rail / 6-cylinder inline, direct injection, turbocharged intercooled, inline pump EGR / 8-cylinder inline, direct injection, turbocharged intercooled, electronic common rail
Transmission Parameters
Transmission Brand: Fast Gear / FAW Jiefang
shift method: Manual
Forward gears: 12 / 10 / 8Gear
Number of Reverse Gears: 2 / 1pcs
Cargo box parameters
Unloading Type: Dump type / Rear-dump body
Cargo box length: 7 / 8 / 7.6 / 7.2 / 6.5 / 6.8 / 6.6 / 6.4 / 6.2 / 6 / 5.8 / 5.6m
Cargo box width: 2.3m
Cargo box height: 1.16 / 1 / 1.2 / 1.28 / 1.1 / 1.05 / 0.8m
fuel tank
Fuel tank capacity: 350L
FAQ
What kind of truck is FAW Liute FAW Liute Longwei L5P Heavy Truck Dump Trucks?
FAW Liute FAW Liute Longwei L5P Heavy Truck is an export-oriented Dump Trucks lineup with about 18 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for FAW Liute Longwei L5P Heavy Truck Dump Trucks?
FAW Liute Longwei L5P Heavy Truck Dump Trucks export reference is about $36,153 – $49,083. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does FAW Liute Longwei L5P Heavy Truck Dump Trucks cover?
FAW Liute Longwei L5P Heavy Truck Dump Trucks mainly covers: Drive: 8x4; Horsepower: 310 hp / 330 hp; Emission: China IV; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in FAW Liute Longwei L5P Heavy Truck Dump Trucks?
For FAW Liute Longwei L5P Heavy Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does FAW Liute Longwei L5P Heavy Truck Dump Trucks include?
FAW Liute Longwei L5P Heavy Truck Dump Trucks currently lists about 18 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for FAW Liute Longwei L5P Heavy Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
