Dongfeng Special Chassis Series 290 hp 8X4(12 wheels) truck-mounted crane
EXW
Export quote
Dongfeng Special Chassis truck-mounted crane
Main model photos
87 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Special Chassis Series 290 hp 8X4(12 wheels) truck-mounted crane | 8x4 / 290hp / China V | ||
| Dongfeng Zhuandi series 180 hp 4X2(6 wheels) 6.1m truck-mounted crane | 4x2 / 180hp / China V | From $38,889 | |
| Dongfeng Special Chassis Series 210hp 4X2(6 wheels) 5.6m Truck-mounted Crane | 4x2 / 210hp / China V | From $37,014 | |
| Dongfeng special chassis series 180hp 4X2(6 wheels) 5.6m truck-mounted crane | 4x2 / 180hp / China V | From $35,764 | |
| Dongfeng Special Chassis Series 190hp 4X2(6 wheels) 5.6m Truck-mounted Crane | 4x2 / 190hp / China V | From $35,069 |
Dongfeng Zhuandi series 180 hp 4X2(6 wheels) 6.1m truck-mounted crane
EXW
From $38,889
Export quote
Dongfeng Special Chassis Series 210hp 4X2(6 wheels) 5.6m Truck-mounted Crane
EXW
From $37,014
Export quote
Dongfeng special chassis series 180hp 4X2(6 wheels) 5.6m truck-mounted crane
EXW
From $35,764
Export quote
Dongfeng Special Chassis Series 190hp 4X2(6 wheels) 5.6m Truck-mounted Crane
EXW
From $35,069
Export quote
Series Specs
Basic Info
Cab dimensions: 12.0×2.5×3.98 / 9.0×2.55×3.85 / 8.73×2.55×3.85 / 11.95×2.55×3.85 / 10.85×2.55×3.85 / 11.95×2.5×3.85 / 9.0×2.55×3.95 / 9×2.55×3.95 / 8.53×2.55×3.95 / 12.0×2.52×3.8 / 8.53×2.55×3.85m
Type: Truck with crane
Drive type: 8X4 / 4X2 / 6X4
Wheelbase: 2150+4250+1350 / 5100 / 4500 / 5900+1300 / 4350+1300 / 5150 / 1850+4600+1350 / 3800,4200,4500,4700,5100,5600,6500,7100,5150,6300mm
Rated mass: 11.45 / 6.37 / 8.295 / 8.87 / 4.17 / 4.105 / 13.425ton
GVWR: 31 / 18 / 24.49 / 25 / 15.8ton
Front/rear suspension: 1.515/1.685 / 1.25/2.13 / 1.45/3.25 / 1.45/2.7 / 1.45/2.45 / 1.45/2.38 / 1.25/2.85m
Energy Type: Diesel
Body Parameters
Crane model: SQS350,QYS-14,SPS35000,ZLC3500 / SQS200,QYS-8,SPS20000,URV804 / SQS350,QYS-14,SPS35000,URV1204 / SQS350,QYS-14,SPS35000,ZLC4000 / SQS200,QYS-8,SPS20000,ZLC2000
Lifting capacity: 14 / 8 / 11ton
crane self-weight: 5.5 / 3.5ton
Vehicle certification code: DFZ5310JSQSZ5D2 / EQ5180JSQGD5D / EQ5240JSQGD5D / EQ5250JSQGZ5D / EQ5160JSQGZ5D / EQ5310JSQGZ5D
Body Brand: Dongfeng
Engine parameters
Engine Brand: Yuchai / Dongfeng
Engine Model: YuchaiYC6A290-50 / YuchaiYC6JA180-50 / DongfengISB210 50 / DongfengISB190 50 / DongfengISB170 50 / YuchaiYC6JA220-50 / YuchaiYC6JA240-50 / YuchaiYC6A270-50 / YuchaiYC6A240-50 / YuchaiYC4EG160-50 / DongfengISL9.5-292E51A / DongfengISD180 50
Displacement: 7.52 / 6.87 / 5.9 / 4.7 / 9.46 / 4.5L
Emission standard: China V
Max output power: 213 / 132 / 155 / 140 / 125 / 162 / 177 / 199 / 118 / 215kW
Max hp: 290 / 180 / 210 / 190 / 170 / 220 / 240 / 270 / 160 / 292Horsepower
Max torque: 1150 / 700 / 750 / 720 / 560 / 860 / 950 / 1100 / 1000 / 600 / 1200N·m
Max torque speed: 1200-1800 / 1300-1700 / 1200-1700 / 1300-1800 / 1100-1700 / 1200-1600rpm
Rated speed: 2300 / 2500 / 1900rpm
Chassis Specs
Chassis Brand: Dongfeng
Chassis Series: Dongfeng Special Chassis / special chassis
Chassis Model: EQ1310GSZ5DJ2 / EQ1180GD5DJ / EQ1250GZ5DJ1 / EQ1160GZ5DJ / EQ1310GZ5DJ
rear axle description: 10T / 11.5T / 10
Leaf spring count: 9/9/9 / 8/9+7,8/10+7,3/4+3,9/12+10,8/10+8,7/9+6,11/11+10,9/10+8 / 8/9,8/10,9/10,8/13,9/13 / 9/10+8,8/10+7 / 9/9/9,3/3/4,9/9/13
Transmission Parameters
Number of gears: 8 / 9Gear
Transmission Model: Fast Gear 8-speed / Fast Gear 9-speed
Tire
Tire Size: 11.00R20 18PR / 10.00-20 18PR,10.00R20 18PR / 11.00-20 16PR,11.00R20 18PR / 10R22.5 16PR,10.00-20 16PR,10.00R20 16PR,10.00R20 18PR / 10.00-20 18PR,10.00R20 18PR,11.00-20 16PR,11.00R20 18PR,12R22.5 18PR,295/80R22.5 18PR / 10.00-20 18PR,10.00R20 18PR,11.00-20 16PR,11.00R20 18PR,295/80R22.5 18PR,315/80R22.5 16PR,315/60R22.5 18PR,315/70R22.5 18PR
Number of tires: 12 / 6 / 10pcs
FAQ
What kind of truck is Dongfeng Dongfeng Special Chassis truck-mounted crane?
Dongfeng Dongfeng Special Chassis is an export-oriented truck-mounted crane lineup with about 20 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Dongfeng Special Chassis truck-mounted crane?
Dongfeng Special Chassis truck-mounted crane export reference is about $29,236 – $46,111. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Dongfeng Special Chassis truck-mounted crane cover?
Dongfeng Special Chassis truck-mounted crane mainly covers: Drive: 4x2 / 8x4; Horsepower: 180 hp / 190 hp / 210 hp / 290 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dongfeng Special Chassis truck-mounted crane?
For Dongfeng Special Chassis truck-mounted crane: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is truck-mounted crane typically used for?
truck-mounted crane specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Dongfeng Special Chassis truck-mounted crane include?
Dongfeng Special Chassis truck-mounted crane currently lists about 20 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng Special Chassis truck-mounted crane?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
