Xichai CA4DB1-15E68 150 hp 2.2L China VI Diesel Engine
EXW
Export quote
Xichai Jinwei 4DB series engine
Main model photos
12 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Xichai CA4DB1-15E68 150 hp 2.2L China VI Diesel Engine | 150hp / China VI | ||
| Xichai CA4DB1A12E68 120hp 2.2L China VI diesel engine | 120hp / China VI | ||
| Xichai CA4DB2A13E68 130 hp 2.4L China VI Diesel Engine | 130hp / China VI | ||
| Xichai CA4DB2-13E68 130 hp 2.4L China VI Diesel Engine | 130hp / China VI | ||
| Xichai CA4DB2A14E68 140 hp 2.4L China VI Diesel Engine | 140hp / China VI |
Xichai CA4DB1A12E68 120hp 2.2L China VI diesel engine
EXW
Export quote
Xichai CA4DB2A13E68 130 hp 2.4L China VI Diesel Engine
EXW
Export quote
Xichai CA4DB2-13E68 130 hp 2.4L China VI Diesel Engine
EXW
Export quote
Xichai CA4DB2A14E68 140 hp 2.4L China VI Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: Jinwei 4DB Series / Jinwei 4DB1 Series
Engine manufacturer: Xichai
Intake type: Turbocharged Air-to-Air Intercooling
Min. fuel consumption at full load: ≤198 / 205g/kW.h
Engine net weight: 225 / 250kg
Engine Dimensions: 680×590×713 / 680×590×698mm
noise at 1m: ≤95dB
Bore × Stroke: 86×105 / 86×95mm
Valves per cylinder: 4pcs
Engine Brand: Xichai
Engine Model: CA4DB1-15E68 / CA4DB1A12E68 / CA4DB2A13E68 / CA4DB2-13E68 / CA4DB2A14E68 / CA4DB2-15E68 / CA4DB2A17E68 / CA4DB2-17E68 / CA4DB2-18E68 / CA4DB1-11E68 / CA4DB2A16E68 / CA4DB2-16E68 / CA4DB1A14E68 / CA4DB1A13E68 / CA4DB1-14E68 / CA4DB1A13E6 / CA4DB1-13E6 / CA4DB1-12E6 / CA4DB1-11E6 / CA4DB1-12E5 / CA4DB1-13E5 / CA4DB1-09E5 / CA4DB1-10E5 / CA4DB1-11E5
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 2.207 / 2.44 / 2.2 / 2.21L
Emission standard: China VI / China V
Max output power: 112 / 88 / 110 / 129 / 81 / 118 / 100 / 95 / 95.2 / 65 / 70 / 80kW
Max hp: 150 / 120 / 130 / 140 / 170 / 180 / 110 / 160 / 90 / 100Horsepower
Max torque: 320 / 400 / 450 / 500 / 350 / 280 / 225 / 240N·m
Max torque speed: 1000-2400 / 1200-2200 / 1000-2900 / 1200-2600 / 1400-2200 / 1400-2000 / 1600-2400 / 1500-2400rpm
Rated speed: 3000 / 3200rpm
Engine Type: DOC+DPF+Hi-SCR / Inline 4-cylinder, 4-stroke, water-cooled, turbocharged intercooled, BOSCH 1800BAR common rail system, EGR DOC DPF / Inline 4-cylinder, 4-stroke, water-cooled, turbocharged intercooled, BOSCH 1800BAR common rail system, EGR+DOC+DPF / Inline 4-cylinder, four-stroke, water-cooled, turbocharged intercooled
FAQ
What kind of truck is Xichai Xichai Jinwei 4DB series engine?
Xichai Xichai Jinwei 4DB series is an export-oriented engine lineup with about 24 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Xichai Jinwei 4DB series engine cover?
Xichai Jinwei 4DB series engine mainly covers: Horsepower: 120 hp / 130 hp / 140 hp / 150 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Xichai Jinwei 4DB series engine?
For Xichai Jinwei 4DB series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Xichai Jinwei 4DB series engine include?
Xichai Jinwei 4DB series engine currently lists about 24 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Xichai Jinwei 4DB series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
