Foton Times Yuling VQ1 114 hp 4X2(6 wheels) 2.9m Refrigerated Truck
EXW
From $9,375
Export quote
Foton Forland Yuling Mini Truck Refrigerated Truck
Main model photos
716 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Foton Times Yuling VQ1 114 hp 4X2(6 wheels) 2.9m Refrigerated Truck | 4x2 / 114hp / China V | From $9,375 | |
| Foton Times Yuling VQ2 87hp 4X2(6 wheels) 3.12m refrigerated truck | 4x2 / 87hp / China V | From $6,306 | |
| Foton Times Yuling VQ2 112 hp 4X2(6 wheels) 3.12m refrigerated truck | 4x2 / 112hp / China V | From $10,556 | |
| Foton Times Yuling VQ1 112hp 4X2(6 wheels) 2.9m Refrigerated Truck | 4x2 / 112hp / China V | From $4,903 | |
| Foton Times Yuling VQ1 86hp 4X2(6 wheels) 2.93m refrigerated truck | 4x2 / 86hp / China V | From $4,403 |
Foton Times Yuling VQ2 87hp 4X2(6 wheels) 3.12m refrigerated truck
EXW
From $6,306
Export quote
Foton Times Yuling VQ2 112 hp 4X2(6 wheels) 3.12m refrigerated truck
EXW
From $10,556
Export quote
Foton Times Yuling VQ1 112hp 4X2(6 wheels) 2.9m Refrigerated Truck
EXW
From $4,903
Export quote
Foton Times Yuling VQ1 86hp 4X2(6 wheels) 2.93m refrigerated truck
EXW
From $4,403
Export quote
Series Specs
Basic Info
Cab dimensions: 4.85×1.69×2.375 / 5.05×1.77×2.55 / 4.825×1.675×2.35 / 4.795×1.67×2.4 / 4.45×1.55×2.4 / 4.825×1.67×2.35m
Truck Type: Refrigerated Truck
Drive type: 4X2
Vehicle origin: Shandong Zhucheng / Beijing
Wheelbase: 2566 / 2600 / 2700 / 2370mm
Front track width: 1260 / 1345 / 1340mm
rear track: 1195 / 1280 / 1260 / 1340mm
Curb Weight: 1.61 / 2.05 / 1.54 / 1.6 / 1.385 / 1.56ton
Rated payload: 1.495 / 0.999 / 0.995 / 0.495ton
Max. speed: 110 / 90km/h
Front/rear suspension: 0.895/1.389 / 1.09/1.36 / 0.895/1.23 / 0.895/1.2 / 0.895/1.185m
Energy Type: gasoline
Engine parameters
Engine Model: QuanchaiA15G / Wuling LiujiLJ469Q-AEC / RuizhanTNN4G15B / RuizhanTNN4G15A / Foton4W12M1 / Wuling LiujiLJ465Q-2AE
Number of cylinders: 4cylinder
Displacement: 1.499 / 1.249 / 1.206 / 1.051L
Emission standard: China V
Max output power: 84 / 64 / 82 / 63 / 45kW
Max hp: 114 / 87 / 112 / 86 / 61Horsepower
Max torque: 122 / 105 / 143 / 112 / 85N·m
Rated speed: 6000 / 5600rpm
Engine Type: 4-cylinder, inline, water-cooled, 4-stroke / DOHC, 16-valve, VVT-i, electronic multi-point sequential injection / 4-stroke, inline inclined, mechanically adjusted roller rocker arm, electronic fuel injection, electronic ignition
Cargo box parameters
Cargo box dimensions: 2.9×1.56×1.465 / 3.12×1.65×1.56 / 2.93×1.51×1.47 / 2.91×1.42×1.455 / 2.6×1.39×1.47m
Cargo box width: 1.56 / 1.65 / 1.51 / 1.42 / 1.39m
Cargo box height: 1.465 / 1.56 / 1.47 / 1.455m
Body Parameters
Vehicle certification code: BJ5030XLC-D5 / BJ5032XLC-AA / BJ5030XLC-AB / BJ5032XLC-F2 / BJ5030XLC-AA / BJ5020XLC-AF
Refrigeration unit: HFC R404A (optional)
Body Brand: Foton Times
Refrigeration temperature: Min -15°C
Others: Body material: fiberglass outer, polystyrene foam inner. Options: ventilation channels, meat hooks, rails. Other: heater, radio, front disc rear drum, load-sensing proportioning valve
Chassis Specs
Chassis Brand: Foton Times
Chassis Series: Yuling
Chassis Model: BJ1030V5JL3-D5 / BJ1032V4JV3-B4 / BJ1030V4JV4-Y2 / BJ1030V4JV4-F1 / BJ1030V4JV2-S1 / BJ1020V3JV4-AF
Frame Dimensions: 130x50x4 / 110X55mm
rear axle description: 121 rear axle / 121 / 110 / BJ121
Axle ratio: 5.375 / 4.875 / 4.33
Leaf spring count: 3/5 / 7/5+3 / 5/4 / -/5
Transmission Parameters
Number of gears: 5Gear
Transmission Model: MengwoLG515 / QingshanMR63 / QingshanMR70 / QingshanMR510A / QingshanMR508A / MengwoMT78Q / QingshanMR510
Cab parameters
Cab: Single Row
Tire
Tire Size: 175R14LT 8PR / 185R15LT 6PR / 175R14LT / 165R13LT 8PR
FAQ
What kind of truck is Foton Forland Yuling Mini Truck Refrigerated Truck?
Foton Forland Yuling Mini Truck is an export-oriented Refrigerated Truck lineup with about 14 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Foton Forland Yuling Mini Truck Refrigerated Truck?
Foton Forland Yuling Mini Truck Refrigerated Truck export reference is about $3,958 – $10,556. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Foton Forland Yuling Mini Truck Refrigerated Truck cover?
Foton Forland Yuling Mini Truck Refrigerated Truck mainly covers: Drive: 4x2; Horsepower: 86 hp / 87 hp / 112 hp / 114 hp; Emission: China V; Fuel: gasoline. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Foton Forland Yuling Mini Truck Refrigerated Truck?
For Foton Forland Yuling Mini Truck Refrigerated Truck: 1) set emission; 2) match body/wheelbase to cargo type; 3) pick drive and horsepower; 4) compare prices, then open a model to quote.
What is Refrigerated Truck typically used for?
Refrigerated Truck covers box, stake or flatbed cargo work from city delivery to regional haul. Filter by body and payload needs.
How many models does Foton Forland Yuling Mini Truck Refrigerated Truck include?
Foton Forland Yuling Mini Truck Refrigerated Truck currently lists about 14 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Foton Forland Yuling Mini Truck Refrigerated Truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
