Chaochai CY4D125-CE4 175hp 4.75L China IV diesel engine
EXW
Export quote
Chaochai CYD Series engine
Main model photos
12 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Chaochai CY4D125-CE4 175hp 4.75L China IV diesel engine | 175hp / China IV | ||
| Chaochai CY4D85-FD 115hp 4.75L China II Diesel Engine | 115hp / China III / Euro III | ||
| Chaochai CY4D115-CE4 160 hp 4.75L China IV Diesel Engine | 160hp / China IV | ||
| ChaochaiCY4D85-C3-FD 115hp 4.75L China III Diesel Engine | 115hp / China III / Euro III | ||
| Chaochai CY4D125-C3 170 hp 4.75L China III Diesel Engine | 170hp / China III / Euro III |
Chaochai CY4D85-FD 115hp 4.75L China II Diesel Engine
EXW
Export quote
Chaochai CY4D115-CE4 160 hp 4.75L China IV Diesel Engine
EXW
Export quote
ChaochaiCY4D85-C3-FD 115hp 4.75L China III Diesel Engine
EXW
Export quote
Chaochai CY4D125-C3 170 hp 4.75L China III Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: CYD Series
Engine manufacturer: Dongfeng Chaoyang Chaochai Power Co., Ltd.
Suitable Range: For 8-12 ton trucks, construction vehicles, 7-9m buses, school buses, 5-10 ton forklifts / Compatible with 5–10 ton forklifts, excavators, generator sets, etc. / Medium and heavy Sinotruk trucks, buses, and construction machinery. / ·3-5 ton cargo trucks, construction machinery, high-end luxury tourist midibuses, and generator sets, marine sets / 3-5 ton cargo truck, construction machinery, high-end luxury tourist midibus, and generator sets, marine sets / Ideal replacement matching power for medium and heavy Sinotruk trucks, buses, and construction machinery. / This product is mainly used for 3-5 ton trucks, high-end luxury tourist midibuses, and construction machinery, generator sets, marine engines, etc. / This product is mainly used for around 4 ton light trucks, high-end 29-seat luxury tourist midibuses with AC and audio, and construction machinery, generator sets, marine engines, etc.
Intake type: Turbocharged Air-to-Air Intercooling
Min. fuel consumption at full load: ≤205 / 205 / 215 / 225g/kW.h
Engine net weight: 470 / 395 / 595 / 365 / 350kg
Engine Dimensions: 892x733x788 / 964x723x863 / 1181×699.8×833.3 / 1280×850×945 / 1121.5×615.5×743.5mm
noise at 1m: 113 / 116 / 115dB
Compression ratio: 17：1 / 18:1 / 18：1 / 18.5：1
Bore × Stroke: 110x125 / 115x125 / 110x112mm
Valves per cylinder: 2 / 4pcs
firing order: 1-3-4-2 / 1-5-3-6-2-4
Engine Brand: Chaochai
Engine Model: CY4D125-CE4 / CY4D85-FD / CY4D115-CE4 / CY4D85-C3-FD / CY4D125－C3/D3 / CY4D120－D3 / CY4D125－D3 / CY4D120－C3 / CY4D115－D3 / CY4D115-C3 / CY6D78Ti / CY4D47Ti / CY4D43Ti
Number of cylinders: 4 / 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 4.752 / 4.751 / 7.79 / 4.334L
Emission standard: China IV / China III / Euro III / China II/Euro II
Max output power: 128 / 85 / 118 / 125 / 120 / 115 / 180 / 110kW
Max hp: 175 / 115 / 160 / 170 / 163 / 156 / 245 / 150Horsepower
Max torque: 550 / 420 / 450 / 585 / 520 / 830 / 580 / 460N·m
Max torque speed: 1300-1500 / 1400-1600 / 1300-1600 / 1400 / 1500rpm
Rated speed: 2600 / 2200 / 2300 / 2400rpm
Engine Type: Vertical inline water-cooled 4-stroke, turbocharged intercooled, electronically controlled high-pressure common rail, DOC+POC / Vertical, inline, water-cooled, four-stroke / Vertical inline, water-cooled, four-stroke, turbocharged intercooled / Vertical in-line, water-cooled, 4-stroke, turbocharged & intercooled / Vertical inline, water-cooled, 4-stroke, turbocharged intercooled
FAQ
What kind of truck is Chaochai Chaochai CYD Series engine?
Chaochai Chaochai CYD Series is an export-oriented engine lineup with about 13 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Chaochai CYD Series engine cover?
Chaochai CYD Series engine mainly covers: Horsepower: 115 hp / 160 hp / 170 hp / 175 hp; Emission: China III / Euro III / China IV; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Chaochai CYD Series engine?
For Chaochai CYD Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Chaochai CYD Series engine include?
Chaochai CYD Series engine currently lists about 13 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Chaochai CYD Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
