Dongfeng ISDe200 40 200hp 4.5L China IV Diesel Engine
EXW
Export quote
Dongfeng ISDe4.5 Series engine
Main model photos
6 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng ISDe200 40 200hp 4.5L China IV Diesel Engine | 200hp / China IV | ||
| Dongfeng ISDe160 40 160hp 4.5L China IV Diesel Engine | 160hp / China IV | ||
| Dongfeng ISDe140 40 140 hp 4.5L China IV Diesel Engine | 140hp / China IV | ||
| Dongfeng ISDe180 30 180hp 4.5L China III Diesel Engine | 180hp | ||
| Dongfeng ISDe160 30 (600NM) 160hp 4.5L China III Diesel Engine | 160hp / China III / Euro III |
Dongfeng ISDe160 40 160hp 4.5L China IV Diesel Engine
EXW
Export quote
Dongfeng ISDe140 40 140 hp 4.5L China IV Diesel Engine
EXW
Export quote
Dongfeng ISDe180 30 180hp 4.5L China III Diesel Engine
EXW
Export quote
Dongfeng ISDe160 30 (600NM) 160hp 4.5L China III Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: ISDe4.5 Series
Engine manufacturer: Dongfeng Engine Co., Ltd. / Dongfeng
Suitable Range: Truck engine / For Trucks
Intake type: Turbocharged Air-to-Air Intercooling
Min. fuel consumption at full load: 195g/kW.h
Engine net weight: 366 / 350kg
Engine Dimensions: 810*720*820 / 901X723X819mm
Compression ratio: 17.3:1 / 17.3：1 / 17.3
Bore × Stroke: 107x124mm
Valves per cylinder: 4pcs
firing order: 1-3-2-4
Engine Brand: Dongfeng
Engine Model: ISDe200 40 / ISDe160 40 / ISDe140 40 / ISDe180 30 / ISDe160 30(600NM) / ISDe140 30
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 4.5L
Emission standard: China IV / China III / Euro III
Max output power: 140 / 118 / 103 / 132kW
Max hp: 200 / 160 / 140 / 180Horsepower
Max torque: 740 / 600 / 550 / 650 / 450N·m
Max torque speed: 1400rpm
Rated speed: 2500rpm
Engine Type: Electronically controlled / Inline / Inline 4-cylinder, electronic control system, enhanced high-pressure common rail, particulate filter / Inline, electronic control system, enhanced high-pressure common rail, particulate filter
FAQ
What kind of truck is Dongfeng Dongfeng ISDe4.5 Series engine?
Dongfeng Dongfeng ISDe4.5 Series is an export-oriented engine lineup with about 6 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Dongfeng ISDe4.5 Series engine cover?
Dongfeng ISDe4.5 Series engine mainly covers: Horsepower: 140 hp / 160 hp / 180 hp / 200 hp; Emission: China III / Euro III / China IV; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dongfeng ISDe4.5 Series engine?
For Dongfeng ISDe4.5 Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Dongfeng ISDe4.5 Series engine include?
Dongfeng ISDe4.5 Series engine currently lists about 6 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng ISDe4.5 Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
