FAW Jiefang J6L 320hp 8X4(12 wheels) Oil Tank Truck (Chengliwei brand)
EXW
From $72,222
Export quote
Chengliwei FAW Jiefang chassis fuel tanker truck
Main model photos
121 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Jiefang J6L 320hp 8X4(12 wheels) Oil Tank Truck (Chengliwei brand) | 8x4 / 320hp / China V | From $72,222 | |
| FAW Jiefang J6L 190 hp 4X2(6 wheels) Oil Tanker Truck (Chengliwei Brand) | 4x2 / 180hp / China V | From $30,944 | |
| FAW Jiefang J6M 260hp 6X4(10 wheels) Fuel Tank Truck (Chengliwei Brand) | 6x4 / 260hp / China V | From $40,611 | |
| FAW Jiefang J6L 220hp 6X2(8 wheels) Fuel Tank Truck (Chengliwei Brand) | 6x2 / 220hp / China V | From $30,347 | |
| FAW Jiefang J6L 220hp 6X2(8 wheels) Fuel Tank Truck (Chengliwei Brand) | 6x2 / 220hp / China V | From $30,347 |
FAW Jiefang J6L 190 hp 4X2(6 wheels) Oil Tanker Truck (Chengliwei Brand)
EXW
From $30,944
Export quote
FAW Jiefang J6M 260hp 6X4(10 wheels) Fuel Tank Truck (Chengliwei Brand)
EXW
From $40,611
Export quote
FAW Jiefang J6L 220hp 6X2(8 wheels) Fuel Tank Truck (Chengliwei Brand)
EXW
From $30,347
Export quote
FAW Jiefang J6L 220hp 6X2(8 wheels) Fuel Tank Truck (Chengliwei Brand)
EXW
From $30,347
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Jiefang J6M 324 hp 8X4(12 wheels) Flammable Liquid Tanker Truck (Chengliwei Brand) | 8x4 / 320hp / China IV |
Series Specs
Basic Info
Cab dimensions: 11.76×2.5×3.505 / 8.45×2.5×3.2 / 10.16×2.5×3.505 / 10.35×2.5×3.35 / 10.7×2.5×3.3 / 8.45×2.48×3.15 / 8.5×2.5×3.15 / 11.72×2.5×3.505 / 11.9×2.5×3.454m
Drive type: 8X4 / 4X2 / 6X4 / 6X2 / 8X2
Truck Type: Fuel tanker truck / aluminum fuel tanker truck
Wheelbase: 1950+4550+1350 / 4700 / 4800+1350 / 1900+4700 / 1950+4250+1350mm
Vehicle origin: Suizhou, Hubei
Front track width: 1987/1987 / 1890 / 1987 / 1890/1890 / 1950/1950mm
rear track: 1860/1860 / 1860 / 1880/1880 / 1847 / 1800 / 1860,1878 / 1946/1847 / 1847/1847mm
Curb Weight: 10.805 / 8.3 / 11.52 / 8.205 / 9.905 / 5.985 / 7.9 / 6.65 / 12.805 / 13.105ton
Rated payload: 21.065 / 9.805 / 13.285 / 16.12 / 14.42 / 9.82 / 7.905 / 11.155 / 18 / 17.7 / 16.91ton
Max. speed: 79km/h
Front/rear suspension: 1.46/2.45 / 1.4/2.35 / 1.46/2.55 / 1.4/2.7 / 1.4/2.4 / 1.46/2.71 / 1.400/2.650m
Energy Type: Diesel
Body Parameters
Tank Size: 8.75×2.48×1.78 / 5.5×2.35×1.6 / 7.15×2.35×1.65 / 7.7×2.48×1.88 / 7.9×2.4×1.62 / 5.8×2.25×1.5 / 5.6×2.17×1.44m
Tank Volume: 31.5 / 14.7 / 19.9 / 24.1 / 21.6 / 11.8 / 14.1 / 22.7 / 26.5m3
Transport medium: gasoline
Medium Density: 0.7ton/cubic meter
Vehicle certification code: CLW5320GYYC5 / CLW5180GJYC5 / CLW5251GYYC5 / CLW5251GYYLC5 / CLW5250GYYC5 / CLW5161GYYLC5 / CLW5163GYYC5 / CLW5180GYYLC5 / CLW5312GYYC5 / CLW5311GYYC5 / CLW5311GYYP63K2L6T4A2E4
Body Brand: Chengliwei
Engine parameters
Engine Brand: Dachai / Xichai
Engine Model: DachaiCA6DK1-32E51 / DachaiCA4DK1-18E51 / DachaiCA6DK1-26E5 / DachaiCA4DK1-22E51 / DachaiBF6M2012-18E5 / DachaiCA6DK1-28E5 / Xichai CA6DL1-32E4
Number of cylinders: 6 / 4cylinder
Displacement: 7.146 / 4.764 / 6.06 / 7.7L
Emission standard: China V / China IV
Max output power: 239 / 139 / 195 / 165 / 209 / 238kW
Max hp: 320 / 180 / 260 / 220 / 280Horsepower
Max torque: 1200 / 720 / 1050 / 820 / 1100 / 1250N·m
Max torque speed: 1200-1700 / 1300-1700rpm
Rated speed: 2300 / 1500 / 1900rpm
Engine Type: 6-cylinder inline, direct injection, turbocharged intercooled, electronic common rail / SCR / Electronically controlled / Common Rail+SCR / Turbocharged intercooled, direct injection, inline, electronic common rail
Chassis Specs
Chassis Brand: FAW Jiefang
Chassis Series: J6L / FAW JiefangJ6M / FAW JiefangJ6L
Chassis Model: CA5320GYYP63K1L6T4E5 / CA5180GYYP62K1L5E5 / CA5250GYYP63K1L3T1E5 / CA5250GYYP62K1L6T3E5 / CA5160GYYP62K1L3E5 / CA5310GYYP63K1L6T10E5 / CA5310GYYP63K2L6T4A2E4
Front axle description: 1950 / 1800
Frame Dimensions: 270×75×(7+5) / 237×75×(7+4)mm
rear axle description: Ф435 stamped-welded axle / 457 axle (auto adjust arm, imported ABS)
Axle ratio: 4.875 / 5.143 / 4.111
Leaf spring count: 3/3/- / 3/- / 10/4;11/4 / 11/13/13+7,11/11/13+7,11/11/4+-,7/7/4+- / 10/12+8,7/10+3,7/7+6 / 10/12+8 / 7/10+3 / 3/3/5+-/10+9 / 3/3/11,10/10/11
Transmission Parameters
Number of gears: 8 / 9 / 6 / 10Gear
Transmission Model: FAW Jiefang 8-speed / FAWCA9TB160M / FAWCA6T138 / 8-speed gearbox / CA10TA130M
Cab parameters
Cab: J6M Semi-Float Flat Roof Small Day Cab / J6L Semi-floating Flat Roof Short Extended Cab / 2017 Model J6L Semi-Float Flat-Roof Small Half-Row Cab
FAQ
What kind of truck is Chengliwei Chengliwei FAW Jiefang chassis fuel tanker truck?
Chengliwei Chengliwei FAW Jiefang chassis is an export-oriented fuel tanker truck lineup with about 12 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Chengliwei FAW Jiefang chassis fuel tanker truck?
Chengliwei FAW Jiefang chassis fuel tanker truck export reference is about $21,944 – $72,222. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Chengliwei FAW Jiefang chassis fuel tanker truck cover?
Chengliwei FAW Jiefang chassis fuel tanker truck mainly covers: Drive: 4x2 / 6x2 / 6x4 / 8x4; Horsepower: 180 hp / 220 hp / 260 hp / 320 hp; Emission: China IV / China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Chengliwei FAW Jiefang chassis fuel tanker truck?
For Chengliwei FAW Jiefang chassis fuel tanker truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is fuel tanker truck typically used for?
fuel tanker truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Chengliwei FAW Jiefang chassis fuel tanker truck include?
Chengliwei FAW Jiefang chassis fuel tanker truck currently lists about 12 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Chengliwei FAW Jiefang chassis fuel tanker truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
