SHACMAN Commercial Vehicle Xuande X3 Heavy Truck 350 hp 8X4(12 wheels) 9.5m Flatbed Cargo Truck
EXW
Export quote
SHACMAN Commercial Vehicle SHACMAN Xuande X3
Main model photos
184 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SHACMAN Commercial Vehicle Xuande X3 Heavy Truck 350 hp 8X4(12 wheels) 9.5m Flatbed Cargo Truck | 8x4 / 350hp / China V | ||
| SHACMAN Commercial Vehicle Xuande X3 Heavy Truck Lightweight Edition 270 hp 4X2(6 wheels) 9.5m Van Cargo Truck | 4x2 / 270hp / China V | From $40,583 | |
| SHACMAN Commercial Vehicle Xuande X3 heavy truck Composite Edition 385 hp 8X4(12 wheels) 9.5m cage cargo truck | 8x4 / 385hp / China V | From $48,153 | |
| SHACMAN Commercial Vehicle Xuande X3 Heavy Truck Lightweight Version 270 hp 6X2(8 wheels) 9.5m Box Cargo Truck (MAN Rear Axle) | 6x2 / 270hp / China V | From $41,972 | |
| SHACMAN Commercial Vehicle Xuande X3 Heavy Truck Lightweight Edition 270 hp 6X2(8 wheels) 7.8m Van Cargo Truck (MAN rear axle) | 6x2 / 270hp / China V | From $41,694 |
SHACMAN Commercial Vehicle Xuande X3 Heavy Truck Lightweight Edition 270 hp 4X2(6 wheels) 9.5m Van Cargo Truck
EXW
From $40,583
Export quote
SHACMAN Commercial Vehicle Xuande X3 heavy truck Composite Edition 385 hp 8X4(12 wheels) 9.5m cage cargo truck
EXW
From $48,153
Export quote
SHACMAN Commercial Vehicle Xuande X3 Heavy Truck Lightweight Version 270 hp 6X2(8 wheels) 9.5m Box Cargo Truck (MAN Rear Axle)
EXW
From $41,972
Export quote
SHACMAN Commercial Vehicle Xuande X3 Heavy Truck Lightweight Edition 270 hp 6X2(8 wheels) 7.8m Van Cargo Truck (MAN rear axle)
EXW
From $41,694
Export quote
Series Specs
Basic Info
Model code (announced): SX1310MP5 / SX5180XXYMP5 / SX5310CCYMP5 / SX5250XXYMP5 / SX5250CCYMP5 / SX1250MP5 / SX5250XYKMP5
Type: Cargo Trucks / enclosed cargo truck / stake truck
Drive type: 8X4 / 4X2 / 6X2
Wheelbase: 1800+4700+1300 / 7475 / 1800+4700+1350 / 1800+5400 / 1800+4600mm
Box length class: 9.5 / 7.8m
Engine Model: YuchaiYC6L350-50 / DongfengISD270 50 / Xi’an CumminsISM11E5 385 / DongfengISD245 50 / WeichaiWP7.270E51 / WeichaiWP6.245E50 / YuchaiYC6A270-50 / YuchaiYC6J245-52
Transmission Model: Fast Gear12JSD160TA / Fast Gear9JS119TB / Fast Gear12JSD180TA
Rear Axle Ratio: 4.44 / 4.111 / 4.11 / 3.364
Cab length: 12 / 11.89 / 10.1 / 11.2 / 10.4 / 10.14m
Cab width: 2.5 / 2.55 / 2.22 / 2240m
Cab height: 3.36 / 3.995 / 3.95 / 3.65 / 3.99 / 3.1m
Front track width: 2011/2011 / 2011 / 2023/2023mm
rear track: 1860/1860 / 1860mm
Curb Weight: 12.6 / 8.87 / 13.2 / 10.9 / 10.3 / 11.5 / 9.9 / 11.89ton
Rated payload: 18.27 / 9 / 17.67 / 13.97 / 14.57 / 14.97 / 13.37 / 14.505 / 14.905ton
GVWR: 31 / 18 / 25ton
Max. speed: 95 / 100km/h
Origin: Baoji, Shaanxi / Baoji
tonnage class: Heavy-duty cargo trucks
Approach angle: 23°
departure angle: 12°
market segment: General dry cargo / Express & Freight / Agricultural product transport, green channel / LTL transport / Agricultural and sideline product transport / Daily industrial goods transport / Building material transport / Building materials, green channel / Green Pass / Logistics, LTL, General Cargo, Green Channel / LTL transport, daily bulk cargo, urban distribution, green channel / Daily industrial goods transport, LTL transport, daily bulk cargo, green channel
Remarks: Optional cab X3 extended semi-high roof. / Standard: Cab: TJG161(G/2240) four-point airbag suspension, air-suspension seat, A/C, sun visor, central door lock, Tianxingjian Zhiya Edition BD telematics terminal. Cab color: Pearl Molybdenum Red. Brakes: aluminum air tanks, domestic 4-channel ABS. Overspeed alarm (100km/h), ECU reads vehicle code, brake test connector, right-turn voice alert, load distribution label. Optional: Cab: TJG161(H/2240), four-point mechanical suspension, electric tilt, wind deflector [available with cab TJG161(H/2240)], power-adjustable/heated rearview mirrors. Cab colors: Space Blue, Pearl White, Blazing Gold, Coffee Gold. Fuel tank: 600L aluminum alloy tank. Tires: 11.00R20. Tianxingjian Zhixing Edition, disc front axle with brake pad wear alarm. / Standard: Tianxingjian Zhiya BD vehicle terminal, ECU reads VIN, brake test connector, right-turn voice alert, load placement label. Optional: 600L aluminum fuel tank; tires 11.00R20, four-point mechanical suspension, electric tilting / Optional 9JS119TA transmission, standard: Tianxingjian Zhiya Edition BD onboard terminal, ECU reads vehicle code, brake test connector, right-turn voice alert, load layout label. Optional: 600L aluminum fuel tank; tires 11.00R20, four-point mechanical suspension, electric tilt
Front/rear suspension: 1.54/2.61 / 1.54/2.985 / 1.51/2.1 / 1.54/2.1 / 1.512/2.583m
Version: Lightweight version / composite version
Energy Type: Diesel
Engine parameters
Engine Brand: Yuchai / Dongfeng / Xi’an Cummins / Weichai
Engine info: Yuchai8.4L / Dongkang 6.7L / Xikang 11L / WeichaiWP7 / WeichaiWP6 / Yuchai7.5 / Yuchai7.5L / Yuchai6.5L
Number of cylinders: 6cylinder
Cylinder arrangement: Inline
Displacement: 8.424 / 6.7 / 10.8 / 7.47 / 6.75 / 7.52 / 6.494L
Emission standard: China V
Max output power: 257 / 198 / 283 / 180 / 199kW
Max hp: 350 / 270 / 385 / 245Horsepower
Max torque: 1400 / 970 / 1900 / 950 / 1160 / 900 / 1100N·m
Max torque speed: 1200-1700 / 1100-1300 / 1200-1800 / 1200-1600rpm
Rated speed: 2200 / 2500 / 1900 / 2300rpm
Engine Type: Vertical, inline, water-cooled, four-stroke / SCR / Full electronic control / Water-cooled, electronic high-pressure common rail, turbocharged intercooled, SCR / Inline 6-cylinder, electronic high-pressure common rail, SCR / Inline, 4-stroke, water-cooled, wet cylinder liner, turbocharged intercooled / Vertical, inline 6-cylinder, water-cooled, 4-stroke, electronic direct injection
Technology route: Common Rail
Transmission Parameters
Transmission Brand: Fast Gear
FAQ
What kind of truck is SHACMAN Commercial Vehicle SHACMAN Xuande X3 Quasi-Heavy Truck Cargo Trucks?
SHACMAN Commercial Vehicle SHACMAN Xuande X3 Quasi-Heavy Truck is an export-oriented Cargo Trucks lineup with about 260 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for SHACMAN Commercial Vehicle SHACMAN Xuande X3?
SHACMAN Commercial Vehicle SHACMAN Xuande X3 export reference is about $28,222 – $48,153. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does SHACMAN Commercial Vehicle SHACMAN Xuande X3 cover?
SHACMAN Commercial Vehicle SHACMAN Xuande X3 mainly covers: Drive: 4x2 / 6x2 / 8x4; Horsepower: 270 hp / 350 hp / 385 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SHACMAN Commercial Vehicle SHACMAN Xuande X3?
For SHACMAN Commercial Vehicle SHACMAN Xuande X3: 1) set emission; 2) match body/wheelbase to cargo type; 3) pick drive and horsepower; 4) compare prices, then open a model to quote.
What is Cargo Trucks typically used for?
Cargo Trucks covers box, stake or flatbed cargo work from city delivery to regional haul. Filter by body and payload needs.
How many models does SHACMAN Commercial Vehicle SHACMAN Xuande X3 include?
SHACMAN Commercial Vehicle SHACMAN Xuande X3 currently lists about 260 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SHACMAN Commercial Vehicle SHACMAN Xuande X3?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
