JAC Kangling H3 132hp 4X2(6 wheels) 4.03m Single Row Refrigerated Truck (China VI)
EXW
From $18,028
Export quote
JAC H3 light truck Refrigerated Truck
Main model photos
119 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| JAC Kangling H3 132hp 4X2(6 wheels) 4.03m Single Row Refrigerated Truck (China VI) | 4x2 / 132hp / China VI | From $18,028 | |
| JAC Kangling H3 95hp 4X2(6 wheels) 3.37m Crew Cab Refrigerated Truck (China VI) | 4x2 / 95hp / China VI | From $16,986 | |
| JAC Kangling H3 95hp 4X2(6 wheels) 3.7m Single Row Refrigerated Truck (China VI) | 4x2 / 95hp / China VI | From $16,847 |
JAC Kangling H3 95hp 4X2(6 wheels) 3.37m Crew Cab Refrigerated Truck (China VI)
EXW
From $16,986
Export quote
JAC Kangling H3 95hp 4X2(6 wheels) 3.7m Single Row Refrigerated Truck (China VI)
EXW
From $16,847
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| JAC Kangling H3 130 hp 4X2(6 wheels) 4.03m single-row refrigerated truck (China VI) | 4x2 / 130hp / China VI | From $12,194 |
JAC Kangling H3 130 hp 4X2(6 wheels) 4.03m single-row refrigerated truck (China VI)
EXW
From $12,194
Export quote
Series Specs
Basic Info
Cab dimensions: 5.995×2.04×2.92 / 5.475×1.975×2.8 / 5.995×2.13×3.02m
Truck Type: Refrigerated Truck
Drive type: 4X2
Wheelbase: 3365 / 2850mm
Vehicle origin: Hefei, Anhui
Front track width: 1455 / 1470mm
rear track: 1425 / 1395 / 1470mm
Curb Weight: 3.21ton
Rated payload: 1.155ton
GVWR: 4.495ton
Max. speed: 100km/h
Remarks: Optional: 100L plastic fuel tank, 2010mm wide cargo box, checkered plate, 6.50R16LT 8PR tubeless tires. / Optional: 100L plastic fuel tank, 1900mm wide cargo box, checkered plate, dual battery.
Front/rear suspension: 1.1/1.53 / 1.1/1.525m
Energy Type: Diesel
Engine parameters
Engine Model: QuanchaiQ23-132E60 / QuanchaiQ23-95E60 / JACHFC4DB3-2E
Number of cylinders: 4cylinder
Displacement: 2.3 / 2.183L
Emission standard: China VI
Max output power: 97 / 70 / 95kW
Max hp: 132 / 95 / 130Horsepower
Max torque: 320 / 240N·m
Rated speed: 3000 / 3200rpm
Engine Type: Common Rail
Cargo box parameters
Cargo box dimensions: 4.03×1.81×1.8 / 3.37×1.81×1.85 / 3.7×1.81×1.85 / 4.03×1.9×1.9m
Cargo box width: 1.81 / 1.9m
Cargo box height: 1.8 / 1.85 / 1.9m
Body Parameters
Vehicle certification code: HFC5041XLCP23K1C7S / HFC5041XLCP23K1B4S
Body Brand: JAC
Chassis Specs
Chassis Brand: JAC
Chassis Series: Kangling H3
Chassis Model: HFC1041P23K1C7S / HFC1041P23K1B4S
Front axle description: 2T
Frame Dimensions: 180*65*4.5 / 140*55*5mm
rear axle description: 4T / 3T
Axle ratio: 4.875
Leaf spring count: 4/5+6,4/4+2 / 4/5+3 / 4/5+6
Transmission Parameters
Number of gears: 5Gear
Transmission Model: Xingrui LC5T28B
Cab parameters
Cab: Single Row / Sleeper cab
fuel tank
Fuel tank capacity: 120 / 85L
FAQ
What kind of truck is JAC JAC H3 light truck Refrigerated Truck?
JAC JAC H3 light truck is an export-oriented Refrigerated Truck lineup with about 4 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for JAC H3 light truck Refrigerated Truck?
JAC H3 light truck Refrigerated Truck export reference is about $12,194 – $18,028. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does JAC H3 light truck Refrigerated Truck cover?
JAC H3 light truck Refrigerated Truck mainly covers: Drive: 4x2; Horsepower: 95 hp / 130 hp / 132 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in JAC H3 light truck Refrigerated Truck?
For JAC H3 light truck Refrigerated Truck: 1) set emission; 2) match body/wheelbase to cargo type; 3) pick drive and horsepower; 4) compare prices, then open a model to quote.
What is Refrigerated Truck typically used for?
Refrigerated Truck covers box, stake or flatbed cargo work from city delivery to regional haul. Filter by body and payload needs.
How many models does JAC H3 light truck Refrigerated Truck include?
JAC H3 light truck Refrigerated Truck currently lists about 4 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for JAC H3 light truck Refrigerated Truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
