SHACMAN Light Truck Xuelong Delong K1 Comfort 170hp 4X2(6 wheels) 4.08m Refrigerated Truck
EXW
Export quote
SHACMAN Light Truck SHACMAN Xuelong Delong K1
Main model photos
87 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SHACMAN Light Truck Xuelong Delong K1 Comfort 170hp 4X2(6 wheels) 4.08m Refrigerated Truck | 4x2 / 170hp / China VI | ||
| SHACMAN Light Truck Xuelong Delong K1 Comfort 170hp 4X2(6 wheels) 4.08m Refrigerated Truck | 4x2 / 170hp / China VI | ||
| SHACMAN Light Truck Delong K1 Luxury 160hp 4X2(6 wheels) 4.8m Refrigerated Truck | 4x2 / 160hp / China VI | From $22,417 | |
| SHACMAN Light Truck Delong K1 Luxury 160hp 4X2(6 wheels) 5.1m Refrigerated Truck | 4x2 / 160hp / China VI | From $22,208 | |
| SHACMAN Light Truck Delong K1 Basic 160hp 4X2(6 wheels) 4.8m Refrigerated Truck | 4x2 / 160hp / China VI | From $22,083 |
SHACMAN Light Truck Xuelong Delong K1 Comfort 170hp 4X2(6 wheels) 4.08m Refrigerated Truck
EXW
Export quote
SHACMAN Light Truck Delong K1 Luxury 160hp 4X2(6 wheels) 4.8m Refrigerated Truck
EXW
From $22,417
Export quote
SHACMAN Light Truck Delong K1 Luxury 160hp 4X2(6 wheels) 5.1m Refrigerated Truck
EXW
From $22,208
Export quote
SHACMAN Light Truck Delong K1 Basic 160hp 4X2(6 wheels) 4.8m Refrigerated Truck
EXW
From $22,083
Export quote
Series Specs
Basic Info
Cab dimensions: 5.995×2.26×3.155 / 7.045×2.55×3.59 / 5.995×2.26×3.255 / 5.995×2.26×2.955m
Drive type: 4X2
Truck Type: Refrigerated Truck
Wheelbase: 3300 / 3800mm
Vehicle origin: Shandong Yantai / Laiyang, Shandong
Front track width: 1701 / 1796 / 1736 / 1585mm
rear track: 1670 / 1795 / 1700mm
Curb Weight: 3.2 / 6.065ton
Rated payload: 1.1 / 4.94 / 1.165ton
GVWR: 4.495 / 11.2ton
Max. speed: 95km/h
Remarks: Standard: ventilated/heated comfort seat; Optional: Fast Gear 8JS75TE-C transmission, 350L aluminum fuel tank / Option: Fast Gear 8JS75TE-C transmission, 350L aluminum alloy fuel tank / Standard: Metallic paint, K5000 full-enclosed cab, overhead storage box, insect screen, cornering auxiliary light, 7-inch premium LCD combo instrument, 80Ah maintenance-free battery (no anti-theft), mechanical master power switch, reverse buzzer, electric horn, air horn, domestic brake valve, spring energy storage parking, spare tire, high-strength steel rim, standard steel mudguard bracket, aluminum rear underrun protection, aluminum side guard, manual parking brake, 2.0T Hande disc maintenance-free, rear stabilizer bar; Optional: Fast Gear C8J45TA transmission, 3.5T (rated 6T)/4.875 Hande maintenance-free wide-track rear axle, 3/8+6 leaf springs, T-box (for Beijing), ETC (wired). / Standard: Metallic paint, K5000 full-enclosed cab, overhead storage box, insect screen, cornering auxiliary light, 7-inch premium LCD combo instrument, 80Ah maintenance-free battery (no anti-theft), mechanical master power switch, reverse buzzer, electric horn, air horn, domestic brake valve, spring energy storage parking, spare tire, high-strength steel rim, standard steel mudguard bracket, aluminum rear underrun protection, aluminum side guard, manual parking brake; Optional: Fast Gear C8J45TA transmission, 3.5T (rated 6T)/4.875 Hande maintenance-free wide-track rear axle, 3/8+6 leaf springs, T-box (for Beijing), ETC (wired). / Standard: Metallic paint, full-enclosed cab, insect screen, mechanical master power switch, reverse buzzer, electric horn, air horn, spring energy storage parking, high-strength steel rim, aluminum mudguard bracket, aluminum rear underrun protection, aluminum side guard, EPB (electronic parking brake), exhaust auxiliary brake, rear stabilizer bar, ESC+ASR, 20Ah iron-lithium battery; Optional: 4.333 ratio, leaf spring count 3/5+2, ETC (wired), 150L aluminum alloy fuel tank. / Standard: Metallic paint, K5000 full-enclosed cab, rear stabilizer bar, overhead storage box, insect screen, cornering auxiliary light, 7-inch premium LCD combo instrument, 80Ah maintenance-free battery (no anti-theft), mechanical master power switch, reverse buzzer, electric horn, air horn, domestic brake valve, spring energy storage parking, spare tire, high-strength steel rim, standard steel mudguard bracket, aluminum rear underrun protection, aluminum side guard, manual parking brake; Optional: Fast Gear C8J45TA transmission, 3.5T (rated 5T)/4.333 Hande maintenance-free wide-track rear axle, 3/5+2 leaf springs, 150L aluminum alloy fuel tank, T-box (for Beijing), ETC (wired). / Standard: Metallic paint, full-enclosed cab, insect screen, mechanical battery master switch, reverse buzzer, electric horn, air horn, spring brake parking, high-strength steel rim, standard steel mudguard bracket, aluminum rear underrun guard, aluminum side guard, EPB (electronic parking brake), exhaust brake, rear stabilizer bar, ESC+ASR; Optional: 4.333 ratio, leaf spring 3/5+2, ETC (wired), 150L aluminum fuel tank. / Standard: Metallic paint, full-enclosed cab, insect screen, mechanical battery master switch, reverse buzzer, electric horn, air horn, spring brake parking, high-strength steel rim, standard steel mudguard bracket, aluminum rear underrun guard, aluminum side guard, EPB (electronic parking brake), exhaust brake, rear stabilizer bar; Optional: 4.333 ratio, leaf spring 3/5+2, ETC (wired), 150L aluminum fuel tank. / Standard: Metallic paint, full-enclosed cab, insect screen, mechanical battery master switch, reverse buzzer, electric horn, air horn, spring brake parking, high-strength steel rim, standard steel mudguard bracket, aluminum rear underrun guard, aluminum side guard, EPB (electronic parking brake); Optional: 4.333 ratio, leaf spring 3/5+2, ETC (wired), 150L aluminum fuel tank. / Standard: Metallic paint, K5000 full-enclosed cab, overhead storage box, insect screen, cornering auxiliary light, 7-inch premium LCD combo instrument, 80Ah maintenance-free battery (no anti-theft), mechanical master power switch, reverse buzzer, electric horn, air horn, domestic brake valve, spring energy storage parking, spare tire, high-strength steel rim, standard steel mudguard bracket, aluminum rear underrun protection, aluminum side guard, manual parking brake; Optional: Fast Gear C8J45TA transmission, 3.5T (rated 5T)/4.333 Hande maintenance-free wide-track rear axle, 3/5+2 leaf springs, 150L aluminum alloy fuel tank, T-box (for Beijing), ETC (wired). / Standard: Metallic paint, full-enclosed cab, overhead storage box, insect screen, air-suspension seat, dual USB fast-charge power, cornering light, 7-inch premium LCD cluster, 80AH maintenance-free battery (no anti-theft), mechanical master switch, reverse buzzer, electric horn, air horn, domestic brake valve, spring energy storage parking, spare tire, high-strength steel rim, standard steel driveshaft, standard steel fender bracket, aluminum rear underrun guard, aluminum side guard, T-box, 2.0T Hande disc front axle, rear stabilizer bar; Optional: ratio 4.333, 3/5+2 leaf spring, 150L aluminum fuel tank, ETC (wired) / Standard: Metallic paint, full-enclosed cab, insect screen, mechanical battery master switch, reverse buzzer, electric horn, air horn, high-strength steel rim, aluminum driveshaft, aluminum mudguard bracket, aluminum rear underrun guard, aluminum side guard, EPB (electronic parking brake), exhaust brake, rear stabilizer bar, LED headlights, ESC+ASR, 20Ah LiFePO4 battery; Optional: 4.333 ratio, leaf spring 3/5+2, ETC (wired), 150L aluminum fuel tank. / Standard: Metallic paint, full-enclosed cab, insect screen, mechanical battery master switch, reverse buzzer, electric horn, air horn, high-strength steel rim, standard steel driveshaft, standard steel mudguard bracket, aluminum rear underrun guard, aluminum side guard, EPB (electronic parking brake), exhaust brake, rear stabilizer bar, LED headlights, ESC+ASR; Optional: 4.333 ratio, leaf spring 3/5+2, ETC (wired), 150L aluminum fuel tank.
Front/rear suspension: 1.13/1.565 / 1.13/2.115 / 1.13/1.535m
Energy Type: Diesel
Engine parameters
Engine Model: WeichaiWP2.5NQ170E62 / WeichaiWP3NQ160E61 / WeichaiWP2.5NQ160E61 / WeichaiWP2.5NQ150E61 / WeichaiWP2.3NQ130E61
Number of cylinders: 4cylinder
Displacement: 2.493 / 2.97 / 2.49 / 2.29L
Emission standard: China VI
Max output power: 125 / 118 / 110 / 96kW
Max hp: 170 / 160 / 150 / 130Horsepower
Max torque: 480 / 450 / 380N·m
Rated speed: 3000 / 2900 / 3200rpm
Engine Type: Inline, direct injection, water-cooled, 4-stroke, turbocharged, intercooled, electronically controlled high-pressure common rail / High-pressure common rail / 4-valve, high-pressure common rail, turbocharged intercooled
Cargo box parameters
Cargo box dimensions: 4.08×2.1×2.1 / 4.8×2.3×2.2 / 5.1×2.3×2.2 / 3.7×2.1×2.1m
Cargo box width: 2.1 / 2.3m
Cargo box height: 2.1 / 2.2m
Body Parameters
Vehicle certification code: YTQ5041XLCKH331 / YTQ5041XLCKJ336 / YTQ5111XLCKK422
Body Brand: SHACMAN Light Truck
Chassis Specs
Chassis Brand: SHACMAN Light Truck
Chassis Series: Xuelong Delong K1 / Delong K1 / Jindelong K1
Chassis Model: YTQ1041KH331 / YTQ1041KJ331 / YTQ1111KK422
Front axle description: 2.4T Hande maintenance-free front axle / 2.0T Hande maintenance-free wide track front axle / 2.0T Hande maintenance-free front axle / 2.0T Hande disc front axle / 2.0T Hande maintenance-free
Frame Dimensions: 865×193 straight-through beam / 800x180 straight-through beam / 800×180 straight beammm
rear axle description: Rated load 7T Hande maintenance-free rear axle / Rated 6T Hande maintenance-free wide wheelbase rear axle / Rated 6T Hande maintenance-free / 5T rated Hande maintenance-free wide-track rear axle / 3.5T (rated 6T) Hande maintenance-free wide-track rear axle / 3.5T (rated 5T) Hande maintenance-free rear axle / 3.5T (rated 5T) Hande maintenance-free wide-track rear axle / 3.5T (rated 5T) Hande maintenance-free
Axle ratio: 4.875 / 4.333
Leaf spring count: 10/9+7 / 3/8+6 / 3/5+3 / 3/3+2
Transmission Parameters
Number of gears: 8 / 6Gear
Transmission Model: Fast GearC8J50TA / Fast GearC6J50T / Fast GearC8J45TA / Fast GearC6J45TB / Fast GearF6JZ45BM
Cab parameters
Cab: Wide-body single cab / Wide-body Extended Cab / Sleeper cab / Single Row / Wide-body single cab with half bed
fuel tank
Fuel tank capacity: 150 / 120L
FAQ
What kind of truck is SHACMAN Light Truck SHACMAN Xuelong Delong K1 Refrigerated Truck?
SHACMAN Light Truck SHACMAN Xuelong Delong K1 is an export-oriented Refrigerated Truck lineup with about 76 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for SHACMAN Light Truck SHACMAN Xuelong Delong K1?
SHACMAN Light Truck SHACMAN Xuelong Delong K1 export reference is about $16,250 – $22,417. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does SHACMAN Light Truck SHACMAN Xuelong Delong K1 cover?
SHACMAN Light Truck SHACMAN Xuelong Delong K1 mainly covers: Drive: 4x2; Horsepower: 160 hp / 170 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SHACMAN Light Truck SHACMAN Xuelong Delong K1?
For SHACMAN Light Truck SHACMAN Xuelong Delong K1: 1) set emission; 2) match body/wheelbase to cargo type; 3) pick drive and horsepower; 4) compare prices, then open a model to quote.
What is Refrigerated Truck typically used for?
Refrigerated Truck covers box, stake or flatbed cargo work from city delivery to regional haul. Filter by body and payload needs.
How many models does SHACMAN Light Truck SHACMAN Xuelong Delong K1 include?
SHACMAN Light Truck SHACMAN Xuelong Delong K1 currently lists about 76 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SHACMAN Light Truck SHACMAN Xuelong Delong K1?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
