Dongfeng FuruiKa R5 156 hp 4X2(6 wheels) Kitchen Waste Garbage Truck (Chengliwei Brand)
EXW
From $22,639
Export quote
Chengliwei Dongfeng Chassis garbage truck
Main model photos
111 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng FuruiKa R5 156 hp 4X2(6 wheels) Kitchen Waste Garbage Truck (Chengliwei Brand) | 4x2 / 156hp / China VI | From $22,639 | |
| Dongfeng FuruiKa R5 170 hp 4X2(6 wheels) Kitchen Waste Garbage Truck (Chengliwei Brand) | 4x2 / 170hp / China VI | From $23,333 | |
| Dongfeng FuruiKa F4 130 hp 4X2(6 wheels) Compactor Refuse Truck (Chengliwei Brand) | 4x2 / 130hp / China VI | From $23,194 | |
| Dongfeng FuruiKa 130 hp 4X2(6 wheels) Compressed Garbage Truck (Chengliwei Brand) | 4x2 / 130hp / China V | From $11,250 | |
| Dongfeng FuruiKa 160 hp 4X2(6 wheels) Compressed Garbage Truck (Chengliwei Brand) | 4x2 / 160hp / China V | From $12,778 |
Dongfeng FuruiKa R5 170 hp 4X2(6 wheels) Kitchen Waste Garbage Truck (Chengliwei Brand)
EXW
From $23,333
Export quote
Dongfeng FuruiKa F4 130 hp 4X2(6 wheels) Compactor Refuse Truck (Chengliwei Brand)
EXW
From $23,194
Export quote
Dongfeng FuruiKa 130 hp 4X2(6 wheels) Compressed Garbage Truck (Chengliwei Brand)
EXW
From $11,250
Export quote
Dongfeng FuruiKa 160 hp 4X2(6 wheels) Compressed Garbage Truck (Chengliwei Brand)
EXW
From $12,778
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Furika 95 hp 4X2(6 wheels) Garbage Truck (Chengliwei Brand) | 4x2 / 95hp / China IV | From $13,611 | |
| Dongfeng Furui Card 90 hp 4X2(6 wheels) Garbage Truck (Chengliwei Brand) | 4x2 / 90hp / China III / Euro III | ||
| Dongfeng Furika 95 hp 4X2(6 wheels) Garbage Truck (Chengliwei Brand) | 4x2 / 95hp / China III / Euro III |
Dongfeng Furika 95 hp 4X2(6 wheels) Garbage Truck (Chengliwei Brand)
EXW
From $13,611
Export quote
Dongfeng Furui Card 90 hp 4X2(6 wheels) Garbage Truck (Chengliwei Brand)
EXW
Export quote
Dongfeng Furika 95 hp 4X2(6 wheels) Garbage Truck (Chengliwei Brand)
EXW
Export quote
Series Specs
Basic Info
Cab dimensions: 6.85×2.25×3.2 / 6.97×2.08×2.57 / 7.1×2.3×2.75 / 7.4×2.3×2.75 / 7.35×2.3×2.75 / 5.8×2×2.3 / 5.5×2×2.23 / 6.47×2.05×2.56m
Type: Kitchen waste truck / Compression-type garbage truck / garbage truck / Dump refuse truck
Drive type: 4X2
Wheelbase: 3800 / 3308 / 3300mm
Front/rear track width: Front: 1745mm; Rear: 1630 / Front: 1525mm; Rear: 1498 / Front: 1740mm; Rear: 1640 / Front track: 1506,1404,1500,1441, Rear track: 1466,1458,1520,1500 / Front track: 1506mm; Rear track: 1466mm / Front track: 1506, Rear track: 1466
Rated mass: 6.2 / 1.63 / 5.7 / 3.32 / 2.38 / 1ton
GVWR: 11.995 / 7.36 / 12.495 / 7.3 / 6.01 / 6.495ton
Front/rear suspension: 1.13/1.92 / 1.055/2.052 / 1.13/2.42 / 1.13/2.47 / 1.13/2.17 / 1.032/1.468 / 1.032/1.168 / 1.032/1.988m
Energy Type: Diesel
Engine parameters
Injection System: Common Rail
Engine Model: ChaochaiNV30-C6G / ChaochaiCY4SK261 / XichaiCA4DB1-13E6 / YuchaiYCD4T4S-130 / YuchaiYCD4P4S-160 / ChaochaiCY4BK151 / YuchaiYC4FA130-50 / YuchaiYC4S150-50 / 4B28BTCI / Yuchai YC4F90-30 / Chaochai CY4102-C3F
Displacement: 2.968 / 3.856 / 2.2 / 3.857 / 4.58 / 2.982 / 3.767 / 2.834 / 2.659L
Emission standard: China VI / China V / China IV / China III / Euro III
Max output power: 115 / 125 / 95 / 118 / 105 / 110 / 70 / 66kW
Max hp: 156 / 170 / 130 / 160 / 143 / 150 / 95 / 90Horsepower
Rated speed: 3200 / 3000 / 2600 / 2800 / 3400rpm
Body Parameters
Special Function Description: Dumping method: rear dump. With 2-person cab, rated payload (kg): 3320; with 3-person cab, rated payload (kg): 3255. Cab selection based on chassis. Protection material: Q235A carbon steel. Connection: front/rear and side guards welded. Rear guard section (mm): 100×50×5, ground clearance (mm): 420. Engine models: 4B28BTCI, SD4BW754U, YN33CRD2, CY4102-CE4F, YC4FA90-40. Corresponding fuel consumption (L/100km): 15.79, 15.51, 15.37, 15.22, 15.09. / Cab optional as per chassis. Roof height: 300mm, roof weight: 230kg. Dump direction: rear dump. / When this vehicle is selected without a rear turnover mechanism, the overall length is 6320mm, corresponding to a rear overhang of 1988mm. The cab is selected according to the chassis. When the cab has 2 passengers, the rated load mass (kg) is 1000; when the cab has 3 passengers, the rated load mass (kg) is 935.
Vehicle certification code: CLW5120TCA6 / CLW5070ZYSD6 / CLW5121ZYSE5 / CLW5071ZZZ4 / CLW5060ZLJ3 / CLW5060ZYS3
Body Brand: Chengliwei
Cargo box parameters
Box volume: 5 / 3m³
Chassis Specs
Chassis Brand: Dongfeng
Chassis Series: Forica R5 / Forica F4 / Forica / Dongfeng
Chassis Model: EQ1125SJ8CDC / EQ1075SJ3CDF / EQ1127SJ8GDC / DFA1070SJ35D6 / EQ1060TJ20D3
rear axle description: Front axle 2T / Rear axle 4T
Leaf spring count: 8/10+7,12/12+9 / 6/6+5 / 8/10+7 / 8/9+5,6/8+4,6/6+5 / 8/9+5,6/8+4 / 6/8+4
Transmission Parameters
Number of gears: 6 / 5Gear
Transmission Model: WLY 6-speed / 5-speed transmission / 5-speed gearbox / Dongfeng 5-Speed
Tire
Tire Size: 245/70R19.5,8.25R20 / 7.00R16 / 8.25R20 14PR,8.25-20 16PR / 7.00-16 14PR / 6.50-16,6.50R16，7.00-16,7.00R16 / 6.50-16
Number of tires: 6pcs
FAQ
What kind of truck is Chengliwei Chengliwei Dongfeng Chassis garbage truck?
Chengliwei Chengliwei Dongfeng Chassis is an export-oriented garbage truck lineup with about 11 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Chengliwei Dongfeng Chassis garbage truck?
Chengliwei Dongfeng Chassis garbage truck export reference is about $10,972 – $23,333. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Chengliwei Dongfeng Chassis garbage truck cover?
Chengliwei Dongfeng Chassis garbage truck mainly covers: Drive: 4x2; Horsepower: 90 hp / 95 hp / 130 hp / 156 hp / 160 hp / 170 hp; Emission: China III / Euro III / China IV / China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Chengliwei Dongfeng Chassis garbage truck?
For Chengliwei Dongfeng Chassis garbage truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is garbage truck typically used for?
garbage truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Chengliwei Dongfeng Chassis garbage truck include?
Chengliwei Dongfeng Chassis garbage truck currently lists about 11 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Chengliwei Dongfeng Chassis garbage truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
