Dongfeng T5 350hp 8X4(12 wheels) Truck-Mounted Crane (Pafeite)(16T)
EXW
From $76,111
Export quote
Pafeite Dongfeng Chassis truck-mounted crane
Main model photos
18 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng T5 350hp 8X4(12 wheels) Truck-Mounted Crane (Pafeite)(16T) | 8x4 / 350hp / China V | From $76,111 | |
| Dongfeng T5 290hp 8X4(12 wheels) Truck-Mounted Crane (Pafeite)(16T) | 8x4 / 290hp / China V | From $73,611 | |
| Dongfeng T5 270hp 8X4(12 wheels) Truck-Mounted Crane (Pafeite)(16T) | 8x4 / 270hp / China V | From $72,222 | |
| Dongfeng T5 350 hp 8X4(12 wheels) Truck-Mounted Crane (Pafeite Brand) | 8x4 / 350hp / China V | From $63,611 | |
| Dongfeng T5 290 hp 8X4(12 wheels) Truck-Mounted Crane (Pafeite Brand) | 8x4 / 290hp / China V | From $59,722 |
Dongfeng T5 290hp 8X4(12 wheels) Truck-Mounted Crane (Pafeite)(16T)
EXW
From $73,611
Export quote
Dongfeng T5 270hp 8X4(12 wheels) Truck-Mounted Crane (Pafeite)(16T)
EXW
From $72,222
Export quote
Dongfeng T5 350 hp 8X4(12 wheels) Truck-Mounted Crane (Pafeite Brand)
EXW
From $63,611
Export quote
Dongfeng T5 290 hp 8X4(12 wheels) Truck-Mounted Crane (Pafeite Brand)
EXW
From $59,722
Export quote
Series Specs
Basic Info
Cab dimensions: 12×2.55×3.95 / 11.95×2.55×3.77 / 9×2.55×3.68m
Type: Truck with crane
Drive type: 8X4 / 6X4 / 4X2
Wheelbase: 2150+4400+1350 / 5850+1350 / 5100mm
Rated mass: 11.705 / 13.375 / 8.575 / 6.155 / 7.125ton
GVWR: 31 / 25 / 18ton
Front/rear suspension: 1.25/2.85 / 1.25/3.5 / 1.25/2.65m
Energy Type: Diesel
Body Parameters
Crane model: QYS-16 / SQS-16 / SPS50000 / QYS-14 / SQS-14 / SQS-12 / SPS30000 / SQS-8 / SPS20000 / SPS16000 / SPS35000
Lifting capacity: 16 / 14 / 12 / 8 / 6.3ton
crane self-weight: 6 / 5 / 4.8 / 4 / 3.5ton
Vehicle certification code: PFT5311JSQGLV / PFT5250JSQGL / PFT5180JSQGLV
Body Brand: Pafeite
Engine parameters
Engine Brand: Yuchai
Engine Model: YuchaiYC6MK350-50 / YuchaiYC6L290-50 / YuchaiYC6A270-50 / YuchaiYC6JA240-50 / YuchaiYC6JA180-50
Displacement: 10.338 / 8.424 / 7.52 / 6.87L
Emission standard: China V
Max output power: 258 / 213 / 199 / 177 / 132kW
Max hp: 350 / 290 / 270 / 240 / 180Horsepower
Max torque: 1600 / 1100 / 950 / 700N·m
Max torque speed: 1100-1500 / 1200-1700 / 1200-1800rpm
Rated speed: 2200 / 2300rpm
Chassis Specs
Chassis Brand: Dongfeng
Chassis Series: Huashen T5 / Yuhu
Chassis Model: EQ1311GLVJ / EQ1250GLJ / EQ5180GLVJ
Leaf spring count: 9/9/13 / 9/10,9/13 / 9/10+8,9/11+8,8/10+8,8/11+8,3/4+3
Transmission Parameters
Number of gears: 10 / 9 / 8Gear
Transmission Model: Fast Gear10JSD140B / Fast Gear9JS119A / Fast Gear8JS85E
Tire
Tire Size: 11.00R20 18PR / 11.00R20 / 10.00R20
Number of tires: 12 / 10 / 6pcs
FAQ
What kind of truck is Pafeite Pafeite Dongfeng Chassis truck-mounted crane?
Pafeite Pafeite Dongfeng Chassis is an export-oriented truck-mounted crane lineup with about 12 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Pafeite Dongfeng Chassis truck-mounted crane?
Pafeite Dongfeng Chassis truck-mounted crane export reference is about $40,000 – $76,111. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Pafeite Dongfeng Chassis truck-mounted crane cover?
Pafeite Dongfeng Chassis truck-mounted crane mainly covers: Drive: 8x4; Horsepower: 270 hp / 290 hp / 350 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Pafeite Dongfeng Chassis truck-mounted crane?
For Pafeite Dongfeng Chassis truck-mounted crane: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is truck-mounted crane typically used for?
truck-mounted crane specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Pafeite Dongfeng Chassis truck-mounted crane include?
Pafeite Dongfeng Chassis truck-mounted crane currently lists about 12 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Pafeite Dongfeng Chassis truck-mounted crane?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
