SAIC Fiat Powertrain Hongyan F3UCE611B*M 520 hp 13L China VI Diesel Engine
EXW
Export quote
SAIC Fiat Powertrain Hongyan Cursor13 Series engine
Main model photos
17 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SAIC Fiat Powertrain Hongyan F3UCE611B*M 520 hp 13L China VI Diesel Engine | 520hp / China VI | ||
| SAIC Fiat Powertrain Hongyan F3UCE611A*M 560hp 13L China VI Diesel Engine | 560hp / China VI | ||
| SAIC Fiat Powertrain Hongyan Cursor13 C13 560E5 560 hp 13L China V Diesel Engine | 560hp / China V | ||
| SAIC Fiat Powertrain Hongyan Cursor13 C13 560 560hp 13L China VI Diesel Engine | 560hp / China VI | ||
| SAIC Fiat Powertrain Hongyan Cursor13 C13 520 520hp 13L China VI Diesel Engine | 520hp / China VI |
SAIC Fiat Powertrain Hongyan F3UCE611A*M 560hp 13L China VI Diesel Engine
EXW
Export quote
SAIC Fiat Powertrain Hongyan Cursor13 C13 560E5 560 hp 13L China V Diesel Engine
EXW
Export quote
SAIC Fiat Powertrain Hongyan Cursor13 C13 560 560hp 13L China VI Diesel Engine
EXW
Export quote
SAIC Fiat Powertrain Hongyan Cursor13 C13 520 520hp 13L China VI Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: CURSOR 13 Series
Engine manufacturer: SAIC Fiat Powertrain Hongyan / SAIC Fiat Hongyan Powertrain Co., Ltd.
Intake type: Exhaust turbocharger
Min. fuel consumption at full load: 185 / 188g/kW.h
Engine net weight: 1230 / 1225kg
Engine Dimensions: 1505x1077x1150 / 1515X1056X1154mm
Bore × Stroke: 135x150mm
Valves per cylinder: 4pcs
Engine Brand: SAIC Fiat Powertrain Hongyan
Engine Model: F3UCE611B*M / F3UCE611A*M / C13 560E5 / C13 560 / C13 520 / C13 480 / Cursor C13 480E5 / Cursor C13 520E5 / Cursor C13 550 / C13 350 C4(F3BEE681D*T) / C13 390 C4(F3BEE681C*T) / C13 430 C4(F3BEE681B*T) / C13 480 C4(F3BEE681A*T) / Cursor13.430(C13.430) / Cursor13.390(C13.390) / Cursor13.350(C13.350) / Cursor13.480(C13.480)
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 12.88L
Emission standard: China VI / China V / China IV
Max output power: 385 / 415 / 412 / 382 / 353 / 404 / 258 / 286 / 316 / 257 / 352kW
Max hp: 520 / 560 / 480 / 550 / 350 / 390 / 430Horsepower
Max torque: 2500 / 2400 / 2200 / 1800 / 2100 / 2000N·m
Max torque speed: 1100-1500 / 1000-1500 / 1100rpm
Rated speed: 1900rpm
Engine Type: Inline 6-cylinder, turbocharged, high-pressure common rail / Inline 6-cylinder, 4-valve, electronically controlled high-pressure common rail system / Water-cooled, 4-stroke, direct injection
FAQ
What kind of truck is SAIC Fiat Powertrain Hongyan SAIC Fiat Powertrain Hongyan Cursor13 Series engine?
SAIC Fiat Powertrain Hongyan SAIC Fiat Powertrain Hongyan Cursor13 Series is an export-oriented engine lineup with about 17 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does SAIC Fiat Powertrain Hongyan Cursor13 Series engine cover?
SAIC Fiat Powertrain Hongyan Cursor13 Series engine mainly covers: Horsepower: 520 hp / 560 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SAIC Fiat Powertrain Hongyan Cursor13 Series engine?
For SAIC Fiat Powertrain Hongyan Cursor13 Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does SAIC Fiat Powertrain Hongyan Cursor13 Series engine include?
SAIC Fiat Powertrain Hongyan Cursor13 Series engine currently lists about 17 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SAIC Fiat Powertrain Hongyan Cursor13 Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
