MC05H.26-61
EXW
Export quote
Sinotruk MC05 Series Engine
Main model photos
18 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| MC05H.26-61 | 260hp / China VI | ||
| Sinotruk MC05H.23-50 230hp 5L China V diesel engine | 230hp / China V | ||
| Sinotruk MC05H.25-50 250hp 5L China V diesel engine | 250hp / China V | ||
| Sinotruk MC05H.23-60 230 hp 5L China VI Diesel Engine | 230hp / China VI | ||
| Sinotruk MC05H.20-60 200 hp 5L China VI Diesel Engine | 200hp / China VI |
Sinotruk MC05H.23-50 230hp 5L China V diesel engine
EXW
Export quote
Sinotruk MC05H.25-50 250hp 5L China V diesel engine
EXW
Export quote
Sinotruk MC05H.23-60 230 hp 5L China VI Diesel Engine
EXW
Export quote
Sinotruk MC05H.20-60 200 hp 5L China VI Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: MC05 Series
Engine manufacturer: Sinotruk Group Co., Ltd. / Sinotruk
Suitable Range: For Trucks
Intake type: Turbocharged Air-to-Air Intercooling
Min. fuel consumption at full load: 199 / 202 / ≤199 / 203g/kW.h
Engine net weight: 459 / 475kg
noise at 1m: ≤94dB
Compression ratio: 16.5:1 / 18 / 18:1
Bore × Stroke: 108x125mm
Valves per cylinder: 4pcs
firing order: 1-3-4-2
Engine Brand: Sinotruk
Engine Model: MC05H.26-61 / MC05H.23-50 / MC05H.25-50 / MC05H.23-60 / MC05H.20-60 / MC05H.25-60 / MC05.21-50 / MC05.18-50 / MC05.16-50 / MC05.14-50 / MC05.14-30 / MC05.16-30 / MC05.15-30 / MC05.18-30 / MC05.21-30 / MC05.18-40 / MC05.16-40 / MC05.14-40 / MC05.21-40 / MC05.15-40
Number of cylinders: 6 / 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 4.91 / 4.58L
Emission standard: China VI / China V / China III / Euro III / China IV
Max output power: 191 / 166 / 180 / 147 / 151 / 132 / 118 / 103 / 110kW
Max hp: 260 / 230 / 250 / 200 / 210 / 180 / 160 / 140 / 150Horsepower
Max torque: 950 / 830 / 700 / 610 / 535 / 570N·m
Max torque speed: 1200-1700 / 1300-1700 / 1400 / 1000-1400rpm
Rated speed: 2400rpm
Engine Type: Inline, water-cooled, 4-stroke, turbocharged with intercooler / Inline 4-cylinder, water-cooled, 4-stroke, turbocharged with intercooler, high-pressure common rail / 4-stroke with turbocharger and intercooler / High-pressure common rail
FAQ
What kind of truck is Sinotruk Sinotruk MC05 Series Engine engine?
Sinotruk Sinotruk MC05 Series Engine is an export-oriented engine lineup with about 20 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Sinotruk MC05 Series Engine cover?
Sinotruk MC05 Series Engine mainly covers: Horsepower: 200 hp / 230 hp / 250 hp / 260 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Sinotruk MC05 Series Engine?
For Sinotruk MC05 Series Engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Sinotruk MC05 Series Engine include?
Sinotruk MC05 Series Engine currently lists about 20 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Sinotruk MC05 Series Engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
