JMC Transit EV 4.4T 5.998m Electric Long Wheelbase Panel Van (High Roof) 85.9kWh
EXW
Export quote
JMC Transit EV Electric Panel Van
Main model photos
8 photos
Models
On sale
JMC Transit EV 4.4T 5.998m Electric Long Wheelbase Panel Van (Medium Roof) 85.9kWh
EXW
Export quote
JMC Transit EV 4.2T 5.998m Electric Long Wheelbase Panel Van (High Roof) 60.16kWh
EXW
Export quote
JMC Transit EV 4.2T 5.998m Electric Long Wheelbase Panel Van (Medium Roof) 60.16kWh
EXW
Export quote
JMC Transit EV 4.3T 5.998m Electric Long Wheelbase Light Bus (High Roof) 85.9kWh
EXW
Export quote
Series Specs
Basic Info
Model code (announced): JX5040XXYTJ-M6BEV / JX5040XXYTJA-M6BEV / JX6601TA-M6BEV / JX6601TB-M6BEV
Wheelbase: 3750mm
Cab length: 5.998m
Cab width: 2.098m
Cab height: 2.59 / 2.36 / 2.595m
Curb Weight: 2.71 / 1.375 / 2.58 / 3.02ton
Rated payload: 1.445 / 2.58 / 1.375 / 2.79ton
GVWR: 4.35 / 4.15 / 4.25ton
Max. speed: 110km/h
Remarks: Standard: central control color large screen. / Color touchscreen, power steering
Front/rear suspension: 0.973/1.275m
electric motor
Motor 1 Brand: Square
Motor 1 Model: TZ220XSFDM60B
Motor Type: Permanent magnet synchronous motor
Energy Type: Electric
total rated power: 60kW
Peak power: 120kW
total peak torque: 320 / 150N·m
total rated torque: 150N·m
Battery/Charging
Charging method: Fast Charge
Battery Brand: CATL
Battery type: Lithium Iron Phosphate Battery
Battery capacity: 85.9 / 60.16kWh
fast charge time: 0.8h
Body parameters
Cargo box volume: 11.5 / 10
Max body depth: 3.565
Max body width: 1.748
Cargo Box Height: 1.843 / 1.614
Chassis Specs
steering assist type: Electric power steering
Body Parameters
Seat count: 3 / 14 / 15Seats
Cab parameters
Seat rows: 3
Wheel brake
Front tire specification: 215/75R16LT
Rear Wheel Specification: 215/75R16LT
Control configuration
ABS:
interior configuration
Multifunction steering wheel:
Reverse Radar:
FAQ
What kind of truck is JMC JMC Transit EV Electric Panel Van?
JMC JMC Transit EV is an export-oriented Electric Panel Van lineup with about 8 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is Electric Panel Van typically used for?
Electric Panel Van focuses on lower-emission work where charging is available. Confirm local charging and registration before purchase.
How many models does JMC Transit EV Electric Panel Van include?
JMC Transit EV Electric Panel Van currently lists about 8 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for JMC Transit EV Electric Panel Van?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
