Sinotruk HOWO NX heavy truck 350 hp 8X4(12 wheels) 6.8m dump truck (Weichai WP9H engine)
EXW
From $50,389
Export quote
Sinotruk HOWO NX Heavy Truck Dump Trucks
Main model photos
587 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk HOWO NX heavy truck 350 hp 8X4(12 wheels) 6.8m dump truck (Weichai WP9H engine) | 8x4 / 350hp / China VI | From $50,389 | |
| Sinotruk HOWO NX heavy truck 350 hp 8X4(12 wheels) 6.5m dump truck (Weichai WP9H engine) | 8x4 / 350hp / China VI | From $50,389 | |
| Sinotruk HOWO NX heavy truck 350 hp 8X4(12 wheels) 6.8m dump truck | 8x4 / 350hp / China VI | From $49,417 | |
| Sinotruk HOWO NX heavy truck 350 hp 8X4(12 wheels) 6.5m dump truck | 8x4 / 350hp / China VI | From $49,417 | |
| Sinotruk HOWO NX heavy truck 350 hp 8X4(12 wheels) 6.2m dump truck | 8x4 / 350hp / China VI | From $48,861 |
Sinotruk HOWO NX heavy truck 350 hp 8X4(12 wheels) 6.5m dump truck (Weichai WP9H engine)
EXW
From $50,389
Export quote
Sinotruk HOWO NX heavy truck 350 hp 8X4(12 wheels) 6.8m dump truck
EXW
From $49,417
Export quote
Sinotruk HOWO NX heavy truck 350 hp 8X4(12 wheels) 6.5m dump truck
EXW
From $49,417
Export quote
Sinotruk HOWO NX heavy truck 350 hp 8X4(12 wheels) 6.2m dump truck
EXW
From $48,861
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk Hohan N5W 340 hp 8X4(12 wheels) 5.6m Dump Truck (Sinotruk) | 8x4 / 340hp / China V | From $50,139 | |
| Sinotruk Hohan N7G 440hp 8X4(12 wheels) 7.6m dump truck | 8x4 / 440hp / China V | From $57,639 | |
| Sinotruk Hohan N7W Standard Transport Edition 400hp 8X4(12 wheels) 5.6m dump truck | 8x4 / 400hp / China V | From $46,667 | |
| Sinotruk Hohan N7W Heavy Truck Standard Transport Edition 400 hp 8X4(12 wheels) 7.2m Dump Truck | 8x4 / 400hp / China V | From $55,139 | |
| Sinotruk Hohan N5G Standard Transport Edition 340 hp 8X4(12 wheels) 5.6m Dump Truck | 8x4 / 340hp / China V | From $49,306 |
Sinotruk Hohan N5W 340 hp 8X4(12 wheels) 5.6m Dump Truck (Sinotruk)
EXW
From $50,139
Export quote
Sinotruk Hohan N7G 440hp 8X4(12 wheels) 7.6m dump truck
EXW
From $57,639
Export quote
Sinotruk Hohan N7W Standard Transport Edition 400hp 8X4(12 wheels) 5.6m dump truck
EXW
From $46,667
Export quote
Sinotruk Hohan N7W Heavy Truck Standard Transport Edition 400 hp 8X4(12 wheels) 7.2m Dump Truck
EXW
From $55,139
Export quote
Sinotruk Hohan N5G Standard Transport Edition 340 hp 8X4(12 wheels) 5.6m Dump Truck
EXW
From $49,306
Export quote
Series Specs
Basic Info
Model code (announced): ZZ3317V326JF1 / ZZ3317V286JF1B / ZZ3317V306JF1 / ZZ3317V286JF1 / ZZ3315N286WE1 / ZZ3315N3866E1 / ZZ3315N356WE1 / ZZ3315N3063E1 / ZZ3315N306WE1 / ZZ3315V2566F1 / ZZ3315N386WE1
Drive type: 8X4
Wheelbase: 1800+3200+1350 / 1800+2800+1350 / 1800+3000+1350 / 1800+3800+1350 / 1800+3500+1350 / 1800+2500+1350mm
Engine Model: WeichaiWP9H350E62 / WeichaiWP8.350E62 / WeichaiWP8.350E61 / WeichaiWP10H400E62 / SinotrukMC09.34-50 / SinotrukMC11.44-50 / WeichaiWP10H400E50 / SinotrukMC07.34-50 / WeichaiWP8.340E51 / SinotrukMC09.38-50 / WeichaiWP7.300E61 / SinotrukMC07.31-50
Transmission Model: SinotrukHW19712C / SinotrukHW19712CL / 12-speed transmission / SinotrukHW19712L / SinotrukHW25712XS / SinotrukHW15710L / SinotrukHW19710 / SinotrukHW19712 / SinotrukHW19710C2
Rear Axle Ratio: 5.57 / 5.45 / 5.143 / 5.571 / 5.32 / 5.26 / 4.8 / 4.63 / 4.77 / 5.73 / 4.875 / 5.286
Cab length: 9.56 / 9.18 / 8.98 / 9.27 / 9.67 / 10.41 / 9.96 / 8.635 / 9.66 / 8.2 / 8.4 / 10.61 / 9.135m
Cab width: 2.55 / 2.496 / 2.52 / 2280m
Cab height: 3.2 / 3.55 / 3 / 3.25m
Front track width: 1996/1996 / 2022/2022 / 2041/2041 / 1930/1930mm
rear track: 1830/1830 / 1860/1860 / 1800/1800mm
Curb Weight: 15.5 / 13.6 / 12.38 / 14.1 / 14.83 / 15.12 / 15.04 / 10.02ton
Rated payload: 15.37 / 17.27 / 18.49 / 16.77 / 16.04 / 15.75 / 15.83ton
GVWR: 31ton
Origin: Jining, Shandong / Jinan, Shandong / Qingdao/Chengdu / Jinan / Jining City / Shandong Zhangqiu
tonnage class: Heavy truck
Approach angle: 17 / 20°
departure angle: 21 / 16 / 20 / 51°
Remarks: Optional: Classic cab, four-way camera; / HW50 direct-connected PTO / HW50 PTO / Transmission with PTO, high bumper, cold climate package, metal oil pan guard / High bumper, four-way camera, metal oil pan guard; folding key
Version: Zhiying Edition / Standard Heavy Load / Standard Transport Edition / Light luxury edition / Standard Container Version
Energy Type: Diesel
Engine parameters
Engine Brand: Weichai / Sinotruk
Number of cylinders: 6 / 5cylinder
Displacement: 8.8 / 7.8 / 9.5 / 8.765 / 10.518 / 6.87 / 7.5L
Emission standard: China VI / China V
Max output power: 257 / 294 / 250 / 324 / 248 / 276 / 220 / 228kW
Max hp: 350 / 400 / 340 / 440 / 380 / 300 / 310Horsepower
Max torque: 1700 / 1400 / 1900 / 1600 / 2100 / 1250 / 1800 / 1300 / 1230N·m
Max torque speed: 1100-1400 / 1200-1600 / 1200-1300 / 1000-1400 / 1200-1800 / 1200-1700rpm
Rated speed: 1900 / 2100 / 2300rpm
Engine Type: CR+DOC+DPF+Hi_SCR / Inline 6-cylinder, water-cooled, 4-stroke, high-pressure common rail, turbocharged intercooled, EGR / Inline, direct injection, water-cooled, 4-stroke, turbocharged, intercooled, electronically controlled high-pressure common rail, Hi+SCR / Inline, 4-stroke, turbocharged with intercooler, Bosch high-pressure common rail CP3.4+ / Inline, water-cooled, 4-stroke, turbocharged with intercooler / Electronically controlled high-pressure common rail SCR / Electronic high-pressure common rail + SCR / High-pressure common rail+EGR / CR+EGR+DOC+DPF+SCR / Inline, direct injection, water-cooled, 4-stroke, turbocharged, intercooled, electronically controlled high-pressure common rail, Hi SCR
Transmission Parameters
Transmission Brand: Sinotruk
shift method: Manual
Forward gears: 12 / 10Gear
Number of Reverse Gears: 2pcs
Housing Material: Steel shell
Cargo box parameters
hydraulic cylinder brand & model: Juntong 172
Unloading Type: Dump type / Rear-dump body
Cargo box length: 6.8 / 6.5 / 6.2 / 6 / 5.8 / 5.6 / 7.6 / 7.2 / 5.4 / 7.8m
Body Parameters
Lifting type: Front lift
FAQ
What kind of truck is Sinotruk HOWO Sinotruk HOWO NX Heavy Truck Dump Trucks?
Sinotruk HOWO Sinotruk HOWO NX Heavy Truck is an export-oriented Dump Trucks lineup with about 37 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Sinotruk HOWO NX Heavy Truck Dump Trucks?
Sinotruk HOWO NX Heavy Truck Dump Trucks export reference is about $43,333 – $65,875. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Sinotruk HOWO NX Heavy Truck Dump Trucks cover?
Sinotruk HOWO NX Heavy Truck Dump Trucks mainly covers: Drive: 8x4; Horsepower: 340 hp / 350 hp / 400 hp / 440 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Sinotruk HOWO NX Heavy Truck Dump Trucks?
For Sinotruk HOWO NX Heavy Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Sinotruk HOWO NX Heavy Truck Dump Trucks include?
Sinotruk HOWO NX Heavy Truck Dump Trucks currently lists about 37 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Sinotruk HOWO NX Heavy Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
